Removing the Front Bezel

1 Press the Power button to turn off the computer.
2 Disconnect all cables and remove all items from the
computer:
Disconnect cables for power, keyboard, mouse,
monitor, etc.
Remove items such as memory cards, USB
drives, etc.
3 Remove the side cover by loosening the screw that
connects the cover to the computer.
Removing and Replacing the Front Bezel
4 Grasp the handle on the side cover and pull towards
the back of the computer. Slide the cover about
2.4 cm (1 inch) to remove it.
5 Remove the side panel by lifting it away from the
computer.
