- Page 1 IF YOU HAVE ANY QUESTIONS OR CONCERNS PLEASE VISIT OUR WEBSITE AT: www.sunjoyonline.com OR TOLL FREE AT: 1-866-578-6569 8:00 AM EST to 8:00 PM PST SUNJOY GROUP I NTER NA TI ONAL PTE LTD 619 Slack St reet Steubenville, Ohio 43952 USA Production Number：2018xxxx...
- Page 2 ASSEMBLY INSTRUCTIONS ITEM# L-GZ215PST-5B SKU# 164707 10’x12’ HAMPTON GAZEBO THIS UNIT IS HEAVY! WARNING: 1.Assembly Instructions must be followed. 2. Gazebo must be secured / anchored when fully assembled. Note: DO NOT assemble this item alone for safety. Four people are necessary.
- Page 3 or other items due to the failure to take down the item during any inclement weather. CARE AND MAINTENANCE: 1. This item is intended for decorative and sunshade purposes only, and is not designed to withstand severe weather, including high winds, sustained tropical downpours, and snow. In order to avoid damage in such instances, remove any accumulated water and the roof immediately.
- Page 4 Parts List Part NO. QTY CS NO. Image Description Post P11144B01100 P11651A01100 Post Base Base Protector P11539A01100 Short Beam (1) P11042C01100 Short Beam (2) P11043C01100 Long Beam (1) P11044C01100 Long Beam (2) P11045C01100 P10737A01100 Slanting Bar Connector Support Bar P11884A01100 P10307B01100 Big Top Bar Connect Bar...
- Page 5 Hardware Pack 1 CS NO. Part NO. Description Image M6X15 screw 8 PCS H09015C11 M6 flat washer 64 PCS H19001C11 H02015C11 M6X15 bolt 40PCS M6X35 bolt 16 PCS H02035C11 M6 wrench 1 PC H00001C12 Fig.1: Fit the base protector (C) onto the post (A), connect the post base (B) and post (A) by using screw (AA) and flat washer (BB).
- Page 6 Fig.4: Attach the netting bar N (M) to beam D (E, F, G) by using bolt (CC) and washer (BB). Fig.5: Fix the support bar (I) to beam G (D, E, F) and post (A) by u sing bolt (CC) and washer (BB). Hardware Pack 2 CS NO.
- Page 7 Fig. 6: Insert the connect bar (J2) to the big top bar (J1), fix them by using bolt (CC) and washer (BB). Fig.6 -1: Insert the big top bar (J1) to the big top connector (O). Screw the hook (P) to big top connector (O). Fig.7: Attach the connect bar (J2) to the post (A) by using screw (EE), washer (BB) and nut (FF).
- Page 8 Fig.12: Hang the mosquito netting (V) to the netting bar N (M) by using Small plastic ring (HH). Fig.13: Hang the wall (U) to the beam (F, D, E, G) by using Big plastic ring (II). Fig.14: Lift the base protector (C ), secure the assembled gazebo to lawn with Peg ( GG ).
