RavenUpgrade.FB 7 Mon Jul 15 11:43:09 1996
Removing Memory Modules
Removing Memory Modules
After removing the main tray from the system, you must remove the mem-
ory modules from the original C100/110 CPU board, as described in the fol-
lowing procedure:
1 Locate the memory modules on the C100/C110 CPU board, as shown in Figure 3.
Memory Connectors
Figure 3
C100/110 Memory Module Location
7
