- Page 1 Industrial LoRaWAN Gateway LCG-300 series Industrial LoRaWAN Gateway LCG-300 Series - 1 -...
- Page 2 Information in this User’s Manual is subject to change without notice and does not represent a commitment on the part of PLANET. PLANET assumes no responsibility for any inaccuracies that may be contained in this User’s Manual.
- Page 3 WEEE separately. Trademarks The PLANET logo is a trademark of PLANET Technology. This documentation may refer to numerous hardware and software products by their trade names. In most, if not all cases, these designations are claimed as trademarks or registered trademarks by their respective companies.
-
Page 4: Table Of Contents
Hardware Installation ....................19 Chapter 3. Preparation ......................22 Requirements ......................22 Setting TCP/IP on your PC ..................23 Planet Smart Discovery Utility .................. 30 Chapter 4. Web-based Management .................. 32 Introduction ......................32 Logging in to the LoRaWAN Gateway ..............32 Main Web Page ...................... - Page 5 Industrial LoRaWAN Gateway LCG-300 series 4.5.5 Routing ....................63 4.5.6 WAN IPv6 Setting .................. 65 4.5.7 DHCP ..................... 65 4.5.8 DDNS ..................... 67 4.5.9 MAC Address Clone ................69 LoRa 70 4.6.1 LoRa ...................... 71 4.6.2 LoRaWAN ....................72 4.6.3 ABP Decryption..................
- Page 6 Industrial LoRaWAN Gateway LCG-300 series Appendix A: DDNS Application .................... 111 - 6 -...
-
Page 7: Chapter 1. Product Introduction
Industrial LoRaWAN Gateway LCG-300 series Chapter 1. Product Introduction Thank you for purchasing PLANET Industrial LoRaWAN Gateway, LCG-300 Series. The descriptions of these models are as follows: LCG-300 Industrial LoRaWAN Gateway with 5-Port 10/100/1000T LCG-300W Industrial LoRaWAN Wireless Gateway with 5-Port 10/100/1000T “LoRaWAN Gateway”... -
Page 8: Package Contents
The package should contain the following: Industrial LoRaWAN Gateway x 1 Quick installation guide x 1 PLANET CloudViewer QIG x1 Wall-mount plate w/screw x 1 set RJ45 dust cap x 6 LoRa antenna x 1 ... -
Page 9: Overview
The LCG-300 series is fully compatible with LoRaWAN protocol and supports connection with up to 300 end-nodes. It also provides pre-configured standard LoRaWAN frequency bands for different countries. PLANET LCG-300 series is a best choice to help you to promote the implementation of AIoT network. - Page 10 Industrial LoRaWAN Gateway LCG-300 series Excellent Ability in Threat Defense The LCG-300 has built-in SPI (stateful packet inspection) firewall and DoS/DDoS attack mitigation functions to provide high efficiency and extensive protection for your network. Thus, virtual server and DMZ functions can let you set up servers in the Intranet and still provide services to the Internet users.
-
Page 11: Features
• Stateful packet inspection (SPI) firewall and content filtering • Blocks DoS/DDOS attack, port range forwarding • Planet NMS controller system and CloudViewer app supported • -45 to 75 degrees C operating temperature; DIN-rail and fanless designs Hardware • 4 x 10/100/1000BASE-T RJ45 LAN ports, auto-negotiation, auto MDI/MDI-X •... - Page 12 • Setup wizard • Dashboard for real-time system overview • Supported access by HTTP or HTTPS • Auto reboot • PLANET NMS System and Smart Discovery Utility for deployment management • Planet CloudViewer app for real-time monitoring - 12 -...
-
Page 13: Product Specifications
Industrial LoRaWAN Gateway LCG-300 series 1.4 Product Specifications Models LCG-300W LCG-300 Hardware Specifications 5 10/100/1000BASE-T RJ45 Ethernet ports including 3 LAN ports (Ports 1 to 3) Copper Ports 1 LAN/WAN port (Port 4) 1 WAN port (Port 5) Serial Interface... - Page 14 Industrial LoRaWAN Gateway LCG-300 series LoRaWAN Frequency Band EU version: 863~870MHZ US version: 902~928MH IN865/EU868/RU864/US915/AU915/KR920/AS923 Receiving -142.5dBm Sensitivity Output Power 27dBm Max. Wireless IEEE 802.11a/n/ac/ax 5GHz Standard IEEE 802.11g/b/n/ax 2.4GHz Band Mode 2.4G & 5G concurrent mode America FCC: 2.412~2.462GHz 2.4GHz...
- Page 15 DES, 3DES, AES or AES-128/192/256 encrypting Authentication MD5/SHA-1/SHA-256/SHA-384/SHA-512 authentication algorithm Methods Management Basic Management Web browser Interfaces SNMP v1, v2c PLANET Smart Discovery utility and NMS controller supported Secure Management SSHv2, TLSv1.2, SNMP v3 Interfaces System Log System Event Log - 15 -...
- Page 16 Industrial LoRaWAN Gateway LCG-300 series Others Setup wizard Dashboard System status/service Statistics Connection status Auto reboot Diagnostics Standards Conformance Regulatory CE, FCC Compliance Environment Temperature: -40 ~ 75 degrees C Operating Relative humidity: 5 ~ 90% (non-condensing) Temperature: -40 ~ 85 degrees C...
-
Page 17: Chapter 2. Hardware Introduction
Industrial LoRaWAN Gateway LCG-300 series Chapter 2. Hardware Introduction 2.1 Physical Descriptions Front View - 17 -... - Page 18 Industrial LoRaWAN Gateway LCG-300 series LED Definition: System Color Function Green Lights to indicate DC power input 1 has power. Green Lights to indicate DC power input 2 has power. Alarm Lights to indicate that power or port has failed.
-
Page 19: Hardware Installation
Industrial LoRaWAN Gateway LCG-300 series 2.2 Hardware Installation Refer to the illustration and follow the simple steps below to quickly install your LoRaWAN Gateway. 2.2.1 LoRa Antenna Installation Step 1: Connect LoRa antennas to the LoRa antenna extension. Step 2: Fasten the LoRa antenna extensions to the connectors. - Page 20 Industrial LoRaWAN Gateway LCG-300 series 3.4 Wiring the Power Inputs The 6-contact terminal block connector on the top panel of LoRaWAN Gateway is used for two DC redundant power inputs. Please follow the steps below to insert the power wire.
- Page 21 Industrial LoRaWAN Gateway LCG-300 series The wire gauge for the terminal block should be in the range between 12 and 24 AWG. PWR1 and PWR2 must provide the same DC voltage while CAUTION operating with dual power input. 3.5 Grounding the Device User MUST complete grounding wired with the device;...
-
Page 22: Chapter 3. Preparation
Industrial LoRaWAN Gateway LCG-300 series Chapter 3. Preparation Before getting into the device’s web UI, user has to check the network setting and configure PC’s IP address. 3.1 Requirements User is able to confirm the following items before configuration: 1. Please confirm the network is working properly; it is strongly suggested to test your network connection by connecting your computer directly to ISP. -
Page 23: Setting Tcp/Ip On Your Pc
Industrial LoRaWAN Gateway LCG-300 series 3.2 Setting TCP/IP on your PC The default IP address of the LoRaWAN Gateway is 192.168.1.1, and the DHCP Server is on. Please set the IP address of the connected PC as DHCP client, and the PC will get IP address automatically from the VPN LoRaWAN Gateway Please refer to the following to set the IP address of the connected PC. - Page 24 Industrial LoRaWAN Gateway LCG-300 series 2. Click "Change adapter settings". 3. Right-click on the Local Area Connection and select Properties. - 24 -...
- Page 25 Industrial LoRaWAN Gateway LCG-300 series 4. Select Internet Protocol Version 4 (TCP/IPv4) and click Properties or directly double-click on Internet Protocol Version 4 (TCP/IPv4). - 25 -...
- Page 26 Industrial LoRaWAN Gateway LCG-300 series 5. Select "Use the following IP address" and "Obtain DNS server address automatically", and then click the “OK” button. - 26 -...
- Page 27 Industrial LoRaWAN Gateway LCG-300 series Windows 10 If you are using Windows 10, please refer to the following: 1. In the search box on the taskbar, type “View network connections”, and then select View network connections at the top of the list.
- Page 28 Industrial LoRaWAN Gateway LCG-300 series 2. Right-click on the Local Area Connection and select Properties. 3. Select Internet Protocol Version 4 (TCP/IPv4) and click Properties or directly double-click on Internet Protocol Version 4 (TCP/IPv4). - 28 -...
- Page 29 Industrial LoRaWAN Gateway LCG-300 series 4. Select "Use the following IP address" and "Obtain DNS server address automatically", and then click the “OK” button. - 29 -...
-
Page 30: Planet Smart Discovery Utility
LCG-300 series 3.3 Planet Smart Discovery Utility For easily listing the LoRaWAN Gateway in your Ethernet environment, the search tool -- Planet Smart Discovery Utility -- is an ideal solution. The following installation instructions are to guide you to running the Planet Smart Discovery Utility. - Page 31 3. To click the “Control Packet Force Broadcast” function, it allows you to assign a new setting value to the device under a different IP subnet address. 4. Press the “Connect to Device” button and the Web login screen appears. Press the “Exit” button to shut down the Planet Smart Discovery Utility. - 31 -...
-
Page 32: Chapter 4. Web-Based Management
Industrial LoRaWAN Gateway LCG-300 series Chapter 4. Web-based Management This chapter provides setup details of the device’s Web-based Interface. 4.1 Introduction The device can be configured with your Web browser. Before configuring, please make sure your PC is under the same IP segment with the device. -
Page 33: Main Web Page
Industrial LoRaWAN Gateway LCG-300 series 4.3 Main Web Page After a successful login, the main web page appears. The web main page displays the web panel, main menu, function menu, and the main information in the center. Web Panel Main Menu... - Page 34 Industrial LoRaWAN Gateway LCG-300 series ■ Main Menu The main menu displays the product name, function menu, and main information in the center. Via the Web management, the administrator can set up the device by selecting the functions those listed in the...
-
Page 35: System
Industrial LoRaWAN Gateway LCG-300 series 4.4 System Use the System menu items to display and configure basic administrative details of the LoRaWAN Gateway The System menu shown in Figure 4-4-1 provides the following features to configure and monitor system. Figure 4-4-1: System Menu... - Page 36 Industrial LoRaWAN Gateway LCG-300 series Fault Alarm Configure fault alarm on LoRaWAN Gateway Digital Input/Output Configure digital input and output on LoRaWAN Gateway Configure Modbus on LoRaWAN Gateway Modbus Remote Syslog Enable Captive Portal on LoRaWAN Gateway Event Log Display Event Log information...
-
Page 37: Setup Wizard
Industrial LoRaWAN Gateway LCG-300 series 4.4.1 Setup Wizard The Wizard will guide the user to configuring the LoRaWAN Gateway easily and quickly. There are different procedures in different operation modes. According to the operation mode you switch to, please follow the instructions below to configure the LoRaWAN Gateway via Setup Wizard as shown in Figure 4-4-2. - Page 38 Industrial LoRaWAN Gateway LCG-300 series Figure 4-4-4: Setup Wizard – LAN Configuration Object Description IP Address Enter the IP address of your LoRaWAN Gateway The default is 192.168.1.1. Subnet Mask An address code that determines the size of the network. Normally use 255.255.255.0 as the subnet mask.
- Page 39 Industrial LoRaWAN Gateway LCG-300 series Step 3: WAN Interface The LoRaWAN Gateway supports two access modes on the WAN side shown in Figure 4-4-5 Figure 4-4-6 Figure 4-4-5: Setup Wizard – WAN 1 Configuration Figure 4-4-6: Setup Wizard – WAN Configuration Mode 1 -- Static IP Select Static IP Address if all the Internet port’s IP information is provided to you by your ISP.
- Page 40 Industrial LoRaWAN Gateway LCG-300 series Figure 4-4-7: WAN Interface Setup – Static IP Setup Object Description IP Address Enter the IP address assigned by your ISP. Netmask Enter the Netmask assigned by your ISP. Enter the Gateway assigned by your ISP.
- Page 41 Industrial LoRaWAN Gateway LCG-300 series Figure 4-4-8: WAN Interface Setup – DHCP Setup Step 5: Security Setting Set up the Wireless Settings as shown in Figure 4-4-9. Figure 4-4-9: Setup Wizard –Security Setting Object Description The SPI Firewall prevents attack and improper access to network SPI Firewall resources.
- Page 42 Industrial LoRaWAN Gateway LCG-300 series ICMP is kind of a pack of TCP/IP; its important function is to transfer simple signal on the Internet. There are two normal attack ways Block ICMP Flood which hackers like to use, Ping of Death and Smurf attack.
- Page 43 Industrial LoRaWAN Gateway LCG-300 series Step 6: Setup Completed The page will show the summary of LAN, WAN and Security settings as shown in Figure 4-4-11. Figure 4-4-11: Setup Wizard –Setup Completed Object Description Finish Press this button to save and apply changes.
-
Page 44: Dashboard
Industrial LoRaWAN Gateway LCG-300 series 4.4.2 Dashboard The dashboard provides an overview of system information including connection, port, and system status as shown in Figure 4-4-12. Figure 4-4-12: Dashboard - 44 -... - Page 45 Industrial LoRaWAN Gateway LCG-300 series WAN/LAN Connection Status Object Description The status means WAN is connected to Internet and LAN is connected. The status means WAN is disconnected to Internet and LAN is connected. The status means WAN is connected to Internet and LAN is disconnected.
-
Page 46: System Status
Industrial LoRaWAN Gateway LCG-300 series 4.4.3 System Status This page displays system status information as shown in Figure 4-4-13. Figure 4-4-13: System Status - 46 -... -
Page 47: System Service
Industrial LoRaWAN Gateway LCG-300 series 4.4.4 System Service This page displays system service information as shown in Figure 4-4-14. Figure 4-4-14: System Service - 47 -... -
Page 48: Statistics
Industrial LoRaWAN Gateway LCG-300 series 4.4.5 Statistics This page displays the number of packets that pass through the LoRaWAN Gateway on the WAN and LAN. The statistics are shown in Figure 4-4-15. Figure 4-4-15: Statistics - 48 -... -
Page 49: Connection Status
Industrial LoRaWAN Gateway LCG-300 series 4.4.6 Connection Status The page will show the DHCP Table and ARP Table. The status is shown in Figure 4-4-16. Figure 4-4-16: Connection Status - 49 -... -
Page 50: Snmp
Industrial LoRaWAN Gateway LCG-300 series 4.4.7 SNMP This page provides SNMP setting as shown in Figure 4-4-21. Figure 4-4-21: SNMP Object Description Enable SNMP Disable or enable the SNMP function. The default configuration is enabled. Read/Write Community Allows entering characters for SNMP Read/Write Community of the... -
Page 51: Nms
LCG-300 series 4.4.8 NMS The LCG-300 series can support both NMS controller and CloudViewer Sever for remote management. PLANET's NMS Controller is a Network Management System that can monitor all kinds of deployed network devices, such as managed switches, media converters, routers, smart APs, VoIP phones, IP cameras, etc., compliant with the SNMP Protocol, ONVIF Protocol and PLANET Smart Discovery utility. - Page 52 Industrial LoRaWAN Gateway LCG-300 series The CloudViewer Server – Internet configuration – is shown in Figure 4-4-24. Figure 4-4-24 CloudViewer Server – Internet Configuration Page Object Description • Email The email registered on CloudViewer Server • The password of your CloudViewer account Password •...
-
Page 53: Fault Alarm
Industrial LoRaWAN Gateway LCG-300 series 4.4.9 Fault Alarm This page provides fault alarm setting as shown in Figure 4-4-25. Figure 4-4-25: Fault Alarm Object Description • Enable Controls whether Fault Alarm is enabled. • Record Controls whether Record is sending System log or SMS. -
Page 54: Digital Input / Output
Industrial LoRaWAN Gateway LCG-300 series 4.4.10 Digital Input / Output This page provides Digital Input / Output setting as shown in Figure 4-4-26. Figure 4-4-26: Digital Input / Output Object Description • Check the Enable checkbox to enable Digital Input / output function. - Page 55 Industrial LoRaWAN Gateway LCG-300 series Allows user to monitor an alarm from port failure, power failure, Digital Input 0 (DI 0) and Digital Input 1(DI 1) which means if Digital Output has detected these events, then Digitial Output would be triggered according to the setting of Condition.
-
Page 56: Modbus
Industrial LoRaWAN Gateway LCG-300 series 4.4.11 Modbus This page provides Modbus setting as shown in Figure 4-4-27. Figure 4-4-27: Modbus Object Description • Enable Enable/disable Modbus function. The industrial device server supports three interfaces. • Serial device • Baudrate The rate of data transmission to and from the attached serial device. -
Page 57: Remote Syslog
Industrial LoRaWAN Gateway LCG-300 series 4.4.12 Remote Syslog This page provides remote syslog setting as shown in Figure 4-4-28. Figure 4-4-28: Remote Syslog Object Description • Enable Controls whether remote syslog is enabled • Syslog Server IP Indicates the IPv4 host address of syslog server •... -
Page 58: Network
Industrial LoRaWAN Gateway LCG-300 series 4.5 Network The Network function provides WAN, LAN and network configurations of the LoRaWAN Gateway as shown in Figure 4-5-1. Figure 4-5-1: Network Menu Object Description Allows setting WAN interface. WAN Advanced Allows setting WAN Advanced settings. -
Page 59: Wan
IGMP The default configuration is disabled. IPv6 Allows setting IPv6 WAN interface. Allows setting DHCP Server. DHCP Allows setting DDNS and PLANET DDNS. DDNS MAC Address Allows setting WAN MAC Address Clone. Clone 4.5.1 WAN This page is used to configure the parameters for Internet network which connects to the WAN port of... - Page 60 Industrial LoRaWAN Gateway LCG-300 series Object Description Please select the corresponding WAN Access Type for the Internet, and fill out the correct parameters from your local ISP in the fields which appear below. Select Static IP Address if all the Internet ports’ IP information is provided to you by your ISP (Internet Service Provider).
-
Page 61: Wan Advanced
Industrial LoRaWAN Gateway LCG-300 series 4.5.2 WAN Advanced This page is used to configure the advanced parameters for Internet area network which connects to the WAN port of your LoRaWAN Gateway as shown in Figure 4-5-3. Here you may change the setting for Load Balance Weight, Detect Interval, Detect Link Up Threshold, etc. -
Page 62: Lan Setup
Industrial LoRaWAN Gateway LCG-300 series 4.5.3 LAN Setup This page is used to configure the parameters for local area network which connects to the LAN port of your LoRaWAN Gateway as shown in Figure 4-5-4. Here you may change the settings for IP address, subnet mask, DHCP, etc. -
Page 63: Multi-Subnet
Industrial LoRaWAN Gateway LCG-300 series 4.5.4 Multi-Subnet This page provides multi-subnet setting as shown in Figure 4-5-5. Figure 4-5-5: Multi-Subnet 4.5.5 Routing Please refer to the following sections for the details as shown in Figures 4-5-6 and 4-5-7. Figure 4-5-6: Routing table... - Page 64 Industrial LoRaWAN Gateway LCG-300 series Figure 4-5-7: Routing setup Routing tables contain a list of IP addresses. Each IP address identifies a remote LoRaWAN Gateway (or other network gateway) that the local LoRaWAN Gateway is configured to recognize. For each IP address, the routing table additionally stores a network mask and other data that specifies the destination IP address ranges that remote device will accept.
-
Page 65: Wan Ipv6 Setting
Industrial LoRaWAN Gateway LCG-300 series 4.5.6 WAN IPv6 Setting This page is used to configure parameter for IPv6 internet network which connects to WAN port of the LoRaWAN Gateway as shown in Figure 4-5-8. It allows you to enable IPv6 function and set up the parameters of the LoRaWAN Gateway’s WAN. - Page 66 Industrial LoRaWAN Gateway LCG-300 series Figure 4-5-9: DHCP Object Description By default, the DHCP Server is enabled, meaning the LoRaWAN Gateway will assign IP addresses to the DHCP clients DHCP Service automatically. If user needs to disable the function, please set it as disable.
-
Page 67: Ddns
PLANET Easy DDNS PLANET Easy DDNS is an easy way to help user to get your Domain Name with just one click. You can just log in to the Web Management Interface of your devices, say, your LoRaWAN Gateway, and check the DDNS menu and just enable it. - Page 68 Note that please first register with the DDNS service and set up the domain name of your choice to begin using it. When the PLANET DDNS service is activated, user is able to select to enable or disable Easy DDNS.
-
Page 69: Mac Address Clone
Industrial LoRaWAN Gateway LCG-300 series 4.5.9 MAC Address Clone Clone or change the MAC address of the WAN interface. The setup is shown in Figure 4-5-11. Figure 4-5-11: MAC Address Clone Object Description Clone WAN MAC Set the function as enable or disable. -
Page 70: Lora
Industrial LoRaWAN Gateway LCG-300 series 4.6 LoRa The LoRa menu provides LoRa functions as shown in Figure 4-6-1. Please refer to the following sections for the details. Figure 4-6-1: Cellular menu Object Description Allows setting LoRa configuration. LoRa LoRaWAN Allows setting LoRaWAN configuration. -
Page 71: Lora
Industrial LoRaWAN Gateway LCG-300 series 4.6.1 LoRa This page provides LoRa configuration as shown in Figure 4-6-2. Figure 4-6-2: LoRa configuration Object Description After the configured length of time, the Gateway will issue a Pull request to the specified IP address to confirm its connection is still Keep Alive Period (sec) active. -
Page 72: Lorawan
Industrial LoRaWAN Gateway LCG-300 series 4.6.2 LoRaWAN This page provides LoRaWAN configuration as shown in Figure 4-6-3. Figure 4-6-3: LTE/NR advanced Object Description The service of LoRaWAN LoRaWAN Server Mode Email The registered email of LoRaWAN server Gateway ID The unique identity of the base station, which the server can... -
Page 73: Abp Decryption
Industrial LoRaWAN Gateway LCG-300 series 4.6.3 ABP Decryption This page provides ABP Decryption configuration as shown in Figure 4-6-4. Figure 4-6-4: ABP Decryption Object Description The number of ABP Decryption devices Dev ADDR The Dev ADDR of devices APP Session Key... -
Page 74: Mqtt
Industrial LoRaWAN Gateway LCG-300 series 4.6.4 MQTT This page provides MQTT Client Configuration as shown in Figure 4-6-5. Figure 4-6-5: MQTT Client Configuration Object Description Enable or disable MQTT service Enable Quality of Service The level of quality of service... -
Page 75: Lora Log
Industrial LoRaWAN Gateway LCG-300 series 4.6.5 LoRa Log This page shows the frequency for LoRa Radio and traffics in Figure 4-6-6. Figure 4-6-6: LoRa Radio and traffics - 75 -... -
Page 76: Security
Industrial LoRaWAN Gateway LCG-300 series 4.7 Security The Security menu provides Firewall, Access Filtering and other functions as shown in Figure 4-7-1. Please refer to the following sections for the details. Figure 4-7-1: Security menu Object Description Allows setting DoS (Denial of Service) protection as enable. -
Page 77: Firewall
Industrial LoRaWAN Gateway LCG-300 series 4.7.1 Firewall A "Denial-of-Service" (DoS) attack is characterized by an explicit attempt by hackers to prevent legitimate users of a service from using that service. The LoRaWAN Gateway can prevent specific DoS attacks as shown in Figure 4-7-2. - Page 78 Industrial LoRaWAN Gateway LCG-300 series ICMP is kind of a pack of TCP/IP; its important function is to transfer simple signal on the Internet. There are two normal attack ways Block ICMP Flood which hackers like to use, Ping of Death and Smurf attack.
-
Page 79: Mac Filtering
Industrial LoRaWAN Gateway LCG-300 series 4.7.2 MAC Filtering Entries in this table are used to restrict certain types of data packets from your local network or Internet through the LoRaWAN Gateway Use of such filters can be helpful in securing or restricting your local... -
Page 80: Ip Filtering
Industrial LoRaWAN Gateway LCG-300 series 4.7.3 IP Filtering IP Filtering is used to deny LAN users from accessing the public IP address on internet as shown in Figure 4-7-4. To begin blocking access to an IP address, enable IP Filtering and enter the IP address of the web site you wish to block. - Page 81 Industrial LoRaWAN Gateway LCG-300 series Object Description Anywhere (of destination Check the box if you want to control all web sites, meaning the LAN IP Address) user can’t visit any web site. Input the port of destination IP Address which you want to block.
-
Page 82: Web Filtering
Industrial LoRaWAN Gateway LCG-300 series 4.7.4 Web Filtering Web filtering is used to deny LAN users from accessing the internet as shown in Figure 4-7-6. Block those URLs which contain keywords listed below. Figure 4-7-6: Web Filtering Object Description Web Filtering Set the function as enable or disable. -
Page 83: Port Forwarding
Industrial LoRaWAN Gateway LCG-300 series 4.7.5 Port Forwarding Entries in this table allow you to automatically redirect common network services to a specific machine behind the NAT firewall as shown in Figure 4-7-8. These settings are only necessary if you wish to host some sort of server like a web server or mail server on the private local network behind your LoRaWAN Gateway's NAT firewall. -
Page 84: Dmz
Industrial LoRaWAN Gateway LCG-300 series Object Description Virtual Server IP Address Enter the local IP address. Enter local ports you want to control. For TCP and UDP Services, enter the beginning of the range of port numbers used by the Internal Service Port service. -
Page 85: Virtual Private Network
Industrial LoRaWAN Gateway LCG-300 series 4.8 Virtual Private Network To obtain a private and secure network link, the LoRaWAN Gateway is capable of establishing VPN connections. When used in combination with remote client authentication, it links the business’ remote sites and users, conveniently providing the enterprise with an encrypted network communication method. -
Page 86: Ipsec
Industrial LoRaWAN Gateway LCG-300 series 4.8.1 IPSec IPSec (IP Security) is a generic standardized VPN solution. IPSec must be implemented in the IP stack which is part of the kernel. Since IPSec is a standardized protocol it is compatible to most vendors that implement IPSec. - Page 87 Industrial LoRaWAN Gateway LCG-300 series Figure 4-8-3: IPSec Tunnel Object Description IPSec Tunnel Enable Check the box to enable the function. Tunnel Name Enter any words for recognition. This is only available for host-to-host connections and specifies to which interface the host is connecting.
- Page 88 Industrial LoRaWAN Gateway LCG-300 series Input the IP address of the remote host. For instance, "210.66.1.10”. Remote IP Address Remote Network The remote subnet in CIDR notation. For instance, "210.66.1.0”. Remote Netmask The netmask of the remote host. Set up the detection time of DPD (Dead Peer Detection).
-
Page 89: Gre
Industrial LoRaWAN Gateway LCG-300 series by using it three times. It can achieve an algorithm up to 168 bits. SHA1: The SHA1 is a revision of SHA. It has improved the shortcomings of SHA. By producing summary hash values, it can achieve an algorithm up to 160 bits. - Page 90 Industrial LoRaWAN Gateway LCG-300 series Figure 4-8-5: GRE Tunnel Object Description Check the box to enable the function. Active Enter any words for recognition. Tunnel Name This is only available for host-to-host connections and specifies to which interface the host is connecting.
-
Page 91: Pptp Server
Industrial LoRaWAN Gateway LCG-300 series 4.8.3 PPTP Server Use the IP address and the scope option needs to match the far end of the PPTP server; its goal is to use the PPTP channel technology, and establish Site-to-Site VPN where the channel can have equally good results from different methods with IPSec. - Page 92 Industrial LoRaWAN Gateway LCG-300 series When the PPTP client connects to the PPTP server, it will assign the DNS server IP address to client. When the PPTP client connects to the PPTP server, it will assign the WINS WINS server IP address to client.
-
Page 93: L2Tp Server
Industrial LoRaWAN Gateway LCG-300 series 4.8.4 L2TP Server This section assists you in setting the L2TP Server as shown in Figure 4-8-7. Figure 4-8-7: L2TP Server Object Description L2TP Server Set the function as enable or disable. Server IP Address Input the IP address of the L2TP Server. - Page 94 Industrial LoRaWAN Gateway LCG-300 series Object Description Preshare Key Enter a pass phrase. User and Password Create the username and password for the VPN client. Main. Connection Type Aggressive. It provides the way to create the SA between two PCs. The SA can access the encoding between two PCs, and the IT administrator can assign to which key size or Preshare Key and algorithm to use.
-
Page 95: Ssl Vpn
Industrial LoRaWAN Gateway LCG-300 series 4.8.5 SSL VPN This section assists you in setting the SSL Server as shown in Figure 4-8-8. Figure 4-8-8: SSL Server Object Description Set the function as enable or disable. SSL VPN Server Set a port for the SSL Service. Default port is 1194. -
Page 96: Vpn Connection
Industrial LoRaWAN Gateway LCG-300 series 4.8.6 VPN Connection This page shows the VPN connection status as shown in Figure 4-8-9. Figure 4-8-9: VPN Connection Status Object Description Click the IPSec/GRE/…/SSL VPN bookmark to check the current VPN Connection connection status. -
Page 97: Wireless
Industrial LoRaWAN Gateway LCG-300 series 4.9 Wireless The Wireless menu provides the following features as shown in Figure 4-10-1 Figure 4-9-1: Wireless Menu Object Description 2.4G Wi-Fi Allow to configure 2.4G Wi-Fi. 5G Wi-Fi Allow to configure 5G Wi-Fi. MAC ACL Allow configure MAC ACL. -
Page 98: G Wi-Fi
Industrial LoRaWAN Gateway LCG-300 series 4.9.1 2.4G Wi-Fi This page allows the user to define 2.4G Wi-Fi as shown in Figure 4-10-2. Figure 4-10-2: 2.4G WFI Object Description Wireless Status Allows user to enable or disable 2.4G WiFi Wireless Name (SSID) It is the wireless network name. -
Page 99: Wi-Fi
Industrial LoRaWAN Gateway LCG-300 series 4.9.2 5G Wi-Fi This page allows the user to define 5G Wi-Fi as shown in Figure 4-10-3. Figure 4-10-3: 5G WFI Object Description Wireless Status Allows user to enable or disable 5G Wi-Fi Wireless Name (SSID) It is the wireless network name. -
Page 100: Mac Acl
Industrial LoRaWAN Gateway LCG-300 series 4.9.3 MAC ACL This page provides MAC ACL configuration as shown in Figure 4-10-4. Figure 4-10-4: MAC ACL Object Description Active Allows the devices to pass in the rule Device Name Set an allowed device name... -
Page 101: Wi-Fi Advanced
Industrial LoRaWAN Gateway LCG-300 series 4.9.4 Wi-Fi Advanced This page allows the user to define advanced setting of Wi-Fi as shown in Figure 4-10-5. Figure 4-10-5: Wi-Fi advanced Object Description 2.4G Mode 11AC: Select 802.11B/G or 802.11N/G 11AX: Select 802.11B/G or 802.11N/G or 802.11AX 5G Mode 11AC: Select 802.11A or 802.11AN or 802.11AC... -
Page 102: Wi-Fi Statistics
Industrial LoRaWAN Gateway LCG-300 series 4.9.5 Wi-Fi Statistics This page displays Wi-Fi statistics as shown in Figure 4-10-6. Figure 4-10-6: Wi-Fi statistics - 102 -... -
Page 103: Connection Status
Industrial LoRaWAN Gateway LCG-300 series 4.9.6 Connection Status This page shows the host names and MAC address of all the clients in your network as shown in Figure 4-10-7. Figure 4-10-7: Connection status Object Description Name Display the host name of connected clients. -
Page 104: Maintenance
Industrial LoRaWAN Gateway LCG-300 series 4.10 Maintenance The Maintenance menu provides the following features for managing the system as shown in Figure 4-11-1 Figure 4-11-1: Maintenance Menu Object Description Allows changing the login username and password. Administrator Allows setting Date & Time function. -
Page 105: Administrator
Industrial LoRaWAN Gateway LCG-300 series 4.10.1 Administrator To ensure the LoRaWAN Gateway's security is secure, you will be asked for your password when you access the LoRaWAN Gateway's Web-based utility. The default user name and password are "admin". This page will allow you to modify the user name and passwords as shown in Figure 4-11-2. -
Page 106: Date And Time
Industrial LoRaWAN Gateway LCG-300 series 4.10.2 Date and Time This section assists you in setting the system time of the LoRaWAN Gateway. You are able to either select to set the time and date manually or automatically obtain the GMT time from Internet as shown in Figure 4-11-3. -
Page 107: Saving/Restoring Configuration
Industrial LoRaWAN Gateway LCG-300 series 4.10.3 Saving/Restoring Configuration This page shows the status of the configuration. You may save the setting file to either USB storage or PC and load the setting file from USB storage or PC as Figure 4-11-4... -
Page 108: Upgrading Firmware
Industrial LoRaWAN Gateway LCG-300 series Object Description press the button first. 4.10.4 Upgrading Firmware This page provides the firmware upgrade function as shown in Figure 4-11-5 Figure 4-11-5: firmware upgrade page Object Description Choose File Press the button to select the firmware. -
Page 109: Reboot / Reset
Industrial LoRaWAN Gateway LCG-300 series 4.10.5 Reboot / Reset This page enables the device to be rebooted from a remote location. Once the Reboot button is pressed, users have to re-log in the Web interface as Figure 4-11-6 is shown below:... -
Page 110: Diagnostics
Industrial LoRaWAN Gateway LCG-300 series 4.10.6 Diagnostics The page allows you to issue ICMP PING packets to troubleshoot IP connectivity issues. After you press “Ping”, ICMP packets are transmitted, and the sequence number and roundtrip time are displayed upon reception of a reply. The Page refreshes automatically until responses to all packets are... - Page 111 Industrial LoRaWAN Gateway LCG-300 series Appendix A: DDNS Application Configuring PLANET DDNS steps: Step 1: Visit DDNS provider’s web site and register an account if you do not have one yet. For example, register an account at http://planetddns.com Step 2: Enable DDNS option through accessing web page of the device.
