Ametek Mocon Dansensor MAP Mix 9001 ME User Manual page 25

Dansensor MAP Mix 9001 ME
®
Inlet filter
Indicators for
Signal cable
Material
Ambient temperature Operational:
Weight/dimensions
EN
Models ≤ 400 liter/min.:
Models > 400 liter/min.:
Alarm monitoring on/off

Low pressure on " GAS IN", "
Alarm output active
Alarm output:
Flow control valve:
Stainless steel, IP 54
0 to +45°C, < 95% RH, non condensing
Storage: -10 to +60°C, < 95% RH, non condensing
(See illustration below)
Type
H x W x D [mm]
250/2
400/2
200/3
400/3
60 μm
500 μm
 
GAS IN" and "
N.O.+ N.C. + COM connection
Max. 48V / 1A
(Option)
Connection of 24 VDC
Weight [kg]
194 x 235 x 420
194 x 235 x 420
194 x 235 x 420
194 x 473 x 420
User Manual
GAS IN"
10,1
10,3
12,2
17,2
P/N 250151-P
10/2021
23
