RavenUpgrade.FB 8 Mon Jul 15 11:43:09 1996
Figure 4
Removing Memory Modules
2 To remove a memory module, push the ejector tabs on each side of the module.
Lift the memory module up and out of the connector and place it on a static-free
surface. Figure 4 shows how to remove a memory module.
Removing a Memory Module
8
