S20I / S20ID
F R E E S T A N D I N G G A S F I R E P L A C E
OWNER'S MANUAL
WARNING:
If the information in this manual is not followed exactly, a
fire or explosion may result causing property damage, personal injury
or loss of life. Installation and service must be performed by a qualified
installer, service agency or the gas supplier.
C#4001609
CERTIFIED TO: ANSI Z21.88 / CSA 2.33 VENTED GAS FIREPLACE HEATERS
50-3221
Version Française: www.enviro.com/fr.html
CSA 2.17 GAS FIRED APPLIANCES FOR HIGH ALTITUDES

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S20ID and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Enviro S20ID

Summary of Contents for Enviro S20ID

  • Page 1 S20I / S20ID F R E E S T A N D I N G G A S F I R E P L A C E OWNER’S MANUAL WARNING: If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life.

  • Page 2: Safety Precautions

    Safety Precautions WARNING: FIRE OR EXPLOSION HAZARD Failure to follow safety warnings exactly could result in serious injury, death, or property damage. - Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance. - WHAT TO DO IF YOU SMELL GAS •...
  • Page 3 NEVER ALLOW CHILDREN shut. TO TOUCH GLASS. • If the S20I / S20ID unit is pulled out of its installation, and A barrier designed to reduce the risk of burns from the the vent-air intake system is disconnected for any reason,...

  • Page 4: Table Of Contents

    Table of Contents Safety Precautions......................2 Table of Contents......................4 Codes And Approvals....................5 Specifications......................6 Dimensions.....................6 Rating Label Location..................6 Operating Instructions....................7 Lighting Instructions..................7 Air Shutter......................8 Normal Sounds During Operation..............8 Remote Control Operations.................8 Initializing the System for the First Time............11 Switching to Continuous Pilot Mode..............11 Fan Control......................13 Maintenance And Service.....................14 Routine Maintenance..................14...

  • Page 5: Codes And Approvals

    After the unit has gone through the first burn, turn the unit off including the pilot, let the unit get cold then remove the glass door and clean it with a good gas fireplace glass cleaner, available at your local ENVIRO dealer.

  • Page 6: Specifications

    5 1/8" 49.7 46.7 19 5/8" 18 3/8" 62.2 24 1/2" Figure 1. S20I/ S20ID Dimensions - Top Vent & L ating abeL ighting nstRuctions ocation The rating label and lighting instructions are located on rating plate the backside of stove.

  • Page 7: Operating Instructions

    Operating Instructions For Your Safety, Read Safety Precautions And Lighting Instructions Before Operating WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY A FIRE OR EXPLOSION MAY RESULT, CAUSING PROPERTY DAMAGE, PERSONAL INJURY OF LOSS OF LIFE. ighting anD uRning nstRuctions FOR YOUR SAFETY READ BEFORE OPERATING WARNING:...

  • Page 8: Air Shutter

    Table 1: Normal Sounds Component Sound & Reason S20I/ S20ID Creaking when heating up or cooling down. Burner Light pop or poof when turned off; this is more common with LP units. Temperature Sensor Clinking when it senses to turn the blower on or off.

  • Page 9: Remote Control Operations

    Operating Instructions For Your Safety, Read Safety Precautions And Lighting Instructions Before Operating For S20ID models refer to the separate Dexen user manual supplied for remote control operations. emote ontRoL peRations Proflame 2 is a modular remote control system that directs the functions of the Westport. The Proflame 2 TMFSLA is configured to control the on/off main burner operation, its flame levels and provides on/off and Smart thermostatic control of the appliance.
  • Page 10 Operating Instructions CPI Mode Figure 5: Proflame 2 Transmitter LCD Screen. (ifc): ntegRateD iRepLace ontRoLLeR The Proflame 2 IFC (Figure 6) connects directly to the gas valve, stepper motor, pilot and covection fan with a wiring harness. The IFC is mainly powered by 120 VAC but can also run off a battery backup four (4) AA type batteries for shorter periods of time.

  • Page 11: Initializing The System For The First Time

    Operating Instructions peRating RoceDuRe Initializing The System For The First Time Install the four (4) AA batteries into the IFC battery holder. Note the polarity of the battery and insert into the battery bay as indicated on the body of the battery holder. Press the reset button on the IFC marked “SW1” (see Figure 6). The IFC will “beep”...
  • Page 12 Operating Instructions Turn off the Appliance Press the ON/OFF Key on the Transmitter. The Transmitter LCD display Room Temperature will only show the room temperature and Icon (see Figure 9). A single “beep” from the IFC confirms reception of the command and both the pilot light (if the unit is not set to continuous pilot) and main burner will turn off.

  • Page 13: Fan Control

    Operating Instructions Fan Control The S20I comes with a convection fan that can be controlled with the Transmitter. The fan speed can be adjusted thorugh six (6) speeds. To control the fan press the MODE key (Figure 4) to index to the fan control icon (Figure 12).

  • Page 14: Maintenance And Service

    The glass must be purchased from an ENVIRO dealer. No substitute materials are allowed. Remove the door (see page 12). The replacement glass will come with a new gasket installed. Remove any silicone remnants from the door.

  • Page 15: Face Removal

    Maintenance And Service emovaL The Face on the S20I/ S20ID needs to be removed whenever access to the firebox is required. To remove the face loosen tow screws at the bottom of the face, then rotate the door as shown in Figure 16. The face is hooked on the frame at the top and will need to be rotated past 45 degrees until is is free.

  • Page 16: Burner Removal

    Maintenance And Service uRneR emovaL The burner may need to be removed for a few reasons, including cleaning under the burner, converting the unit to a different gas type, or to replace the burner altogether. Proceed only when the unit has completely cooled down.
  • Page 17 Maintenance And Service Conversion Kit Installation: 1. Turn the unit off by pressing the ON/OFF Key on the remote and shut off gas supply at the shut-off valve upstream of the unit. CAUTION: The gas supply must be shut off prior to disconnecting the electrical power and before proceeding with the conversion.
  • Page 18 Maintenance And Service 13. Relight the main burner in both the “HI” and “LO” positions to verify proper burner ignition, operation and proper flame appearance (figure 62, page 45). Confirm the inlet and manifold pressures are within the acceptable ranges as directed in section I ntIal ntallatIon onnectIon anD...

  • Page 19: Initial Installation

    • Locate the stove in a large and open room that is centrally located in the house. This will optimize heat circulation and comfort. • As the S20I / S20ID is equipped with a convection fan, ensure that an electrical outlet is within 6 ft (1.8 m) of the stove.

  • Page 20: Rear Vent Conversion

    QUALIFIED INSTALLERS ONLY onveRsion If desired, the S20I/ S20ID can be converted from a top vent to a rear vent unit by following the steps below. Note: When converted to rear vent the S20I/ S20ID has a smaller range of allowable venting, refer to before final installation.
  • Page 21 (see Figure 23). Re-install the back plate and tighten the four retaining screws. Finally, install the plate vent cover supplied with the S20I/ S20ID as shown in Figure 26. Figure 26. Vent Conversion - Step 4...

  • Page 22: Direct Vent

    The vent length for the S20I/ S20ID must be between 7” (18 cm) and 44ft (13.4 m). This model is vented with co-axial 4” intake, 6 5/8” exhaust aluminum or stainless steel approved rigid vent leading into a vertical or horizontal termination cap.
  • Page 23 Initial Installation QUALIFIED INSTALLERS ONLY EXCEPTION TO WARNING: This product has been evaluated by Intertek for using a DirectVent Pro starting collar in conjunction with venting brand names listed in table 4. Use of these systems with the DirectVent Pro starting collar is deemed acceptable and does not affect the Intertek listing of the appliance.

  • Page 24: Horizontal Termination - Rear Vent W/ No Rise

    QUALIFIED INSTALLERS ONLY oRizontaL eRmination ent with no eRticaL The S20I/ S20ID can be installed in rear vent applications with no vertical rise within the parameters as shown in Figures 28 and 29. Refer to the I section nItIal nstallatIon...

  • Page 25: Mobile Home Installation

    Initial Installation QUALIFIED INSTALLERS ONLY obiLe nstaLLation The S20I/ S20ID can be installed in a mobile home but must be securely fastened to the floor as directed below: • Remove the face as outlined in m aIntenance anD erVIce emoVal •...

  • Page 26: Vent Termination Restrictions

    Initial Installation QUALIFIED INSTALLERS ONLY eRmination estRictions Fixed Closed Fixed Openable Closed Openable Termination Cap Air Supply Inlet Gas Meter Restriction Zone (Termination not allowed) Figure 31. Vent Termination Restrictions, refer to Table 5. Table 5: Vent termination clearances. Letter Canadian Installation US Installation Description...

  • Page 27: Allowable Vent Configurations

    Initial Installation QUALIFIED INSTALLERS ONLY LLowabLe onfiguRations Figures 32.1 & 32.2 show the range of possible vent configurations if the unit is top or rear vented, for vertical and horizontal terminations. Any layout that remains within the shaded areas is acceptable. Having the fewest number of elbows is ideal, as they tend to disrupt air movement.

  • Page 28: Air Restrictor Settings

    When installing the S20I/ S20ID with 8ft (2.44M) or more of vertical venting it may be necessary to restrict the fresh air supply in the firebox to control the combustion and flame appearance. Using the pair of air restrictors supplied with the unit, install them on each side of the firebox and adjust to the correct setting as outlined in the figure and table below.

  • Page 29: Horizontal Termination

    Initial Installation QUALIFIED INSTALLERS ONLY oRizontaL eRmination NOTES: 1. Horizontal pipes must not be level. For every 12 inches (305 mm) of horizontal travel (away from the stove), there should be at least ¼ inch (6.4 mm) of vertical travel. Never allow the vent to run downward, as this could cause high temperatures or even present the possibility of a fire.

  • Page 30: Vertical Termination

    Initial Installation QUALIFIED INSTALLERS ONLY Step 4. With the hole now framed, the wall thimble installed, and the pipe extending into the wall, proceed to the outside. Attach the termination to the pipe using RTV and Mil-Pac or Rutland No 78 Stove and Gasket Cement to seal joints.
  • Page 31 Initial Installation QUALIFIED INSTALLERS ONLY STEP 5. Cut hole in the roof centered on the small hole placed in the roof from Step 2. The hole should be of sufficient size to meet minimum requirements for Clearance to Combustibles, as specified. Continue to assemble lengths of pipe and elbows necessary to reach from the ceiling support box up through the roof line.
  • Page 32 Initial Installation QUALIFIED INSTALLERS ONLY NOTES: (1) If an offset is necessary in the attic to avoid obstructions, it is important to support the vent pipe every 3 feet (914 mm), to avoid excessive stress on the elbows, and possible separation. Wall straps are available for this purpose (see Figure 37).

  • Page 33: Gas Line Connection And Testing

    Figure 39: Fully Labeled Gas Valve. required pressure test. See Dexen User Manual for S20ID valve details TO TEST VALVE PRESSURES The pressure taps are located on the top right of the valve shown in Figure 39. • Turn set screw 1 turn counter clockwise to loosen, ”...

  • Page 34: Electrical Requirements

    If any of the original wire as supplied with the appliance must be replaced, it must be replaced with 18 AWG wire with a temperature rating of 105°C Note: For S20ID specific wiring diagram refer to the Dexen user manual supplied and label attached to the fireplace.

  • Page 35: Secondary Installation

    Secondary Installation Rate anD nstaLLation The placement of the logs is not arbitrary. If they are positioned incorrectly, the flames can be “pinched” and will not burn correctly. All of the logs come with either a notch or ledge, which make alignment easier. Using the pictures provided, carefully set the logs in place (see Figures 41 through 47).
  • Page 36 Secondary Installation Step 3: Install the big y shaped twig on the far left side by locating the bottom of it on the far left log grate upright. The twig should run parallel with the side of the firebox and the top will rest on the top of the ember bed.
  • Page 37 A small amount on the bottom side of the logs is normal. Remove and replace the logs in the same manner described above. If new coal nuggets or logs are required, contact your nearest ENVIRO dealer. Never operate the fireplace with the glass door removed.

  • Page 38: Safety Screen Replacement

    The S20I/ S20ID is supplied with a safety screen already installed on the back of the face. If the safety screen becomes damaged must be replaced with part number 50-3070 following the steps below: Loosen Figure 48. Safety Screen Removal...

  • Page 39: Trouble Shooting

    Trouble Shooting s20iD iagnostic Lash oDes Does not appLy to moDeLs 1. Fail to ignite: If there is no positive ignition, the board will go into lock out and the LED will blink 3 times in intervals until the system is reset.
  • Page 40 Trouble Shooting Note: For S20ID specific troubleshooting refer to the Dexen user manual supplied Problem Possible Cause Solution The pilot flame has gone out Thermostat · Turn it ON does not The On/Off switch is turn to OFF work The thermostat is set too high ·...
  • Page 41 Troubleshooting Problem Possible Cause Solution · Turn the system off by pressing the ON/OFF button on the transmitter · After approximately 2 seconds press the ON/OFF button on the transmitter again. Locking Reset the Proflame IFC board · In the manual flame control mode, use the down arrow conditions button to reduce the flame to off, indicated by the word OFF displayed on the transmitter LCD screen.

  • Page 42: Parts List

    Parts List Note: For S20ID specific replacement parts refer to the Dexen user manual supplied Reference Part Description Part Number Number Door Release Tool 50-2510 Door Latch Mechanism w/ Spring (set of 2) 50-1285 Firebox Air Restrictors (set of 2)

  • Page 43: Parts Diagram

    Parts Diagram...

  • Page 44: Notes

    Notes...

  • Page 45: Warranty

    Sherwood Industries Ltd. (“Sherwood”) hereby warrants, subject to the terms and conditions herein set forth, this product against defects in material and workmanship An expanded list of exclusions is available at www.enviro.com/help/warranty.html during the specified warranty period starting from the date of original purchase at retail.

  • Page 46: Installation Data Sheet

    _________________________________________ _________________________________________ NATURAL GAS (NAT) PROPANE(LPG) _________________________________________ INLET GAS PRESSURE:_________in wc PHONE:___________________________________ MAIN BURNER ORIFICE:__________# DMS PILOT ORIFICE #_________OR________in diam. INSTALLER’S SIGNATURE: _________________________________________ MANUFACTURED BY: SHERWOOD INDUSTRIES LTD. 6782 OLDFIELD RD. SAANICHTON, BC, CANADA V8M 2A3 www.enviro.com Winter 2021 C-15104...
