Parts List - RITE-HITE REVOLUTION SP Installation And Owner's Manual

Hub
Blades
Clevis Cover
Dome Hub Cover
Flat Hub Cover
Frame Screen Insert
Replacement Blade Bolt
Pub. No. RFSP Rev. 5 - December 2010
Part Number Quantity General Description
135151 1 Hub, 10", 22 deg. Blade angle
135152 2 (2) Blade set, 8', RSP, Polished
135153 2 (2) Blade set, 10', RSP, POLISHED
135154 2 (2) Blade set, 12' RSP POLISHED
135155 2 (2) Blade set, 8', RSP ANODIZED
135156 2 (2) Blade set, 10' RSP ANODIZED
135157 2 (2) Blade set, 12' RSP ANODIZED
135280 2 (2) Blade set, 8', RSP MILL FINISH
135281 2 (2) Blade set, 10' RSP MILL FINISH
135282 2 (2) Blade set, 12' RSP MILL FINISH
135158 4 Clevis Cover, Annodized
135159 4 Clevis Cover, Polished
135160 4 Clevis Cover, Painted
135161 1 Dome Hub Cover, Painted to match Annodize
135283 1 Dome Hub Cover, Painted to match MILL FINISH
135162 1 Dome Hub Cover, Plated to match Polished
135163 1 Dome Hub Cover, Painted to match painted blades
135164 4 Bolt, .3125-18 x .50, socket head cap screw, self locking
135165 1 Flat Hub Cover, Annodized
135166 1 Flat Hub Cover, Polished
135167 1 Flat Hub Cover, PAINTED
135164 4 Bolt, .3125-18 x .50, socket head cap screw, self locking
135168 4 4" x 20" ABS FRAME INSERT, annodized
135169 4 4" x 20" FRAME INSERT, polished
135170 4 4" x 20" FRAME INSERT, painted to match blades
135171 1 Blade Bolt, Replacement, 22mm x 102 mm Aluminum with Acorn nut RSP Fan
REVOLUTION SP FAN
PARTS
25
