REVOLUTION SP FAN
COMPONENTS AND TOOLS
UNPACKING OF THE COMPONENTS
You should have received the following items:
(2) boxes of fan blades, they are packed (2) per box for a total of (4) blades – approximately 25
lb. (11.4 kg) per box.
(1) motor / hub assembly – approximately 80 lb. (36.4 kg)
(1) box containing miscellaneous mounting hardware and cables - approximately 25 lb. (11.4 kg)
(1) box containing the control box – approximately 35 lb. (15.9 kg)
Insure you have received all of the above items before installation begins. Notify the factory if
parts are missing or damaged.

TOOLS REQUIRED:

7
(2) ⁄ " wrenches
1 6
(2) ½" wrenches
(1) 1 ¼" box end wrench
1
(1) 1 ⁄ " box end wrench
1 6
(2) ¾" wrenches
(1) Vice grip
(1) Large standard screwdriver
(1) Small standard screwdriver
(1) Torque wrench capable of 50 ft-lb
(1) Metric 7mm deep well socket - Only required for motor voltage change
(1) ¼" cable cutter
(4) 10 AWG electrical terminals for motor terminations
If you are mounting to support angles that span building joists, you will also need a
drill and a ½" drill bit.
4
Pub. No. RFSP Rev. 5 - December 2010
