Description
The Keithley Instruments Model 237-ALG-2 is a 6.6 ft (2 m) triaxial cable that is terminated with a three-slot
male triaxial connector on one end and alligator clips on the other end.
This cable can allow exposed hazardous voltages when used in certain applications, and is
intended for use only by qualified personnel who recognize shock hazards and are familiar
with the safety precautions required to avoid possible injury. If an operator is using this
cable, a qualified person must provide training in electrical safety procedures and proper use
of the equipment and must ensure that the operator is protected from electric shock and
contact with hazardous live circuits. Refer to the complete user manual for the product being
used with this cable for complete cable configuration infor\-mation and additional safety
instructions.
Never touch or change connections when power is applied to the cable assembly. Always
turn off all power and discharge all capacitors before connecting or disconnecting the cable.
PA-298 Rev. D / June 2013
Figure 1: Model 237-ALG-2
*PA298D*
Model 237-ALG-2
Triaxial Cable
1
