Canon imagePROGRAF iPF8300S Basic Guide No.1 Basic Manual page 41

11
Pull the Printhead Fixer Cover down toward the front to
lock the Printhead in place.
12
Push the Printhead Fixer Lever toward the back of the
printer until it clicks.
13
Push the Carriage Cover down toward the front.
14
Close the Top Cover .
Ink now fi lls the system. It takes about 13 minutes for ink
to fi ll the system.
• Never remove an Ink Tank while the system is fi lling with ink.
• The procedure is now fi nished if you have set Rep.P.head Print to Off in the Control Panel menu.
If so, execute Head Posi. Adj. > Auto(Advanced) in the Control Panel menu.
(→
15
Follow the instructions on the Display Screen and supply
paper that you will use for printing. After the paper is
advanced, Head Posi. Adj. will be executed automatically.
(→ , If Vertical Lines are Warped or Colors are
Misaligned)
• When printing fi ne lines or text at high precision on glossy or semi-glossy photo or proofi ng paper, set
the optimal Printhead height before aligning the printhead.
(→"Enhancing Printing Quality," User's Guide)
, If Vertical Lines are Warped or Colors are Misaligned)
41
Replacing the Printhead
