  • Page 1 Replacing an Expansion Card 5000 and 7000 Series End-User Replaceable Parts Program...
  • Page 2 All other product names mentioned herein may be trademarks or registered trademarks of their respective companies. Compaq shall not be liable for technical or editorial errors or omissions contained herein. The information in this document is subject to change without notice.
  • Page 3: Replacing An Expansion Card

    Replacing an Introduction Expansion Card Your Compaq Internet PC has an Easy Access panel that makes accessing the internal parts easy. This document An Expansion Card is a contains instructions for removing and replacing the following expansion cards: Modem 1 or Network Interface circuit board that fits into a (NIC) 2 (see Figure 1-1).
  • Page 4: Tools Needed

    Compaq. Your replacement part is warranted for the longer of 90 days from the date the part was delivered to you, or the original One Year Limited Warranty that came with your Compaq Presario. Preparing Your Computer For Disassembly...
  • Page 5: Disconnecting The Power

    I. Disconnecting the Power 1. Turn off the computer using the Power button (see Figure 1-2). Figure 1-2 2. Disconnect the power cord from the electrical outlet 1 and computer 2 (see Figure 1-3). Failure to disconnect the power from the computer may result in personal injury.
  • Page 6 II. Opening the Side Access Panel 1. Remove the screw 1 securing the side access panel. Locate the latch 2 directly below the screw, press down, and hold in the down position (see Figure 2-1). You do not have to replace the screw securing the side access panel.
  • Page 7 III. Identifying and Locating Different Expansion Cards The Expansion Card Chart below shows the various types of expansion cards. This chart will help you to identify the different types of expansion cards such as a modem 1 and a Network Interface Card (NIC) 2 that can be added to your computer (see Figure 3-1).
  • Page 8: Removing The Expansion Card

    IV. Removing the Expansion Card 1. Turn the computer on its side (open side facing up) and locate the expansion card(s) (see Figure 4-1). 2. Remove the screw 1 securing the expansion card and save it for your replacement card (see Figure 4-1). Important: Keep the screw that secured the defective card to the chassis.
  • Page 9 V. Replacing the Expansion Card Note: Save all the packing materials received with your replacement card. You will need them to return the defective part. 1. Align the expansion card with the PCI slot 1 on the system board and with the expansion card rear connector(s) slot on the chassis (see Figure 5-1).
  • Page 10: Replacing The Side Access Panel

    VI. Replacing the Side Access Panel Align the tabs on the top and bottom of the side access panel with the slots (located on the top and bottom edge) of the chassis and slide the side access panel into place (see Figure 6-1).
  • Page 11 Replacing procedures. 4. If you are still experiencing problems, contact Compaq Support: 1-800-984-9350. VIII. Returning the Defective Part Please refer to the Compaq Part Return Instructions that came with your replacement part for instructions on returning the defective part. EPLACING AN...
  • Page 12 198676-001 www.compaq.com...
