Disassembling The Compaq LTE 5000 Notebook Computer
This page contains step-by-step instructions and photographs that document the process
of taking your Compaq LTE 5000 or 5000-series notebook computer apart.
If you're curious about what's inside your LTE, want to look into upgrading it, or need to
remove a power on/standby/BIOS password, this page will tell you how to get the
computer apart and back together safely.
For safety, simplicity and time's sake, I am not doing a complete teardown of the
computer. The information here will help you see what's inside, repair a failing fan or
remove the power on password. While upgrading components like the display and
processor card with those from a "better" computer are possible, and I have done them
(note the 150MHz processor card in my LTE 5000...), they are very involved and require
you to take the LTE almost completely apart. Unless you are very sure of your skills and
have done this to other notebook computers before, I don't suggest you even try such
advanced upgrades.
Larger photos will be coming soon.
NOTICE: All information on this page is provided strictly on a use at your your own risk
basis. I cannot be held responsible for any results--good or bad--from the use of this
information. Please understand that this is NOT like taking apart a desktop computer!!!
If you don't have the needed tools, skills or physical ability to take your computer apart
safely I do not recommend you try. As with any other computer, the parts inside your LTE
are vulnerable to electro-static discharge damage. The parts used are also usually more
delicate and much more integrated than those in a desktop computer. You've been
warned...
Things You Need:
Small bladed or Torx-tip screwdrivers
A well lighted workspace
Containers to hold various screws and other bits of the machine as you take it apart
Plenty of time to do this without interruption.
Please be sure you have these things before continuing. It isn't difficult to get the LTE
apart, but you should take the time to make notes and keep various pieces well separated
and marked as you take the computer apart.
Let's get started.
IMPORTANT: Be sure you have shut your LTE down completely. Do not leave it in
standby during this process, as even with the battery removed a backup battery will
keep the memory running for quite some time. Remove any compact discs from the
CD-ROM drive before shutting your computer down.
1. Remove all media and storage devices from the computer. The release latch for the
floppy/CD/2nd hard disk bay is at the left side of the machine as it faces you. Press it and
pull the drive out. Do not hold the machine with the drives facing down and pull the latch.

Advertisement

loading

Summary of Contents for Compaq 5000 Series

  • Page 1 Disassembling The Compaq LTE 5000 Notebook Computer This page contains step-by-step instructions and photographs that document the process of taking your Compaq LTE 5000 or 5000-series notebook computer apart. If you're curious about what's inside your LTE, want to look into upgrading it, or need to remove a power on/standby/BIOS password, this page will tell you how to get the computer apart and back together safely.
  • Page 2 The fall will likely damage them. Use the release latch on the right side of the LTE to remove the battery. 2. Remove any media from the floppy drive. 3. After removing the battery and floppy/CD/2nd hard disk, remove the primary hard drive from the computer.
  • Page 3 Note: I don't have the original Compaq supplied hard disk container in my computer. The container you see in my pictures is that from a Procom "Atom Drive" upgrade. The hard disk container may be opened and a different drive put in, if desired. While the connector on the tray is a proprietary type, the drive inside is a standard 2.5"...
  • Page 4 6. Now remove the rear set of keyboard screws. These are located in the middle of the bottom of the LTE. 7. You should now have all the keyboard screws removed. Collect all of the screws you removed (there should be seven screws) and flip the LTE back over. Place it so the ports are now facing you.
  • Page 5 yank it right out of the computer, but why take the chance?) Fold the panel almost to its maximum open position. Lift the upper trim piece up and remove it. Using both hands is helpful and recommended. I couldn't because I had to take the picture somehow... Do not play with the power button, standby switch or lid closure switch.
  • Page 6 12. Tilt the computer back on its display panel so that the area where the drives go is facing you once again. Using a small flat bladed screwdriver, pry up the keyboard at the front of the computer. It is held by simple "snaps" at four places. Look up into the keyboard area and you'll see each one.
  • Page 7 the display are routed in their plastic "grooves". You will need to put them back there when you put the keyboard back in. Do not be tempted to play with the grey latches for the drive/battery bays. These too are spring loaded and not well secured once the keyboard is out. 15.
  • Page 8 17. At this point the entirety of the LTE motherboard, processor card, memory slots and charging circuit will be visible. (Some of this is hidden under the metal shielding, which I suggest you remove and discard...) Each of these assemblies may be removed, but for the moment I do not have directions here on doing this.
  • Page 9 21. Place the rear trim panel into place behind the keyboard. If it does not want to go into place, check your cable routing and adjust any cables that are in the way. Inspect the rear cover carefully. The back should be lined up with the screw holes and there should be no bulging or "lumpy"...
  • Page 10 23. Replace the rearmost three keyboard screws. 24. Replace the four front keyboard screws. If you missed any snaps, press them into place now. 25. Replace the hard disk. Push it in until you hear it click into place. Replace the locking screw if your computer had one in place and you want to do so.
  • Page 11 26. Replace the other drives and the battery.. Push them in until they click into place. 27. Replace any other peripherals that you removed...such as PC cards, etc... 28. Power up. Your LTE 5000 computer should come up immediately. Let it boot up and check for proper operation.
