ELLESMERE 4K / 5K / 6K
Non Boiler SF Steel Stove
This appliance is hot while in operation and retains its heat for a long period of time after use.
Children, aged or infirm persons should be supervised at all times and should not be allowed
to touch the hot working surfaces while in use or until the appliance has thoroughly cooled.
When using the stove in situations where children, aged and/or infirm persons are
present a fireguard must be used to prevent accidental contact with the stove. The fireguard
should be manufactured in accordance with BS 8423:2002.
INSTALLATION AND OPERATING INSTRUCTIONS
(Smoke Exempt)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ELLESMERE 4K and is the answer not in the manual?

Questions and answers

Related Manuals for AGA ELLESMERE 4K

Summary of Contents for AGA ELLESMERE 4K

  • Page 1 ELLESMERE 4K / 5K / 6K Non Boiler SF Steel Stove (Smoke Exempt) This appliance is hot while in operation and retains its heat for a long period of time after use. Children, aged or infirm persons should be supervised at all times and should not be allowed to touch the hot working surfaces while in use or until the appliance has thoroughly cooled.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS PAGE NO. Installation & Operating Instructions ........General .

  • Page 3: Installation & Operating Instructions

    Further information on the requirements of the Clean Work Act are met. Air Act can be found here : Any alteration that is not approved by AGA, could http://smokecontrol.defra.gov.uk/ invalidate the approval of the appliance, operation of the warranty and could also affect your statutory Your local authority is responsible for implementing rights.

  • Page 4: Pre-Installation

    TOP FLUE EXIT PRE-INSTALLATION Push the flue connector pipe (not supplied) into the Before using the stove for the first time all remaining flue spigot and cement into place using approved stickers must be removed, all accessories must be fire cement ensuring that no cement blocks the flue removed from the ashpan, check if any items have passageway (see Fig.1).

  • Page 5: Ventilation & Combustion Air Requirements

    Fig 2 If there is another appliance using air fitted in the same or adjacent room, it will be necessary to provide an additional air supply. All materials used in the manufacture of air vents should be such that the vent is dimensionally stable, corrosion resistant, and no provision for closure.

  • Page 6: Commissioning & Handover

    For free standing installations it is acceptable to Note:- If there is any work that is being carried out place the stove on a solid sheet of non combustible that would effect the air quality supplied to the stove material minimum 12mm thick, as the product will such as sanding a floor or glueing linoleum etc.
  • Page 7 REDUCED CLEARANCE TO COMBUSTIBLES - (With Heatshield) - See Figs 4a, 4b, 4c Side wall to stove 28” 700mm Back wall to stove 28” 700mm Corner 25” 635mm Mantle clearance 25” 635mm Fig.4a Fig.4b Fig.4c...

  • Page 8: Stove Dimensions

    STOVE DIMENSIONS Fig. 5 Note: Dimensions stated are in milimeters and may be subject to a slight +/- variation.

  • Page 9: Technical Data

    ELLESMERE STOVES TECHNICAL DATA 4 kW FUEL WOOD ANCIT WOOD ANCIT WOOD ANCIT Nominal Output - Room Typical refuelling intervals to obtain nominal outputs [Hour] Fuel Gas Mass Flow [g/s] Flue Gas Temp at Nominal Output [ Efficiency [%] 81.9 79.1 81.9 78.8...

  • Page 10: Air Controls

    When the fire has established the air control should AIR CONTROLS be pushed pushed fully to the right for most efficient On the Ellesmere range of multifuel stoves there is burning of smokeless coals and then pulled forwards one air control controlling both primary and sec- to slow the burn rate as desired.

  • Page 11: Riddling

    Remember to reset the controls after refuelling. RIDDLING DAMPERS / AIR CONTROLS LEFT OPEN Riddle the fire by connecting the hexagon end of the operating tool into the riddling tool socket located on Operation with the air controls or appliance dampers the left side of the stove.

  • Page 12: Maintenance

    MAINTENANCE WARNING NOTE Properly installed, operated and maintained the CREOSOTE - Formation and Need for Removal stove will not emit fumes into the dwelling. When some fuels are burned slowly, they produce Occasional fumes from de-ashing and re-fuelling tar and other organic vapours, which combine with may occur.

  • Page 13: Lighting

    13. This appliance should be regularly maintained and close the door. by a competent service engineer. Use only replacement parts recommended by AGA. 4. When the firebed has fully ignited and is starting Using unauthorised parts will invalidate to die back add 3 small logs, or a small quantity your guarantee and may cause damage or of smokeless fuel.

  • Page 14: Co Alarms

    3. A practical evacuation plan. Lift and hold the stainless steel protection baffle while catching the remaining back brick on the top 4. A plan to deal with a chimney fire as follows: edge and tilting it forward to remove the brick followed by the stainless steel protection baffle.

  • Page 15: Glass

    GLASS 1. How to clean: The glass will clean itself when there is sufficient heat generated by burning fuel. If a build-up of creosote occurs on the glass it may be due to draft conditions, poor quality fuel or very slow burning for a long time.

  • Page 16: Exploded View - Ellesmere 4Kw

    EXPLODED VIEW - ELLESMERE 4kW SPACER - 013A_0300_081 22. GLASS - 177A_0300_051 SPRING - 044B_0000_401 23. GLASS CLIP - 177A_0300_061 LEG ADJUSTER - 061A_0000_131 24. DOOR HANDLE - 177A_0300_071 BASE PLATE - 177A_0000_011 25. WASHER - 177A_0300 _081 ASHPAN - 177A_0000_031 26.

  • Page 17: Exploded View - 5Kw

    EXPLODED VIEW - ELLESMERE - 5kW SPACER - 013A_0300_081 22. GLASS - 177B_0300_051 SPRING - 044B_0000_401 23. GLASS CLIP - 177A_0300_061 LEG ADJUSTER - 061A_0000_131 24. DOOR HANDLE - 177A_0300_071 BASE PLATE - 177B_0000_011 25. WASHER - 177A_0300 _081 ASHPAN - 177B_0000_031 26.

  • Page 18: Exploded View - 6Kw

    EXPLODED VIEW - ELLESMERE - 6kW SPACER - 013A_0300_081 22. GLASS - 177A_0300_051 SPRING - 044B_0000_401 23. GLASS CLIP - 177A_0300_061 LEG ADJUSTER - 061A_0000_131 24. DOOR HANDLE - 177A_0300_071 BASE PLATE - 177C_0000_011 25. WASHER - 177A_0300 _081 ASHPAN - 177C_0000_031 26.

  • Page 19: Trouble Shooting

    TROUBLE SHOOTING SYMPTOM POSSIBLE CAUSES REMEDY Stove Difficult To Light Air controls set incorrectly Air controls must be set to maximum settings on initial light-up Moisture content of fuel too high Ensure fuel is sufficiently dry Fire Burns Too Quickly Air controls set incorrectly Adjust Air controls Rope seals perished/worn...
  • Page 20 Condensation on light up It is acceptable to have a little condensa- tion on start up, when the fire is established condensation should not be present Moisture content of fuel too high Use correct fuel AGA, Station Road, Ketley, Telford, Shropshire, TF1 5AQ,...
