10x12 ft Monterey Gazebo-Canopy
Assembly Instruction
L-GZ215PST-4-PK
SAFETY INFORMATION
Please read and understand this entire manual before attempting to
assemble
or install the product.
WARNING
Keep all children and pets away from assembly area. Children and pets
should be supervised when they are in the area.
Keep all flame and heat sources away from the tent fabric. This tent is
made with fabric that meets CPAI-84 specification for flame resistance. It
is not fireproof. The fabric will burn if left in continuous contact with any
flame sources. The application of any foreign substance to the tent fabric
may render the flame-resistant properties ineffective.
PREPARATION
Before beginning assembly of product, make sure all parts are present.
Compare parts with package contents list. If any part is missing or
damaged, do not attempt to assemble the product.
