Welcome
Worldpay from FIS® is proud to support ReyPAY® payments processing
with a new partnership that offers you enhanced reporting, innovative
technology and high-line support.
If you have any questions as you transition to the Worldpay platform, please
call us at 866.304.4279 and select the ReyPAY credit card processing support
option. ReyPAY support is available 24/7/365.
2
Ingenico Lane/iPP320 easy setup guide (triPOS Cloud)
Please follow these steps to setup your device
Step 1:
Configure the device for a static IP address if needed
By default, when set up as an IP PIN pad, the Ingenico device is configured to
use DHCP to obtain an IP address. Do not change any setting not explicitly
mentioned in this section. Changing the "Host URL" setting can render the
device useless and force the merchant to send it back for reconfiguration.
To configure the iPP320 PIN pad to use a static IP, use the following steps:
1. Reboot the PIN pad (see p. 4)
2. When the RBA info screen appears, type 2 6 3 4 and press
3. Press F to get the menu
4. Press 3 TDA
5. Press 0 for Configuration
6. Press 0 for Communication
7. Press 0 for Select Comm. Type
8. Press 2 for Ethernet
CANCEL
9. Press
10. Press 2 for Ethernet Settings
11. Press 0 for Connection Method
12. Press 0 for Client
CANCEL
13. Press
14. Press 1 for DHCP and select Static
CANCEL
15. Press
16. Press 3 for IP Address
ENTER
17. Enter an IP Address and press
18. Press CANCEL a few times until the PIN pad asks to reboot
19. Press 1 for Yes
(If you're using a Static IP Address, use options 3 (IP Address), 4 (Subnet Mask),
5 (Gateway), 6 (DNS 1 Address) and 7 (DNS 2 Address) to set up the network.)
Ingenico Lane/iPP320 easy setup guide (triPOS Cloud)
ENTER
