BARCO PROJECTION
U
L
6000
SERIES
NIVERSAL
AMP FOR
P
ROJECTORS
R9841550
I
N
NSTALLATION
OTE
18042002
R5976453/01

Advertisement

loading
Need help?

Need help?

Do you have a question about the R9841550 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Barco R9841550

  • Page 1 BARCO PROJECTION 6000 SERIES NIVERSAL AMP FOR ROJECTORS R9841550 NSTALLATION 18042002 R5976453/01...
  • Page 2 Barco nv Intelligent Displays Noordlaan 5, 8520 Kuurne Phone: +32 56.36.82.11 Fax: +32 56.35.86.51 E-mail: presentations.bid@barco.com Visit us at the web: www.barco.com Printed in Belgium...
  • Page 3: Safety Warnings

    Do not exceed the indicated maximum total lifetime of the lamp for safe operation in normal power mode. Do not use it longer ! Always replace the lamp with the BARCO lamp kit for 6500 projectors. R5976453 UNIVERSAL LAMP FOR 6000 SERIES PROJECTORS 18042002...
  • Page 4 1. Safety R5976453 UNIVERSAL LAMP FOR 6000 SERIES PROJECTORS 18042002...
  • Page 5: Lamp Specifications

    The mechanical design allows to shift the lamp unit by means of two adjustments, hereby insuring the best optical performances of the lamp in both projector configurations. The following procedures are intended for use only by qualified service technicians who have been trained and authorized by BARCO ! R5976453 UNIVERSAL LAMP FOR 6000 SERIES PROJECTORS 18042002...
  • Page 6 2. Introduction R5976453 UNIVERSAL LAMP FOR 6000 SERIES PROJECTORS 18042002...
  • Page 7 3. Access to the lamp unit 3. ACCESS TO THE LAMP UNIT 3.1 Removing the protection cover What has to be done ? • The lamp house door has to be opened and removed. • The lamp protection cover has to be removed. Make sure that the projector is turned off ! Never open the lamp house when the projector is on! Necessary tools flat screwdriver of 5 mm...
  • Page 8 3. Access to the lamp unit Image 3-2 How to remove the protection cover 1. Loosen with a screwdriver the 3 indicated bolts. (image 3-3) 2. Pivote the plate a little downwards. (image 3-4) 3. Take out the protection cover. Image 3-3 Image 3-4 Hot surface !
  • Page 9 4. Removing the lamp unit 4. REMOVING THE LAMP UNIT 4.1 Extracting the lamp unit Necessary tools No tools. How to remove the lamp unit ? 1. Slide the lamp unit backwards. (image 4-1) 2. Take the sides of the lamp connector between thumb and finger. 3.
  • Page 10 4. Removing the lamp unit R5976453 UNIVERSAL LAMP FOR 6000 SERIES PROJECTORS 18042002...
  • Page 11 5. Installing the lamp unit 5. INSTALLING THE LAMP UNIT 5.1 Installing What has to be done ? a) the lamp has to be adjusted according to the mounting configuration of the projector b) the lamp has to be placed in the projector housing and has to be connected Do not touch the front lamp glass with your fingers since this can reduce the light output of the lamp ! If the glass is touched, finger prints can be removed by cleaning the lamp with alcohol.
  • Page 12 5. Installing the lamp unit Image 5-4 Image 5-3 Switching from CM (Ceiling Mount) to TM (Table Mount) Image 5-5 Ceiling Mount configuration Table Mount configuration Placing and connecting the lamp 1. Place the lamp in the housing (as shown on the image). 2.
  • Page 13 5. Installing the lamp unit Image 5-7 reference holes R5976453 UNIVERSAL LAMP FOR 6000 SERIES PROJECTORS 18042002...
  • Page 14 5. Installing the lamp unit R5976453 UNIVERSAL LAMP FOR 6000 SERIES PROJECTORS 18042002...
  • Page 15 6. Closing the lamp house 6. CLOSING THE LAMP HOUSE 6.1 Mounting the covers Necessary tools flat screwdriver of 5 mm Mounting the protection cover 1. Put the protection cover on its place. (image 6-1) Warning: Warning : be careful for the lamp power cable. Do not stick this cable between the protection cover and the lamp house 2.
  • Page 16 6. Closing the lamp house Image 6-3 Image 6-4 R5976453 UNIVERSAL LAMP FOR 6000 SERIES PROJECTORS 18042002...
