As a Segment Switch

Power
Fault
Fast Ethernet Switch
hp procurve
switch 2650
J4899A
Act
Power FDx
Max
Fault
PCs, local servers,
and peripherals
LEGEND: Fast Ethernet cable
The Switch also works well as a segment switch. That is, with its high
performance, it can be used for interconnecting network segments—simply
connect the network hubs that form those segments to the switch, or you can
also connect other switches.
In the illustration above, two "Fast" Ethernet hubs with PCs, printers, and local
servers attached, are both connected to a Switch. The devices attached to the
two hubs can now communicate with each other through the switch. They can
also all communicate with the server that is connected to a 1000Base-T port
on the switch.
Servers with Gigabit
Ethernet NIC
HP ProCurve Switch 2824
Fast Ethernet Switch
hp procurve
switch 2650
J4899A
Power
Fault
Gigabit Ethernet cable
Sample Network Topologies
To backbone
Act
FDx
Max
PCs, local servers,
and peripherals
Installing the Switch
Server with
Gigabit Ethernet NIC
Fiber cable
2-25
