Planet VIP-1680 Series User Manual

2-24 port h.323/sip voip gateway
Hide thumbs Also See for VIP-1680 Series:
Table of Contents

Advertisement

Quick Links

2~24-Port H.323/SIP VoIP Gateway
VIP-281/480/880/1680/2480 series
User's manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VIP-1680 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Planet VIP-1680 Series

Summary of Contents for Planet VIP-1680 Series

  • Page 1 2~24-Port H.323/SIP VoIP Gateway VIP-281/480/880/1680/2480 series User’s manual...
  • Page 2 Copyright Copyright (C) 2007 PLANET Technology Corp. All rights reserved. The products and programs described in this User’s Manual are licensed products of PLANET Technology, This User’s Manual contains proprietary information protected by copyright, and this User’s Manual and all accompanying hardware, software, and documentation are copyrighted.
  • Page 3 Revision User’s Manual for PLANET 2~24-Port H.323/SIP VoIP Gateway: Model: VIP-281/VIP-480/VIP-1680/VIP-2480 series Rev: 2.0 (January, 2007) Part No. EM-VIP GW_V2...

  • Page 4: Table Of Contents

    TABLE OF CONTENTS Chapter 1 Introduction ................6 Overview..........................6 Package Content .......................9 Physical Details .........................9 Front Panel LED Indicators & Rear Panels..............12 Chapter 2 Preparations & Installation ..........14 Physical Installation Requirement ................14 LAN/WAN Interface quick configurations...............15 LAN IP address configuration via web configuration interface.......15 WAN IP address configuration via web configuration interface ......16 Chapter 3 Network Service Configurations........
  • Page 5 FAQ 8: Peer to Peer call for one shoot dialing: FXO to FXO........81 FAQ 9: Peer to Peer call: Hotline setting ..............83 FAQ 10: SIP speed call setting .................85 Appendix C................... 87 VIP-281 series Specifications...................87 VIP-480 series Specifications...................88 VIP-880 series Specifications...................89 VIP-1680 series Specifications.................90 VIP-2480 series Specifications.................91...

  • Page 6: Chapter 1 Introduction

    With years of Internet telephony and router manufacturing experience, PLANET proudly introduces the newest member of the PLANET VoIP gateway family: the VIP-GW, VIP-281 / VIP-480 / VIP-880 / VIP-1680 / VIP-2480 series. The PLANET VoIP Gateway is fully both SIP and H.323 standard compliant residential gateway that...
  • Page 7 (FXS), and PBX connection (FXO). 16-port model, VIP-168nxx: VIP-1680 equips eight FXO and eight FXS interfaces to have the great flexibility of PBX connection (FXO), and telephone or FAX machine connection (FXS). VIP-1680FO equips sixteen FXO interfaces to have the great flexibility of PBX connection (FXO).
  • Page 8 Voice channels status display: This function display each port status likes as on-hook, off-hook, calling number called number, talk duration, codec. • Life line support for co-existing FXO-FXS port of VIP-281, VIP-480, VIP-880, VIP-882, VIP-1680 and VIP-2480 while power down.

  • Page 9: Package Content

    Package Content The contents of your product should contain the following items: The VoIP Gateway Power adapter (2 / 4 / 8-port model) / Power cord (16 / 24-port model) Quick Installation Guide User’s Manual CD RJ-45 cable x 1 RS-232 cable x 1 (8 / 16 / 24-port model) 25 port Telephone Cable x 1 (16 / 24-port model) Rack mount brackets x 2 (16 / 24-port model)
  • Page 10 Front Panel of VIP-480 Rear Panel of VIP-480 Front Panel of VIP-480FS Rear Panel of VIP-480FS Front Panel of VIP-480FO Rear Panel of VIP-480FO Front Panel of VIP-880...
  • Page 11 Rear Panel of VIP-880 Front Panel of VIP-882 Rear Panel of VIP-882 Front Panel of VIP-880FO Rear Panel of VIP-880FO Front Panel of VIP-1680 Front Panel of VIP-1680FO...

  • Page 12: Front Panel Led Indicators & Rear Panels

    Front Panel of VIP-2480 Front Panel of VIP-2480FO Rear Panel of VIP-1680/VIP-1680FO/VIP-2480/VIP-2480FO Front Panel LED Indicators & Rear Panels Front Panel LED State Descriptions GW is powered ON GW is powered Off Flashing The system is running (VIP-880 / VIP-1680 /...
  • Page 13 PSTN line of carrier. Standard Telco 50 PIN It is a 50 pins RJ-21 connector for connecting to telephone patch panel. Note: (the VIP-1680/VIP-2480 series only) Connector (RJ-21) 9-pin RS-232 Connecting VIP to a terminal emulator for configuring VIP...

  • Page 14: Chapter 2 Preparations & Installation

    Chapter 2 Preparations & Installation Physical Installation Requirement This chapter illustrates basic installation of VIP-GW series • Network cables. Use standard 10/100Base-TX network (UTP) cables with RJ45 connectors. • TCP/IP protocol must be installed on all PCs. For Internet Access, an Internet Access account with an ISP, and either of a DSL or Cable modem (for WAN port usage) Administration Interface PLANET VIP-GW provides GUI (Web based, Graphical User Interface) for machine management and...

  • Page 15: Lan/Wan Interface Quick Configurations

    Please locate your PC in the same network segment Note (192.168.0.x) of VIP-GW. If you’re not familiar with TCP/IP, please refer to related chapter on user’s manual CD or consult your network administrator for proper network configurations. LAN/WAN Interface quick configurations Nature of PLANET VIP-GW is an IP Sharing (NAT) device, it comes with two default IP addresses, and default LAN side IP address is “192.168.0.1”, default WAN side IP address is “172.16.0.1”.

  • Page 16: Wan Ip Address Configuration Via Web Configuration Interface

    Parameter Description LAN IP address of VIP-GW IP address Default: 192.168.0.1 LAN IP address of VIP-GW Subnet Mask Default: 255.255.255.0 It is suggested to keep the DHCP server related parameters Hint in default state to keep machine in best performance. After confirming the modification you’ve done, Please click on the Apply button to macke the changes Save Configuration”...

  • Page 17: Chapter 3 Network Service Configurations

    Chapter 3 Network Service Configurations Configuring and monitoring your VoIP Gateway from web browser The VIP-GW integrates a web-based graphical user interface that can cover most configurations and machine status monitoring. Via standard, web browser, you can configure and check machine status from anywhere around the world.

  • Page 18: Wizard Setup For Quick Start

    VIP-GW main page Wizard Setup for Quick Start Wizard Setup After finishing the authentication, the Main menu will display 3 parts of configuration, please click “Wizard Setup” to enter quick start: 1. WAN Port Type Setup (Setup First) For most users, Internet access is the primary application. The VIP-GW support the WAN interface for Internet access and remote access.
  • Page 19 ADSL Dial-Up User (PPPoE Enable) Some ISPs provide DSL-based service and use PPPoE to establish communication link with end-users. If you are connected to the Internet through a DSL line, check with your ISP to see if they use PPPoE. If they do, you need to select this item.

  • Page 20: Configuring Nat Or Bridge Setting

    2. Configuring NAT or Bridge setting: Bridge Mode: When working on Bride Mode, the VoIP gateway will use only the LAN setting IP, The VIP-GW will use the same LAN IP setting as WAN IP. That means, when Bride mode enable, the WAN connection setting will be ignored.

  • Page 21: Voip Call Protocol Setup

    3. VoIP Call Protocol Setup STEP 1 : Configure VoIP Call Signal Protocols : User could select either H.323 or SIP Protocol, and click “select” STEP 2 : configure the numbering with phone/line ports The representation number is the phone number of the telephone that Phone Number is connected to phone port Line ports are connected to the extension ports of the PBX system or...
  • Page 22 STEP 4: Outgoing Dialing Plan The purpose of “Outgoing Direct Call” setting is to let user create a proprietary dialing plan when this Gateway is not registered to any H.323 Gatekeeper or any SIP proxy server. This setting can also assign some dialing plan to local ports (including prefix strip, prefix addition).

  • Page 23: Chapter 4 System Configurations

    Chapter 4 System Configurations Advance Setup of Network Setup In Advanced Setup, VIP-GW provides user two major parts function to configure: One is “Network Setup”, the other one is “VoIP Call Setup” Network Setup Label Sets/changes the WAN port type like “Fixed IP”, “DHCP WAN Setting Client”...

  • Page 24: Wan Setting

    WAN Setting For most users, Internet access is the primary application. The VIP-GW series support the WAN interface for Internet access and remote access. The following sections will explain more details of WAN Port Internet access and broadband access setup. When you click “WAN Setting”, the following setup page will be shown.Three methods are available for Internet access.

  • Page 25: Lan Setting

    DHCP client (Dynamic IP): (get WAN IP address automatically) IP Address: If you are connected to the Internet through a Cable modem line then a dynamic IP address will be assigned. WAN port display the IP address, Subnet Mask and default Note gateway IP address if DHCP client is successful LAN Setting...

  • Page 26: Virtual Server

    DHCP Server Configuration DHCP stands for Dynamic Host Configuration Protocol. It can automatically dispatch related IP settings to any local user configured as a DHCP client. The DHCP server supports up to 253 users (PCs) on Yes: Enables the DHCP server. No: Disables the DHCP server. Start IP Address Sets the start IP address of the IP address pool.

  • Page 27: Dynamic Dns

    How to set a Virtual Server The following example shows how an internal FTP server is exposed to the public domain. The internal FTP server is running on the local host addressed as 192.168.0.100. Public Port Specifies which port should be redirected to the internal host. Private IP Specifies the private IP address of the internal host offering the service.

  • Page 28: Netwrok Management

    User Name Input your DDNS User Name Password Input your DDNS Password Input you set from your DDNS Domain Name Input your DNS Server IP DNS Server IP Netwrok Management Network Parameter allows you to modify the access port of gateway. For example: Setting HTTP port: 80 and Setting TELNET port: 23...

  • Page 29: Advance Setup Of Voip Setup

    Advance Setup of VoIP Setup In Advanced Setup, VIP-GW provides user two major parts function to configure: One is “Network Setup”, the other one is “VoIP Call Setup” VoIP Setup Label The PLANET series gateway support 2~24 phone/line for SIP and VoIP Basic H.323 VoIP call applications.

  • Page 30: Voip Basic Configuration To H.323 Protocol

    VoIP Basic Configuration: (Configure the VoIP protocol to H.323 Protocol) Configure the numbering with FXS / FXO ports. (Depending on GW model number: if user uses the model number is VIP-1680, this VIP-1680 has 16 voice channels for setting, and the VIP-2480 had 24 voice channels for setting)
  • Page 31 Register to H.323 Gatekeeper server Note: If user does not have Gatekeeper, please go to H.323 Dialing Plan Policy for more understandings. H.323 Parameters Label Sets the unique name of this Gateway, that is H.323 ID communicated as part of H.323 messaging. Primary Gatekeeper IP There are two gatekeeper address fields, one is primary, Address...

  • Page 32: Dialing Plan To H.323 Protocol

    Let user set prefix number in RRQ nonstandard voicecap Voice Cap Prefix entry. In H.323 standard the RAS default port number is 1719. The VoIP gateway provides user to change RAS port RAS Port Adjustment number to meet the network environment.(Some area carrier blocks or forbidden the default port number) In H.323 standard the default Q.931 port number is 1720.
  • Page 33 “Delete Length” is the number of digits that will be stripped from beginning of the dialed number. “Add Digit Number” is the digits that will be added to the beginning of the dialed number. “Destination IP Address / Domain Name” is the IP address / Domain Name of the destination gateway that owns this phone number.
  • Page 34 In the “Incoming Dial Plan Configurations” settings: Maximum Entries : 50 “Inbound number” is the leading digits of the dialing number. “Length of Number“ has two text fields need filled: “Min Length” and “Max Length” is the min/max allowed length you can dial. “Delete Length”...
  • Page 35 Scenario description: Hunting for FXO port (VIP-480FO) Port 1: FXO was connected to PSTN. Port 2: FXO was connected to PSTN. Port 3: FXO was connected to PSTN. Port 4: FXO was connected to PSTN. H.323 number “123” call incoming, the port 1 will be off-hook and hear the dial tone from PSTN. If port 1 is busy, the port 2 will be will be off-hook and hear the dial tone from PSTN.

  • Page 36: Advance Setting To H.323 Protocol

    Scenario description: Termination call to FXO for one-shoot call Port 1: FXO was connected to PSTN (area code is 81xxxxxxxx). H.323 leading number “081x” incoming, and delete the first one digit “0”, and call to PSTN number. Note: “081x” will be registered to H.323 Gatekeeper if “Register to GK” was enabled, show as below: Scenario description: Termination call to FXO Port 1: FXS Port 1: FXO was connected to PSTN (area code is 92xxxxxxxx).
  • Page 37 H.323 VoIP Advance Configurtion If this function is enabled, when VoIP call is occurred, the other Smart-QoS data will be automatically reduced traffic which across the internet in order to guarantee the voice bandwidth. After the VoIP call is connected, when you dial a digit, this digit is sent to the other side by DTMF tone.
  • Page 38 The T.38 is a “Real Time Group 3 FAX communication over IP network” format. That’s meaning it’s a protocol for Fax over IP. You have to enable this function. This command configures the number of seconds that the H.323 RRQ TTL gateway should be considered active by the H.323 Gatekeeper.
  • Page 39 You can configure how long the Ring Frequency do you want Ring Frequency to use. Enable battery reverse to detect polarity from PSTN line. The FXO Battery Reverse PSTN line can send H.323 case: Sending the Q.931 connect signal to caller when detecting polarity reverse from PSTN line. When user calls the PSTN line which was connected with the FXO port, there are three answer mode for user to configure.
  • Page 40 Note: This case can avoid the local PSTN charge when the FXS port still ring. 3. Non Answer Mode: FXO will NOT answer the call in any time. Note: Some ITSP only let the FXO for termination function, they do not user use the FXO port for origination Scenario description: H.323 call connecting answer mode Case B: “Hot Line Number”...

  • Page 41: Voip Basic Configuration To Sip Protocol

    H.323 Netwrok Advance Configuration If this function is enabled, when VoIP call is occurred, the other data Smart-QoS will be automatically reduced traffic which across the internet in order to guarantee the voice bandwidth. Bandwidth control You can configure your bandwidth what the Max byte of download and upload of ADSL modem rate.
  • Page 42 SIP Hunting Table: This allows gateway can answer SIP call from internet by Hunting. For example: Port 1 and port 2 is hunting for the port 1 SIP account. If the port 1 is incoming call, the other one SIP call from internet will ring port 2. SIP Proxy Server Setting Enter the SIP realm in this field Domain/Realm...

  • Page 43: Dialing Plan To Sip Protocol

    Dialing Plan to SIP protocol The “Dialing plan” needs setting when the user uses the method of Peer-to-Peer or registering SIP proxy server mode. The SIP dialing plan has two kinds of directions: Outgoing (call out) and incoming (call in). Peer-to-Peer call mode: Effective Outgoing Dial Plan Registering to SIP Proxy Server Mode: Effective...
  • Page 44 Scenario description: Normally dial 2290x leading call out, call to destination domain name: sipgw.test.com 221 leading call out, call to destination IP address: 172.16.0.100 Scenario description: Speed dial If user dials “101”, the gateway automatically dials “1234567890” to destination IP address: 172.16.0.101 If user dials “202”, the gateway automatically dials “0987654321”...
  • Page 45 Scenario description: Hunting for FXS port (VIP-400FS) Port 1: FXS Port 2: FXS Port 3: FXS Port 4: FXS H.323 number “123”call incoming, the port 1 will be ringing. If port 1 is busy, the port will be ringing. If port 1 and port 2 are busy, the port 3 will be ringing. If port 1, port 2 and port 3 are busy, the port 4 will be ringing.

  • Page 46: Advance Setting To Sip Protocol

    Note: “123” will be NOT register to SIP proxy server when gateway is registering SIP proxy server mode Scenario description: Termination call to FXO for one-shoot call Port 1: FXO was connected to PSTN (area code is 81xxxxxxxx). SIP leading number “081x” incoming, and delete the first one digit “0”, and call to PSTN number. Note: “081x”...
  • Page 47 T.30/T.38 real-time FAX compliant Voice/FAX auto-switch. The T.38 is a “Real Time Group 3 FAX communication over IP FAX Mode Option network” format. That’s meaning it’s a protocol for FAX over IP. You have to enable this function. SIP Telephone Advance Configuration If this function is enabled, when silence is occurred for a Silence Compression period of time, no data will be sent across the network...
  • Page 48 generate flash to FXS. Flash Generation: Let you change flash generation time (milliseconds) for PBX detection. Ring Frequency You can configure how long the Ring Frequency do you want to use. Enable battery reverse to detect polarity from PSTN line. The PSTN line can send SIP case: Sending the 200 OK FXO Battery Reverse connect signal to caller when detecting polarity reverse...
  • Page 49 the Phone (connected to the FXS port) was picked up by user. (Note: This case can avoid the Local PSTN charge when the FXS port still ring.) 6. Non Answer Mode: FXO will NOT answer the call in any time. (Note: Some ITSP only let the FXO for termination function, they do not user use the FXO port for origination)

  • Page 50: Port Status

    SIP Netwrok Advance Configuration If this function is enabled, when VoIP call is occurred, the other Smart-QoS data will be automatically reduced traffic which across the internet in order to guarantee the voice bandwidth. Bandwidth control You can configure your bandwidth what the Max byte of download and upload of ADSL modem rate.

  • Page 51: Chapter 5 System Administrations

    Chapter 5 System Administrations Management Management Label You can save configuration and restart the gateway with the default Save Configuration configuration or with the current running configuration. Users can sets/changes the administrator password... Access Control Set to Default You can restart the VIP-GW with the default configuration. Backup/Restore User can backup the configuration file of VPI-GW to PC or restore Configuration...

  • Page 52: Save Configuration

    Save Configuration This page allows you to click “Save Configuration and Reboot” to save configuration and begin to restart. Access Control Changing the Administrator/Guest Password For security reasons, we strongly recommend that you set an administrator/password for the router. On first setup the router requires no password.

  • Page 53: Set To Default Configuration

    Set To Default Configuration If you want to reboot the router using factory default configuration, click “Apply” then reset the router’ s settings to default values. Backup/Restore Configuration to a File User can backup the configuration to a File at Microsoft Operation System. And also restore the configuration file to the VIP-GW from PC.

  • Page 54: Sntp Setting Function

    SNTP Setting Function Click SNTP setting to open the Online Status page. In the example, on the following page: Use SNTP Setting— when checked, gateway uses a Simple Network Time Protocol (SNTP) to set the date and time. The gateway synchronizes the gateway’s time after you select the time zone. Use SNTP Setting;...

  • Page 55: Capture Packetackets Function

    Capture packetackets Function Use “Capturer Packets” to record VIP-GW packets. Users can start and stop the capture then save the file to PC. Use the Ethereal Tool (www.ethereal.com) to analyze the packets.

  • Page 56: Voice Communications

    Appendix A Voice communications The chapter shows you the concept and command to help you configure your PLANET VIP-GW through sample configuration. And provide several ways to make calls to desired destination in VIP-GW. In this section, we’ll lead you step by step to establish your first voice communication via web browsers operations.
  • Page 57 FXS (Foreign exchange Station) port The FXS port allows the connection to an end node, like telephone, fax machine, or out-line of PBX system. FXS port is as like your local phone service provider who provides a number to you. It is easy to tell that after you have connected an end-device to FXS port and you will hear the dial-tone from FXS port once the hand set off-hook.

  • Page 58: H.323 Voip Call: Peer-To-Peer Mode

    H.323 VoIP Call: Peer-To-Peer Mode Scenario 1: Gateway 1 to Gateway 2 PLAR connection H.323 Call (Peer-To-Peer Mode) Outgoing Dial plan Outgoing Dial plan No: 8x | Digit: 3~3 |Des: GW2 IP address No: 9x | Digit: 3~3 | Des: GW1 IP address x: wild card Des: Destination IP Digit: Digit Length min~ max...
  • Page 59 Scenario 3: Gateway 1 (with PBX/PSTN) to Gateway 2 PLAR connection Call Method: Two-Stages-Dialing H.323 Call (Peer-To-Peer Mode) with PBX: Remote Call PSTN number Method 1: Two-Stages-Dialing Outgoing Dial plan Outgoing Dial plan No: 9x | Digit: 3~3 | Des: GW1 IP address No: 8x | Digit:3~3 | Des: GW2 IP address No: 6x | Digit:3~3 | Des :GW1 IP address X: wild card...
  • Page 60 Scenario 5: Gateway 2 to Gateway 1 (Remote Call PSTN number) PLAR connection Call Method: One-Shot-Dialing H.323 Call (Peer-To-Peer Mode) : Remote Call PSTN number Method: One-Shot-Dialing Outgoing Dial plan Outgoing Dial plan No: 8x | Digit: 3~3, Des | GW2 IP address No: 9x | Digit: 3~3 | Des: GW1 IP address Incoming Dial Plan No: 6x | Digit: 3~3 | Des: GW1 IP address...

  • Page 61: H.323 Voip Call: Gatekeeper Mode

    H.323 VoIP Call: Gatekeeper Mode Scenario 7: Gateway 1 to Gateway 2 PLAR connection H.323 Call (GK Mode) Register Number List GW1: 801 GW2: 901 Gateway#2 Gateway#1 Scenario 8: Gateway 2 to Gateway 1 (Call PBX extension number) PLAR connection Call Method: Two-Stages-Dialing H.323 Call (GK Mode) with PBX: Call PBX Extension Method 1: Two-Stage-Dialing...
  • Page 62 Scenario 9: Gateway 2 to Gateway 1 (Remote Call PSTN number with PBX) PLAR connection Call Method: Two-Stages-Dialing H.323 Call (GK Mode) with PBX: Remote Call PSTN number Method 1: Two-Stages-Dialing Register Number List GW1: 801 GW2: 901,609 Gateway#1 Gateway#2 Extension 609 02-12345678 Trunk-Line...
  • Page 63 Scenario 11: Gateway 2 to Gateway 1 (Remote Call PSTN number) PLAR connection Call Method: One-Shot-Dialing H.323 Call (GK Mode) : Remote Call PSTN number Method: One-Shot-Dialing Incoming Dial Plan Register Number List No: 02x | Digit: 3~10 | Strip:2 | FXO port GW1: 801, GW2: 901,609,02x x: wild card Des: Destination IP...

  • Page 64: Sip Voip Call: Peer-To-Peer Mode

    SIP VoIP Call: Peer-To-Peer Mode Scenario 13: Gateway 1 to Gateway 2 PLAR connection SIP Call (Peer-To-Peer Mode) Outgoing Dial plan Outgoing Dial plan No: 8x | Digit: 3~3, Des | GW1 IP address No: 9x | Digit: 3~3, Des | GW1 IP address x: wild card Des: Destination IP Digit: Digit Length min~ max...
  • Page 65 Scenario 15: Gateway 2 to Gateway 1 (Remote Call PSTN number with PBX) PLAR connection Call Method: Two-Stages-Dialing SIP Call (Peer-To-Peer Mode) with PBX: Remote Call PSTN number Method 1: Two-Stages-Dialing Outgoing Dial plan Outgoing Dial plan No: 8x | Digit: 3~3, Des | GW2 IP address No: 9x | Digit: 3~3, Des | GW1 IP address No: 6x | Digit: 3~3, Des | GW1 IP address x: wild card...
  • Page 66 Scenario 17: Gateway 2 to Gateway 1 (Remote Call PSTN number) PLAR connection Call Method: One-Shot-Dialing SIP Call (Peer-To-Peer Mode) : Remote Call PSTN number Method: One-Shot-Dialing Outgoing Dial plan Outgoing Dial plan No: 9x | Digit: 3~3 | Des: GW1 IP address No: 8x | Digit: 3~3, Des | GW2 IP address No: 6x | Digit: 3~3 | Des: GW1 IP address Incoming Dial Plan...

  • Page 67: Sip Voip Call: Sip Proxy Server

    SIP VoIP Call: SIP Proxy Server Scenario 19: Gateway 1 to Gateway 2 PLAR connection SIP Call (Register to SIP Proxy Server Mode) Register Number List GW1: 801 SIP Proxy Server GW2: 901 Gateway#2 Gateway#1 Scenario 20: Gateway 2 to Gateway 1 (Call PBX extension number) PLAR connection Call Method: Two-Stages-Dialing SIP Call (SIP Proxy Server Mode) with PBX: Call PBX Extension Method 1: Two-Stage-Dialing...
  • Page 68 Scenario 21: Gateway 2 to Gateway 1 (Remote Call PSTN number with PBX) PLAR connection Call Method: Two-Stages-Dialing SIP Call (SIP Proxy Server Mode) with PBX: Remote Call PSTN number Method: Two-Stages-Dialing Register Number List GW1: 801 SIP Proxy Server GW2: 901,609 Gateway#1 Gateway#2...
  • Page 69 Scenario 23: Gateway 2 to Gateway 1 (PSTN Call PSTN number) PLAR connection Call Method: Two-Stages-Dialing SIP Call (SIP Proxy Server Mode) : PSTN Call PSTN number Method: Two-Stages-Dialing Register Number List GW1: 801,804 GW2: 901,904 SIP Proxy Server Gateway#1 Gateway#2 02-87654321 04-56785678...

  • Page 70: Faq

    Appendix B Q: What is the default administrator password to login to the gateway? A: By default, your default username is “admin”; default password is “123” to login to the router. For security, you should modify the password to protect your gateway against hacker attacks.

  • Page 71: Faq 1: Firmware Upgrade Requirement And Process

    FAQ 1: Firmware upgrade Requirement and Process 1. Environment Requirement a) A PC with FTP Server (Server-U software) b) A PC or Notebook witch connected to LAN port of gateway. c) Put the image (firmware) named “FW-VIP880_vxxx.bin ” at the assigned folder in FTP Server. For example: “FW-VIP880_v282.bin”...

  • Page 72: Faq 2: Busy Tone Learning

    FAQ 2: Busy Tone Learning STEP 1: Let the FXO port connect to PBX ext. STEP 2: To dial to the FXO port from PBX another ext. STEP 3: Hear dial tone, please dial FXS port number. When FXS port ring, please hang up the phone. STEP 4: At this moment, hear busy tone and also press “y”...

  • Page 73: Faq 3: Fxo Ringer Voltage Threshold / Ringer Voltage Filter Setting

    FAQ 3: FXO Ringer Voltage Threshold / Ringer Voltage Filter Setting VIP-Gateway provides ring detector in FXO device avoiding can not answer and always OFF-HOOK status. This ring detector provides two functions to meet the various PBX’s extension port: 1. FXO ringer voltage threshold 2.
  • Page 74 2. Voice Detection: Voice Detection-based answer supervision is a feature where the Gateway can be configured to “listen” on the line for different tones and voice. The Gateway sends a “connect” signals out or “disconnect” signaling using internet. H.323 scenario description: Loop Start Reverse Battery PSTN line was set polarity reverse a) The gateway can send the “Q.931 connect”...

  • Page 75: Faq 5: Fxo Answer Mode Setting

    Scenario description: Voice Detection based on answer supervision PSTN Line was not support Polarity Reverse: a) The gateway can send the 200 OK SIP signals to Billing system of ITSP, after the user pick up the Phone and detect the voice. b) The gateway can send the 200 BYE SIP signals to Billing system of ITSP, after the user hang up the phone and detect the hang up voice.
  • Page 76 Note: Some ITSP only let the FXO for termination function, they do not user use the FXO port for origination SIP Call Connecting Answer Mode Scenario B description: Hot Line Number” was assigned and the hot line number belongs to SIP device. a) When the call com from PSTN to FXO, FXO start the Hot line dialing to remote SIP gateway b) The phone of remote SIP gateway start ring.
  • Page 77 H.323 Call Connecting Answer Mode Scenario B description: Hot Line Number” was assigned and the hot line number belongs to remote H.323 device. Note: The remote H.323 device need disable the “Auto Answer” a) When the call com from PSTN to FXO, FXO start the Hot line dialing to remote H.323 gateway b) The phone of remote H.323 gateway start ring.

  • Page 78: Faq 6: Peer To Peer Call: Fxo To Fxo

    FAQ 6: Peer to Peer call: FXO to FXO Scenario description: User (500) on site A (VIP-880FO) wishes to have telephone calls to extension (600) on Site B (VIP-880FO B). User (500) on site B (VIP-880FO B) can connect to ser A in the same way. IP address of VIP-880FO_A is: 172.16.0.1 VIP-880FO_A number and dial plan setting: Each port number is 100,200,300,400,500,600,700,800...

  • Page 79: Faq 7: Peer To Peer Call: Fxo To Fxs

    The dial plan of VIP-880FO_B dial plan setting: that means call 0xxx leading number go to IP address 172.16.0.1 gateway (VIP-880FO_A). Usage: The ext.509 dial to ext 501 (connect to FXO port 1) will hear the dial tone, and then dial 0100 go to IP address gateway 172.16.0.2 (VIP-880FO_B), and hear the dial tone again, then dial 609 ext, the ext.609 will ring.
  • Page 80 IP address of VIP-880FO is: 172.16.0.1 VIP-880FO number and dial plan setting: Each port number is 100,200,300,400,500,600,700,800 IP address of VIP-880FS is: 172.16.0.2 VIP-880FS number and dial plan setting: Each port number is 100,200,300,400,500,600,700,800 The dial plan of VIP-880FO dial plan setting: that means call 0xxx leading number go to IP address 172.16.0.2 gateway (VIP-880FS).

  • Page 81: Faq 8: Peer To Peer Call For One Shoot Dialing: Fxo To Fxo

    Usage: The ext.509 dial to ext 501 (connect to FXO) will hear the dial tone, and then dial 0100 go to IP address gateway 172.16.0.2 (VIP-880FS), and phone of port 1(100) will ring. FAQ 8: Peer to Peer call for one shoot dialing: FXO to FXO Scenario description: User (500) on site A (VIP-880FO) wishes to have telephone calls to extension (600) on Site B (VIP-880FO B).
  • Page 82 The dial plan of VIP-880FO_A: that means call 0xxx leading number will go to IP address 172.16.0.2 gateway (VIP-880FO_B). VIP-880FO_B number and dial plan setting: The dial plan of VIP-880FO_B dial plan setting: that means incoming call 60x leading number will hunt port 1 to port 8 The dial plan of VIP-880FO_B: That means call 0xxx leading number will go to IP address 172.16.0.1 gateway (VIP-880FO_A).

  • Page 83: Faq 9: Peer To Peer Call: Hotline Setting

    FAQ 9: Peer to Peer call: Hotline setting Hot line Basic Concept: Any number set in Hot line field will be dialed by VoIP call automatically. For FXS port case: When user picks up the phone, the gateway will dial the hot line number to internet by VoIP call.
  • Page 84 Scenario description: Register to SIP proxy server/H.323 Gatekeeper direct call STEP 1: Let your VIP-GW register to SIP proxy or H.323 Gatekeeper server STEP 2: To set hot line number in Hot Line Option STEP 3: When users pick up the phone (port1), the gateway will dial the “911” to SIP proxy or H.323 Gatekeeper server (ITSP) Scenario description: Register to SIP Proxy / H.323 Gatekeeper server and Peer to Peer direct call first...

  • Page 85: Faq 10: Sip Speed Call Setting

    STEP 4: When users pick up the phone (port 1), the gateway will dial the “911” to the gateway which’s IP address 172.16.0.119. Note: This call will not call to SIP Proxy or H.323 Gatekeeper server because of direct call first. FAQ 10: SIP speed call setting Speed calls Concept: Cut your phone number down to fewer digit dialing!
  • Page 86 Scenario description C: User wants to dial 888 instead of 810-861234567890 Note: The destination IP address is the domain name of sip proxy server...

  • Page 87: Vip-281 Series Specifications

    Appendix C VIP-281 series Specifications Product 2-Port H.323/SIP VoIP Gateway Model VIP-281 VIP-281FS Hardware 1 x 10/100Mbps RJ-45 port 4 x 10/100Mbps RJ-45 port Voice 2 x RJ-11 connection 2 x RJ-11 connection ( 1 x FXS, 1 x FXO) ( 2 x FXS) Protocols and Standard Standard...

  • Page 88: Vip-480 Series Specifications

    VIP-480 series Specifications Product 4-Port H.323/SIP VoIP Gateway Model VIP-480 VIP-480FS VIP-480FO Hardware 1 x 10/100Mbps RJ-45 port 4 x 10/100Mbps RJ-45 port Voice 4 x RJ-11 connection 4 x RJ-11 connection 4 x RJ-11 connection ( 2 x FXS, 2 x FXO) ( 4 x FXS) ( 4 x FXO) Protocols and Standard...

  • Page 89: Vip-880 Series Specifications

    VIP-880 series Specifications Product 8-Port H.323/SIP VoIP Gateway Model VIP-880 VIP-882 VIP-880FO Hardware 1 x 10/100Mbps RJ-45 port 1 x 10/100Mbps RJ-45 port Voice 8 x RJ-11 connection 8 x RJ-11 connection 8 x RJ-11 connection ( 4 x FXS, 4 x FXO) ( 6 x FXS, 2 x FXO) ( 8 x FXO) Protocols and Standard...

  • Page 90: Vip-1680 Series Specifications

    VIP-1680 series Specifications Product 16-Port H.323/SIP VoIP Gateway Model VIP-1680 VIP-1680FO Hardware 1 x 10/100Mbps RJ-45 port 1 x 10/100Mbps RJ-45 port Voice 1 x RJ-21 connector for connecting to 1 x RJ-21 connector for connecting to telephone patch panel...

  • Page 91: Vip-2480 Series Specifications

    VIP-2480 series Specifications Product 24-Port H.323/SIP VoIP Gateway Model VIP-2480 VIP-2480FO Hardware 1 x 10/100Mbps RJ-45 port 1 x 10/100Mbps RJ-45 port Voice 1 x RJ-21 connector for connecting to 1 x RJ-21 connector for connecting to telephone patch panel telephone patch panel (12 x FXS, 12 x FXO) (24 x FXO)
