CONTROL BOX MOUNTING

Mount the control box securely to a wall or building column with appropriate anchors (not
provided). The box should not be greater than 200 ft. (61m) from the fan it is controlling. The fan
should be visible from where the control box is mounted. Mount the VFD control box in a location
where it will still be accessable for troubleshooting.
The electrical system (ground system, insulation etc.) must be verified by an authorized
electrician before fan is put into operation. The verification data should be entered in a record
and be stored by the customer.
RECOMMENDED FUSE RATINGS
Recommended Branch
Input Voltage
110-120V, 1PH, 60 Hz.
200-240V, 1PH, 60 Hz.
200-240V, 3PH, 60 Hz.
460-480V, 3 PH, 60 Hz.
380V, 3PH, 50 Hz.
575V, 3PH, 60 Hz.
INPUT WIRING
Bring the input wires into the bottom of the fuse block. Tighten the screws to secure the wires.
Insert the wires that are going to the motor into the contact blocks that are labeled U, V, W.
Insert the ground wire into the green contact block.
!
WA R N I N G ! ! !
Increasing the speed of the fan beyond
factory set limits is not recommended and
can shorten the life of the motor.
MOTOR RATING
Input Voltage
200-240V, 1PH, 60 Hz.
200-240V, 3PH, 60 Hz.
460-480V, 3 PH, 60 Hz.
380V, 3PH, 50 Hz.
16
Circuit Protection
Amps
20A
15A
15A
15A
15A
10A
Volts
230
400
460
380
Recommended
Incoming Service
Amps
20A
15A
10A
6A
6A
6A
Motor
Freq.
60
60
60
50
F.L.A
3.2
3.2
1.6
1.8
