- Page 1 Backs & Support tooltip Simple Solutions Fixed Hardware Owner’s Manual - Maintenance Guide True Forming Back -Simple Solutions Stability Hardware...
-
Page 2: Table Of Contents
Table of Contents Customer Satisfaction ................i Important Information................ii-iii Warranty ........................ii Supplier Reference ....................ii Warning Labels ....................iii Limited Liability....................iii Testing ........................iii Design and Function .................. 1 Intended Use ......................1 Parts Breakdown....................1 Installation Instructions .................2-5 Preparations...................... -
Page 3: Customer Satisfaction
For further assistance, or more advanced applications, please contact your supplier or Stealth Products at (512) 715-9995 or toll free at (800) 965-9229. Always keep the operating instructions in a safe place so they may be referenced as necessary. -
Page 4: Important Information
Warranty Our products are designed, manufactured, and produced to the highest of standards. If any defect in material and workmanship is found, Stealth Products will repair or replace the product at our discretion. Any implied warranty, including the implied warranties of merchantability and fitness for a particular purpose, shall not extend beyond the duration of this warranty. -
Page 5: Warning Labels
Stealth Products does not hold responsibility for final integration of final assembly of product to end user. Stealth Products is not liable for user death or injury. Testing Initial setup and driving should be done in an open area free of obstacles until the... -
Page 6: Design And Function
The Simple Solutions Fixed hardware is intended to provide a versatile mounting solution for end users who require a fixed mounting hardware for the True Forming Back (TFB) family. The hardware features isolated depth and angle adjustments that provide trouble-free adjustability. -
Page 7: Installation Instructions
Installation Instructions Item Part Number Description Qty. A. J & L Hardware SSS200-36 1" Hold Down Drop Stop Weldment (4-point only) SSS200-152 1 IN 7 Hole J-Hook SSS200-153 Double Slot Adjustable L-Bracket 67582247 5/16 4 10 Internal Tooth H-Lock Washer TFB200-88 Single Hole T-Nut Metric M6x1mm Thread, 14.3mm Barrel Height... -
Page 8: Mounting The Hardware To The Back Shell
Installation Instructions Mounting the Hardware to the Back Shell Step One: Place M6x1x16mm Button Head Screws (A5) and M6 Washers (A4) in the top and bottom slot of the Mounting Bracket (A)*. * Bracket shown without hardware for clarity. 90° Bracket shown; 45° may be used. -
Page 9: Mounting The Hardware To The Back Posts
tooltip Installation Instructions Mounting the Hardware to the Back Posts 7/8" 1" 3/4" The Back Post Clamp can be simply installed on 3/4", 7/8" and 1" back posts. tooltip Step One: Loosen the M5x0.8x25mm Socket Head Screws (C4) on the Back Post Clamps. -
Page 10: Mounting The J&L Hardware
tooltip Installation Instructions Mounting the J & L Hardware 4-point installations require the J & L hardware in the lower position. Depending on the back shell installed, you will use a 45° or 90° bracket* to mount this hardware to the back shell. (J & L is not included with 2-point or HD installations.) Step One: For one inch canes, the Hold Down Drop Stop Weldment (B) can be placed directly on the cane. -
Page 11: Operating Instructions
Operating Instructions Adjustments Depth Adjustment tooltip Note: The Angle Adjustment Plate has two mounting positions, 2" (51mm) apart. This allows a total of 4.5" (115mm) of total depth adjustment. Step One: Loosen the M6x1x16mm Flat Head Screw (A6), the M6x1x20mm Button Head Screw (A8) on the mounting brackets. -
Page 12: Width Adjustment
Operating Instructions tooltip Width Adjustment Step One: Loosen the M6x1x16mm Button Head Screws (A5) on both left and right mounting brackets (A1). tooltip Step Two: Position the mounting brackets (A1) at the desired width. Step Three: Secure the mounting brackets (A1) by tightening the two M6x1x16mm Button Head Screws (A5). -
Page 13: Angle Adjustment
Operating Instructions Angle Adjustment Simple Solutions Fixed mounting hardware allows the back shell to pivot 22.5° up or down. 45° tooltip Step One: Loosen the two M6x1x20mm Socket Head Screws (B1) on both left and right mounting brackets. Step Two: The angle plate allows for 22.5°... -
Page 14: First Time Use
First Time Use Dealer Assistance During first-time use by the client, it is advised that the dealer or service technician assists and explains the set-up to the customer (the user and/or the attendant). If needed, the dealer may make final adjustments. User Testing It is important that the customer is fully aware of the installation, how to use it, and what can be adjusted in order to gain as much mobility as possible. -
Page 15: Maintenance
Maintenance Cleaning • Use a so� cloth to clean the hardware. • Ensure all cleaners are approved for finished steel, aluminum, plas�c, and upholstered surfaces. • A brush with soap and water can be used to remove any dirt and debris. Disinfection •... - Page 16 © 2022, Stealth Products, LLC Warranty Information Home Page Online User Manual Stealth Products, LLC · info@stealthproducts.com · www.stealthproducts.com (800) 965-9229 | (512) 715-9995 | 104 John Kelly Drive, Burnet, TX 78611 P136D687 TFB Fixed Hardware.afpub Mar 25, 2022...
