RavenUpgrade.FB 16 Mon Jul 15 11:43:09 1996

Installing Option Boards

2 Remove the screw from the EISA retainer, and remove the EISA retainer, as

shown in Figure 10.

Eisa Slider

Eisa Retainer

Figure 10

Removing the EISA Retainer and EISA Slider

3 Remove the EISA Slider, as shown in Figure 10.
