Hardware A Cam Bolt (x31) B Cam Connector (x31) C Dowel (x28) D M7x50mm Bolt (x7) E Shelf Support (x12) F M6x25 Screw (x2) G Allen Key H M6x30 (x11) I M6x16 (x2) J Bent Hinge (x2) K Flat Hinge (x4) Note: This product includes two different types of hinges.
Page 5
ASSEMBLY Step 1: Attach the two legs (1) & (2) to the centre support (3) using the four M6x30 Screws (H). E Allen Key H M6x30 (x4)
Page 6
Step 2: Attach the centre leg (4) to the centre support (3) using the two M6x16 Screws (I). E Allen Key I M6x16 (x2)
Page 7
Step 3: Insert three Cam Bolts (A) into part (3) in the locations shown below. A Cam Bolt (x3)
Page 8
Step 4: • Insert three Cam Connectors (B) into all the holes adjacent to the corresponding Cam Bolts. Note: Ensure the arrow on the Cam Connector (B) is facing the direction of the hole. • Attach parts (3) & (7) together by screwing the Cam Connectors (B) clockwise. B Cam Connector (x3)
Page 9
Step 5: Insert eight Cam Bolts (A) and eight Dowels (C) into parts (2) & (3) in the locations shown below. A Cam Bolt (x8) C Dowel (x8)
Page 10
Step 6: • Insert eight Cam Connectors (B) into all the holes adjacent to the corresponding Cam Bolts. Note: Ensure the arrow on the Cam Connector (B) is facing the direction of the hole. • Attach parts (2), (3), (4) & (5) together by screwing the Cam Connectors (B) clockwise. B Cam Connector (x8)
Page 11
Step 6: Insert 12 Cam Bolts (A) and 12 Dowels (C) into parts (1L) & (1R) in the locations shown below. A Cam Bolt (x12) C Dowel (x12)
Page 12
Step 7: • Insert 12 Cam Connectors (B) into all the holes adjacent to the corresponding Cam Bolts. Note: Ensure the arrow on the Cam Connector (B) is facing the direction of the hole. • Attach parts (1L), (1R), (6) & (8) to the assembled frame by screwing the Cam Connectors (B) clockwise.
Page 13
Step 8: • Secure the two Flat Hinges (K) to parts (11) & (13) using the included hinge fasteners. IMPORTANT: Ensure only the Flat Hinges (K) are used in this step. The Bent Hinges (J) will not fit. • Repeat with parts (12) and (14). K Flat Hinge (x4)
Page 14
Step 9: • Insert eight Cam Bolts (A) and eight Dowels (C) into parts (11) & (12) in the locations shown below. • Insert eight Cam Connectors (B) into all the holes adjacent to the corresponding Cam Bolt (A). Note: Ensure the arrow on the Cam Connector (B) is facing the direction of the hole. •...
Page 15
Step 10: Secure the legs to the underside of the sideboard using the seven M6x30 Hex Screws (H). H M6x30mm Hex Screw (x7)
Page 16
Step 11: • Insert the 12 Shelf Supports (E) in the locations shown below. • Place the three shelves, parts (9) & (10) inside the sideboard in the locations shown below. E Shelf Support (x12)
Page 17
Step 12: Secure the legs in place using the two M6x25 Screws (F) from inside the bedside table. F M6x25 Screw (x2)
Page 18
Step 13: Insert the seven M7x50 Screws (D) in the rear of the sideboard. D M7x50mm Screw (x7)
Page 19
Step 14: Secure part (13) to the sideboard assembly using the two Bent Hinges (J) and the included hinge fasteners. J Bent Hinges (x2)
Page 20
