BERRINGTON NON BOILER
SOLID FUEL STOVE
INSTALLATION AND OPERATING INSTRUCTIONS
This appliance is hot while in operation and retains its heat for a long period of time after use. Children, aged
or infirm persons should be supervised at all times and should not be allowed to touch the hot working sur-
faces while in use or until the appliance has thoroughly cooled.
PLEASE READ THESE INSTRUCTIONS CAREFULLY BEFORE INSTALLATION. These instructions cover
the basic principles to ensure the satisfactory installation of the stove, although detail may need slight
modification to suit particular local site conditions.
Advertisement
Table of Contents
Related Manuals for AGA BERRINGTON NON BOILER
Summary of Contents for AGA BERRINGTON NON BOILER
- Page 1 BERRINGTON NON BOILER SOLID FUEL STOVE INSTALLATION AND OPERATING INSTRUCTIONS This appliance is hot while in operation and retains its heat for a long period of time after use. Children, aged or infirm persons should be supervised at all times and should not be allowed to touch the hot working sur- faces while in use or until the appliance has thoroughly cooled.
-
Page 2: Table Of Contents
TABLE OF CONTENTS PAGE NO. General ............. . Health &... -
Page 3: General
BERRINGTON SOLID FUEL STOVE INSTALLATION & OPERATING INSTRUCTIONS IMPORTANT WARNING In all cases the installation must comply with cur- rent Building Regulations, Local Authority Bylaws This stove must not be installed into a chimney that and other specifications or regulations as they serves any other heating appliance. -
Page 4: Flues
FLUES Flue pipes may be of any of the following materials: Flues should be vertical wherever possible and (a) Cast iron as described in BS 41: 1973 (1981), where a bend is necessary, it should not make an angle of more than 45 with the vertical. -
Page 5: Ventilation & Combustion Air Requirements
VENTILATION & COMBUSTION AIR above operation, an additional air vent of sufficient REQUIREMENTS size to prevent this occurrence should be installed. This appliance is rated at less than 9kW. It is imper- PERMANENT AIR VENT ative that there is sufficient air supply to the stove in The stove requires an adequate air supply in order order to support correct combustion. -
Page 6: Flue Connection
FLUE CONNECTION INSTALLATION CLEARANCES This stove can be connected to either a top flue exit Maintain at least the following clearances to all or a rear flue exit by simply reversing the orientation combustible material: of the flue spigot on the flue spigot flange. When From the front 910 mm connecting to a flue pipe it is recommended to have... -
Page 7: Technical Data
SPECIFICATION Fig.7 NOTE: Dimensions stated are in Millimetres and may be subject to a slight +/- variation. TECHNICAL DATA Nominal Heat Output: Wood Logs 8.2kW Solid Mineral Fuel 8.5kW Typical refuelling intervals to obtain nominal outputs: 1.5 hours wood 4 hours solid mineral fuel Flue Outlet Diameter 152mm Fire Door Size:... -
Page 8: Operating Instructions
OPERATING INSTRUCTIONS (closed to maximum). Setting 4 will provide the most heat from the appliance. The zero position may not COAL, ANTHRACITE, WOOD SYNTHETIC LOGS, always be in the 12 o’clock position but the knob will OR OTHER FUELS. “Never use gasoline” gasoline only rotate once between fully open and fully closed. -
Page 9: Important Notes
IMPORTANT NOTES Now that your AGA Solid Fuel Stove is installed and no doubt you are looking forward to many comforts it will provide, we would like to give you some tips on how to get the best results from your stove. -
Page 10: Lighting
LIGHTING Before lighting the stove, ensure that any build up of ashes in the fire box has been removed and that the ashpan has been emptied. Open the firebox and cover the grate with crumpled pieces of paper. Lay pieces of kindling on top of the paper towards the back of the fire box. -
Page 11: De-Ashing
DE-ASHING TO CLEAN CHIMNEY OUTLET When ash build-up becomes excessive in the fire These parts are heavy and must be allowed to chamber shake the firebars by inserting the operat- cool before removal. ing tool into the round slot on the right side of the stove, twisting clockwise and anti-clockwise. -
Page 12: Fire Safety
FIRE SAFETY GLASS CLEANING The glass will self clean when there is sufficient heat To provide reasonable fire safety, the following generated by the burning fuel. If a build-up of cre- should be given serious consideration. osote occurs on the glass it may be due to draft con- ditions, poor quality fuel or very low burning for a Do not over fire the stove. -
Page 13: Exploded View
28. Nylon Cap Washer 46. Glass Shaker Bar Sleeve 29. Handle End Cap 47. Cranked Hinge 2 1/2” Black Air Slide Sub-assembly 30. Aga Badge 48. Door Latch C/P Ashpan 31. Driven Rocker Bar 49. Retainer Glass Door Top Ash Compartment 32. - Page 14 Aga, Station Road, Ketley, Telford, Shropshire, TF1 5AQ, Ref: N00401AXX Rev: 005 DP110214...
