Replacing the 1394 Card
5000 and 7000 Series
End-User Replaceable Parts Program

Advertisement

loading

Related Manuals for Compaq 5000 Series

Summary of Contents for Compaq 5000 Series

  • Page 1 Replacing the 1394 Card 5000 and 7000 Series End-User Replaceable Parts Program...
  • Page 2 All other product names mentioned herein may be trademarks or registered trademarks of their respective companies. Compaq shall not be liable for technical or editorial errors or omissions contained herein. The information in this document is subject to change without notice.
  • Page 3 Replacing the Introduction 1394 Card Your Compaq Internet PC has an Easy Access panel that makes accessing the internal parts easy. This document The 1394 card (also known contains instructions for removing and replacing the 1394 as IEEE 1394) has a high- card (see Figure 1-1).

  • Page 4: Tools Needed

    Compaq. Your replacement part is warranted for the longer of 90 days from the date the part was delivered to you, or the original One Year Limited Warranty that came with your Compaq Presario. Preparing Your Computer for Disassembly...

  • Page 5: Disconnecting The Power

    I. Disconnecting the Power 1. To shut down your computer, click the Start button, and then click Shut Down. The Shut Down Windows dialog box is displayed. Click OK to turn the computer off. 2. Disconnect the power cord from the electrical outlet 1 and 2 computer (see Figure 1-2).
  • Page 6 II. Opening the Side Access Panel 1. Remove the screw 1 securing the side access panel. Locate the latch 2 directly below the screw, press the latch down, and hold it in the down position (Figure 2-1). Did you know ... Figure 2-1 You do not have to replace the screw securing the side access...
  • Page 7 III. Identifying and Locating the 1394 Card Use the illustration to identify and locate the following items: the 1394 card 1, the PCI system board slot 2, and the rear connector slot 3 (see Figure 3-1). Look at the replacement part carefully to help you identify and locate the component to be replaced.
  • Page 8 IV. Removing the 1394 Card 1. Turn the computer on its side (open side facing up), and locate the 1394 card. 2. Disconnect the Front I/O and the power cable (4 pin connector) from the 1394 card (see Figure 4-1). Figure 4-1 1394 C EPLACING THE...
  • Page 9 3. Remove the screw 1 securing the 1394 card, and save it for your replacement card (see Figure 4-2). Important: Keep the screw that secured the defective card to the chassis. You will need it for your replacement card. 4. Pull the 1394 card using a gentle rocking (side-to-side) motion from the PCI slot 2 on the system board (see Figure 4-2).
  • Page 10 V. Replacing the 1394 Card Note: Save all the packing materials received with your replacement card. You will need them to return the defective part. 1. Align the 1394 card with the PCI slot 1 on the system board and with the expansion card rear connector slot on the chassis (see Figure 5-1).
  • Page 11 2. The 1394 card rear connector(s) 1 must be inserted properly into the expansion card rear connector slot 2 to ensure the card will seat properly into the PCI slot on the system board (see Figure 5-2). Note: Carefully insert the rear connector(s) on the 1394 card inside the expansion card rear connector slot on the chassis.
  • Page 12 3. Carefully and firmly press the 1394 card into the PCI slot. 4. Replace the screw 1 to secure the 1394 card to the chassis (see Figure 5-3). Figure 5-3 1394 C EPLACING THE...
  • Page 13 5. Reconnect the Front I/O 1 and the power 2 cable (4 pin connector) to the 1394 card (see Figure 5-4). Figure 5-4 1394 C EPLACING THE...

  • Page 14: Replacing The Side Access Panel

    VI. Replacing the Side Access Panel Align the tabs on the top and bottom of the side access panel with the slots (located on the top and bottom edge) on the chassis and slide the side access panel into place (see Figure 6-1).
  • Page 15 Replacing procedures. 5. If you are still experiencing problems, contact Compaq Support: 1-800-984-9350 VIII. Returning the Defective Part Please refer to the Compaq Part Return Instructions that came with your replacement part for instructions on returning the defective part. 1394 C...
  • Page 16 216695-001 www.compaq.com...
