  • Page 1 BARCO PROJECTION SYSTEMS 6300 Kit R812302K INSTALLATION MANUAL KIT POLARISER BEAM SPLITTER FOR 6300 PROJECTORS Date : Rev : Art. No. : 170699 R5976048...
  • Page 2 Produced by BARCO NV, June 1999. All rights reserved. Trademarks are the rights of their respective owners. BARCO n.v./Projection Systems Noordlaan 5 B-8520 Kuurne Belgium Tel : +32/56/368211 Fax : +32/56/351651 E-mail : sales.bps@barco.com Visite Barco at the web : http://www.barco.com Printed in Belgium...
  • Page 3 Safety This procedure is intended for use only by qualified service technicians who have been trained and authorized by BARCO ! Hot Surface Switch the projector to stand by and let it cool down for at least 15 minutes before starting with the Analyser replacement.
  • Page 4 Wear a wrist band which is connected to the ground while handling the static sensitive Protection Steps parts. Part Listing The kit contains one PBS : Part Number Description Indication R812302 R5976048 Manual inst PBS 6300 Illustration of the BARCO ——————————————————— 4 ————————————— Projection Systems...
  • Page 5 Open both lens locks by pulling them backwards. Take the lens out of the lens house. Illustrations on Removing the Lens Image 1 Motor part Fixation screws Lens lockings Image 2 To be continued on next page. BARCO ——————————————————— 5 ————————————— Projection Systems...
  • Page 6 To remove the top cover, follow the next procedure: Top Cover Step Action Image Pull the 3 rubber sealing pieces. Turn out the 3 fixing screws. Take off the top cover. Illustrations on Top Cover Removal Image 1 Image 2 BARCO ——————————————————— 6 ————————————— Projection Systems...
  • Page 7 1 & 2 both sides of the indicated points to unlock. Pull out the cable. Illustrations Press to unlock connector cable Connector Press to lock Image 1 Image 2 To be continued on next page. BARCO ——————————————————— 7 ————————————— Projection Systems...
  • Page 8 To remove the PMP, follow the next procedure: Step Action Image Turn out the indicated screws. Take off the PMP. If an SDI module is installed, unplug both coax cables before taking off the PMP. Illustrations Image 1 BARCO ——————————————————— 8 ————————————— Projection Systems...
  • Page 9 To mount the feet, follow the next procedure : Feet Step Action Image Turn in the feet on the indicated positions. The projector is ready to be turn upside down. Illustrations Image 1 Image 2 BARCO ——————————————————— 9 ————————————— Projection Systems...
  • Page 10 Pivote the module backwards. Illustrations Image 1 Image 2 Removing Fan To remove the fan, follow the next procedure : Step Action Image Turn out both indicated screws. Slide out the fan Illustrations Image 1 Image 2 BARCO ——————————————————— 10 ————————————— Projection Systems...
  • Page 11 Image Turn the projector upside down. Turn out the 3 feet. Turn out the 3 indicated fixing screws. Take off the bottom cover. Illustrations Image 1 Image 2 To be continued on next page. BARCO ——————————————————— 11 ————————————— Projection Systems...
  • Page 12 Turn out the indicated screw. Turn the projector upside down. Turn out the indicated screw on the left side and on the top side. Slide off the local keypath by moving it backwards Illustrations Image 1 Image 1 BARCO ——————————————————— 12 ————————————— Projection Systems...
  • Page 13 To remove the lightpath cover, follow the next procedure : Lightpath Cover Step Action Image Turn the projector back to normal position Turn out the indicated screws. Take off the lightpath cover. Illustrations Image 1 Image 2 BARCO ——————————————————— 13 ————————————— Projection Systems...
  • Page 14: Step Action

    Insert the PBS so that the holes in the metal frame of the PBS matches the notches (A, B) on the projector frame. Secure this position by turning in both fixing screws. Illustrations Image 1 Image 2 Image 3 Image 4 BARCO ——————————————————— 14 ————————————— Projection Systems...
  • Page 15 Necessary Parts None Mounting the To mount the lightpath cover, follow the next procedure : Lightpath Cover Step Action Image Put the lightpath cover on its place. Turn in the indicated screws. Illustrations Image 1 BARCO ——————————————————— 15 ————————————— Projection Systems...
  • Page 16 Turn in the indicated screw on the left side and on the top side. Turn the projector upside down. Turn in the indicated screw. Remove the feet on the bottom side of the projector Illustrations Image 1 Image 1 To be continued on next page. BARCO ——————————————————— 16 ————————————— Projection Systems...
  • Page 17 Bottom Cover Step Action Image Put the bottom cover back on its place. Turn in the 3 indicated fixing screws. Turn in the 3 feet. Turn the projector upside down. Illustrations Image 2 Image 1 BARCO ——————————————————— 17 ————————————— Projection Systems...
  • Page 18 Image 1 Image 2 Mounting the To mount the CSB module, follow the next procedure : CSB module Step Action Image Turn out both indicated screws. Pivote the module backwards. Illustrations Image 2 Image 1 BARCO ——————————————————— 18 ————————————— Projection Systems...
  • Page 19 If a SDI module on the backside of the PMP is mounted, connect first the I en O coax cable to this module. Put the PMP module on its place. Turn in the indicated screws. Illustrations Image 1 To be continued on next page. BARCO ——————————————————— 19 ————————————— Projection Systems...
  • Page 20: The Pmp

    Image 2 Removing the To remove the extra feet, follow the next procedure : extra Feet Step Action Image Turn out the feet on the indicated positions. 1 & 2 Illustrations Image 1 Image 2 BARCO ——————————————————— 20 ————————————— Projection Systems...
  • Page 21 Put the top cover on the projector Turn in the 3 fixing screws. Cover the fixing screws with the rubber sealing pieces. Illustrations on Top Cover Removal Image 1 Image 2 To be continued on next page. BARCO ——————————————————— 21 ————————————— Projection Systems...
  • Page 22 (only for a motorized lens). If not, turn the lens a little. While pushing down, tighten wing bolts (B) firmly to ensure good functioning of safety latches and motorization. Re-install the lens cover. Illustrations on Removing the Lens Image 1 Image 2 BARCO ——————————————————— 22 ————————————— Projection Systems...
