Installing Option Boards

Installing Option Boards
If you are installing a graphics adapter, read and understand the information
in the subsection titled Graphics Adapter Considerations below before con-
tinuing. Otherwise skip to the subsection titled Option Board Installation.
Graphics Adapter Considerations
If you are installing a graphics option, read the information about the unsup-
ported graphics listed on page 2 first.
Option Board Installation
If you removed option boards from the C100/110 main tray, use this proce-
dure to install them in the new C160L main tray. Otherwise, skip to the next
section.
1 Press the fan release clip and rotate the fan, as shown in Figure 9.
Figure 9 Rotating the Fan
15
