RavenUpgrade.FB 9 Mon Jul 15 11:43:09 1996
Removing Option Boards
Removing Option Boards
If your C100/110 system has any option boards installed, you must remove
them from the original C100/110 main tray, as described in the following
procedure:
1 Press the fan release clip and rotate the fan, as shown in Figure 5.
Figure 5
Rotating the Fan
9
