MINI 3D Scanner Quick Start Guide

Windows: Connect to the MINI 3D Scanner via USB Cable

OVERVIEW (details on following pages): Double Click to open Revo Scan---> Confirm "Device is connected" (displays

after several seconds) ---> Click New Scan to select Accuracy, Scan Mode and Texture ---> Confirm distance to be

"Excellent" ---> Adjust the brightness in RGB camera and Depth Camera ---> Start/Pause Scanning ---> Stop to

Complete/Restart Scanning ---> Fuse Point Cloud ---> Mesh ---> Texture (only available for Color scans) ---> Export the

3D model

NOTE: The screenshots in this tutorial are from the Windows version of Revo Scan. There will be slight differences in each

of the four device versions.

Make sure the MINI scanner is connected to a

USB 3.0+ port, because USB 2.0 will not supply

sufficient operating current. An indicator of this is

repeated power resets and lost connections.
