  • Page 1 Customize the Look of your Computer 5000 and 7000 Series End-User Replaceable Parts Program...
  • Page 2 All other product names mentioned herein may be trademarks or registered trademarks of their respective companies. Compaq shall not be liable for technical or editorial errors or omissions contained herein. The information in this document is subject to change without notice.
  • Page 3 Customize the Introduction Look of Your This document can be used for removing and replacing the speaker grills 1, Internet Keyboard Button Panel 2, CD Computer Storage door (lower front panel) 3 and upper front panel 4 (see Figure 1-1). The MyStyle Accent Color Kit allows you to change the colors of your speaker...

  • Page 4: Tools Needed

    Compaq. Your replacement part is warranted for the longer of 90 days from the date the part was delivered to you, or the original One Year Limited Warranty that came with your Compaq Presario. Preparing Your Computer for Disassembly...

  • Page 5: Disconnecting The Power

    I. Disconnecting the Power 1. Turn off the computer using the Power button (see Figure 1-2). Figure 1-2 2. Disconnect the power cord from the electrical outlet 1 and computer 2 (see Figure 1-3). Failure to disconnect the power from the computer may result in personal injury.
  • Page 6 II. Opening the Side Access Panel 1. Remove the screw 1 securing the side access panel. Locate the latch 2 directly below the screw, press down, and hold in the down position (see Figure 2-1). You do not have to replace the screw securing the side access panel.
  • Page 7 III. Removing the Upper Front Panel and CD Storage Door (Lower Front Panel) 1. Locate the lock securing the upper front panel to the front of the chassis. The lock is located on the base of the lower 3.5" diskette drive cage inside the chassis. Rotate the lock to the down position to unlock the upper front panel (see Figure 3-1).
  • Page 8 2. From the front of the system, press the indention 1 located at the top of the CD Storage door (lower front panel) to open 2 (see Figure 3-2). Figure 3-2 USTOMIZE THE OOK OF OMPUTER...
  • Page 9 3. Locate the finger holes 1 under the bottom of the upper front panel and place your fingers in the holes. Pull the upper front panel forward until the top panel tabs 2 release from the slots on the chassis (see Figure 3-3). Figure 3-3 USTOMIZE THE OOK OF...
  • Page 10 4. Lift the CD Storage door (lower front panel) slightly with both hands while pressing both tabs 1 with your thumbs at the same time. Lift the CD Storage door (lower front panel) to release 2 from the chassis (see Figure 3-4). Figure 3-4 USTOMIZE THE OOK OF...
  • Page 11 IV. Replacing the Upper Front Panel and CD Storage Door (Lower Front Panel) 1. Place the upper front panel into the slots 1 at the top of chassis and gently snap the panel 2 into place (see Figure 4-1). Figure 4-1 USTOMIZE THE OOK OF OMPUTER...
  • Page 12 2. Locate the hinge pins 1 (left and right side) on the CD Storage door (lower front panel). Insert the pins into the door hinge slots 2 on the chassis and firmly press downward to lock the door in place (see Figure 4-2). Figure 4-2 USTOMIZE THE OOK OF...
  • Page 13 V. Replacing the Side Access Panel Align the tabs on the top and bottom of the side access panel with the slots (located on the top and bottom edge) of the chassis and slide the side access panel into place (see Figure 5-1).
  • Page 14 VI. Removing the Internet Keyboard Button Panel 1. Locate the finger holes on the back of the Internet Keyboard Button Panel and gently lift up on the Internet Keyboard Button Panel to release the tabs 1 from the keyboard slots 2 (see Figure 6-1). Figure 6-1 USTOMIZE THE OOK OF...
  • Page 15 2. Align and insert the tabs 1 into the slots 2 on the Internet Keyboard Button Panel and snap into place (see Figure 6-2). Figure 6-2 USTOMIZE THE OOK OF OMPUTER...
  • Page 16 VII. Removing the Speaker Grills 1. Place your fingers (at the top of the speaker assembly) over the back and gently pull to loosen (see Figure 7-1). Figure 7-1 USTOMIZE THE OOK OF OMPUTER...
  • Page 17 2. Move your fingers to the middle of the speaker grill and gently pull off the speaker grill (see Figure 7-2). Figure 7-2 USTOMIZE THE OOK OF OMPUTER...
  • Page 18 3. To replace the speaker grill, align the pins with the holes inside the speaker and snap into place (see Figure 7-3). Figure 7-3 USTOMIZE THE OOK OF OMPUTER...
  • Page 19 VIII. If You Are Still Experiencing Problems If you experience problems, contact Compaq Support: 1-800- 984-9350. IX. Returning The Defective Part Please refer to the Compaq Part Return Instructions that came with your new part for instructions on returning the defective part. USTOMIZE THE...
