RM2000 Rackmount Kit

The RM2000 is designed for use with the TDS1000/2000 Series
oscilloscopes.
3
2
Figure 1: RM2000 Rackmount Kit parts
Figure 1- x Part number
1- - 1 RM2000
1- - 2 071- - 1103- - XX
1- - 3 016- - 0099- - XX
not saleable
not saleable
not saleable
not saleable
not saleable

RM2000 Rackmount Instructions

1 RMS2000 Replacement
Description
RM2000 Rackmount Kit, includes a front and back
panel set, 2 handles, Instructions, bag of screws
RM2000 Rackmount Kit - - Instructions
Standard mounting hardware in plastic bag, includes:
4 ea (for handles) screws 8-32 x 1/2 phil pan,
#8 med splt L/W
4 ea screw M 5 x 16 oval head phil, flat washers
4 ea screw M 6 x 16 oval head phil, flat washers
6 ea nut 8-32 x 11/32 keps, #10 finish washers
4 ea 10-32 x 3/4 poz, 12-24 x 3/4 poz, flat washers
