BERRINGTON
SOLID FUEL BOILER
STOVE
INSTALLATION AND OPERATING INSTRUCTIONS
This appliance is hot while in operation and retains its heat for a long period of time after use. Children, aged
or infirm persons should be supervised at all times and should not be allowed to touch the hot working surfaces
while in use or until the appliance has thoroughly cooled.
Advertisement
Table of Contents
Related Manuals for AGA Berrington
Summary of Contents for AGA Berrington
- Page 1 BERRINGTON SOLID FUEL BOILER STOVE INSTALLATION AND OPERATING INSTRUCTIONS This appliance is hot while in operation and retains its heat for a long period of time after use. Children, aged or infirm persons should be supervised at all times and should not be allowed to touch the hot working surfaces...
-
Page 2: Table Of Contents
General ............. . Pre Installation Assembly . -
Page 3: General
BERRINGTON SOLID FUEL STOVE INSTALLATION & OPERATING INSTRUCTIONS GENERAL When installing, operating and maintaining your Berrington Stove respect basic standards of fire safety. Read these instructions carefully before commencing the installation. Failure to do so may result in damage to persons and property. Consult... -
Page 4: Flue Pipes
2300 Appliance FLUE PIPES A flue pipe should only be used to connect an appli- ance to a chimney and should not pass through any roof space. Flue pipes may be of any of the following materials: (a) Cast iron as described in BS 41: 1973 (1981), (b) Mild steel with a wall thickness of at least 3mm, (c) Stainless steel with a wall thickness of at least 1mm and as described in BS EN 10095:... -
Page 5: Flue Pipes
These air vents must also be fire proofed as per Building Regulations. Air vents traversing cavity walls should include a continuous duct across the cavity. The duct should be installed in such a manner as not to impair the weather resistance of the cavity. Joints between air vents and outside walls should be sealed to prevent the ingress of moisture. -
Page 6: Floor Protection
LOCATION There are several conditions to be considered in selecting a location for your Berrington Stove. a. Position in the area to be heated- central locations are usually best. b. Allowances for proper clearances to combustibles. -
Page 7: Specifications
Fig 8 Dimensions Metric (mm) NOTE: Dimensions stated below may be subject SPECIFICATIONS Metric Depth 495mm Flue Outlet 152mm Fire Door Size 455x230mm Log Size 400mm SPECIFICATION to a slight +/- variation. TECHNICAL DATA Boiler Tapping: 1” BSP Boiler Capacity: 12.7 Litres Maximum Operating Water Pressure 2.0 Bar Nominal Output: Wood Logs Solid Mineral Fuel Room:... -
Page 8: Plumbing
PLUMBING REGULATIONS The plumbing must be in accordance with all relevant regulations and practices. It must include a gravity circuit with expansion pipe, open to the atmosphere. The central heating will be pump-dri- ven as with other types of boilers. GRAVITY CIRCUIT The gravity circuit consists of the domestic hot water tank of 135 litres indirect cylinder, fixed in an upright... -
Page 9: Low / Slumber Burn
(closed to maximum). Setting 4 will provide the most heat from the appliance. The zero position may not always be in the 12 o’clock position but the knob will only rotate once between fully open and fully closed. (See Fig.10) LOW / SLUMBER BURN To achieve an overnight or a low burn rate, close the air wash slider fully by sliding the lever left using the... -
Page 10: Important Notes
Now that your Solid Fuel Stove is installed and no doubt you are looking forward to many comforts it will provide, we would like to give you some tips on how to get the best results from your stove. 1. We would like if you could take some time to read the operating instructions/hints, which we are confident, will be of great benefit to you. -
Page 11: Lighting
Before lighting the stove, ensure that any build up of ashes in the fire box has been removed and that the ashpan has been emptied. Open the firebox and cover the grate with crumpled pieces of paper. Lay pieces of kindling on top of the paper towards the back of the fire box. -
Page 12: De-Ashing
DE-ASHING When ash build-up becomes excessive in the fire chamber shake the firebars by inserting the operat- ing tool into the round slot on the right side of the stove, twisting clockwise and anti-clockwise. A poker is also provided for de-ashing. DISPOSAL OF ASHES The stove is provided with a steel ashpan. -
Page 13: Fire Safety
FIRE SAFETY To provide reasonable fire safety, the following should be given serious consideration. 1. Do not over fire the stove. 2. Over-firing will also damage painted or enamel finish. 3. Install a smoke detector in the room. 4. A conveniently located class A fire extinguisher to contend with small fires resulting from burn- ing embers. -
Page 14: Exploded View
BERRINGTON SOLID FUEL BOILER STOVE EXPLODED VIEW Aga, Station Road, Ketley, Telford, Shropshire, TF1 5AQ, Ref: N00430AXX Rev: 001 DP070308...
