  • Page 1 AeGIS NPB9000P Installation and Programming Manual REV. 0620-11...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Limitations of Liability Chapter 1. Getting Started ..................... 1 1.1. Introduction ..........................1 1.2. System Description, Specifications and Accessories ..............1 1.3 Unpacking the System ......................... 3 1.4 Warranty ............................3 Chapter 2. Installation ....................4 Chapter 3. Programming ....................9 Programming Function Codes ..................
  • Page 4 Chapter 5. Trouble Shooting Guide ................37 General FCC Requirements ................... 40 Quick Guide ........................41...

  • Page 5: Limitations Of Liability

    Pach and Company does not assume any liability for any damages, which may arise in installation or use of the AeGIS NPB9000P Series. Pach and Company does not assume liability for any incompatibility between the AeGIS NPB9000P Series and users devices.

  • Page 6: Chapter 1. Getting Started

    Systems with optional 26 Bit Wiegand Proximity Reader or Radio Reader with remote or local programming via software. The manual is designed to guide you through the proper programming and use of the AeGIS NPB9000P Series. It is impor- tant for you to read and follow the manual completely.

  • Page 7: 1.3 Unpacking The System

    Cable Distance: 500 feet maximum. Dimension: 5.0” x 1.6” x 0.75” (HWD) 26 Bit Wiegand Radio Reader (AWRR) Power Input: 5.0 VDC Regulated (Power by the AeGIS NPB9000P Series +5VDC regulated) or 6.0 - 24 VDC Unregualted (not supplied). Transmit Frequency: 318 Mhz.

  • Page 8: Warranty

    10. Pach and Company is not responsible for time, travel, and/or labor costs of any distributor and/or dealer-installer, including but not limited to, any expenses to install, uninstall or reinstall hardware/software/firmware related to warranty issues, product enhancements, or product failures. Pach and Company Chapter 1 Page 3 AeGIS NPB9000P Series GETTING STARTED 06/20/11...
  • Page 9 NEW PRODUCT WARRANTY EXCEPTION WIEGAND CARD, KEYFOB AND TRANSMITTER Pach and Company warrants the wiegand card, clam, and keyfob to be free of defects in material or workmanship for a period of three (3) months from the date of invoice. The above warranty is subject to the following conditions. 1.
  • Page 10 written authorization from Pach and Company Technical Department, with such authorization given only to manufac- turer approved dealer/installers. 4. Under no circumstances will Pach and Company honor warranty any product found to have been altered, repaired, and/or modified by the end-user consumer. 5.
  • Page 11 7. Return Merchandise Authorization (RMA) numbers will not be issued to the end-user consumers. Consumers must contact their selling dealer-installer for any/all warranty issues. 8. Distributor and/or Dealer-Installer are responsible for all shipping charges, incl. freight and insurance fees, for products shipped to Pach and Company repair center.

  • Page 12: Chapter 2. Installation

    Chapter 2 INSTALLATION Figure 2.1 Pach and Company Chapter 2 Page 4 AeGIS NPB9000P Series INSTALLATION 06/20/11...
  • Page 13 Figure 2.2 Pach and Company Chapter 2 Page 5 AeGIS NPB9000P Series INSTALLATION 06/20/11...
  • Page 14 Figure 2.3 Pach and Company Chapter 2 Page 6 AeGIS NPB9000P Series INSTALLATION 06/20/11...
  • Page 15 Relay 6 (61-72 tenants) Relay 7 (73-84 tenants) Relay 8 (85-96 tenants) Relay 9 (97-108 tenants) Relay 10 (109-120 tenants) Table 2.1 MS79012 - MS7910, MX79012 - MX79120 DIP SWITCHES SETTING Pach and Company Chapter 2 Page 7 AeGIS NPB9000P Series INSTALLATION 06/20/11...
  • Page 16 0019 0043 0991 0020 0044 0992 0021 0045 0993 0022 0046 0994 0023 0047 0995 0024 0048 0996 Table 2.3 The Relay Number Correlation with 4-digit Phone Number Pach and Company Chapter 2 Page 8 AeGIS NPB9000P Series INSTALLATION 06/20/11...

  • Page 17: Chapter 3. Programming

    Chapter 3 PROGRAMMING The AeGIS NPB9000P Series can be programmed locally using the built-in keypad or RS-232 via the Pach and Company Management Software or remotely via the Pach and Company Management Software (see the CD for Manual). 3.1 LOCAL PROGRAMMING VIA BUILT-IN KEYPAD...

  • Page 18: Replace System Master Code

    Unlock Time for Door 1 and Door 2. Step 3 Enter 1 for relay 1 (door 1) or 2 for relay 2 (door 2) then press #, the display shows Pach and Company Chapter 3 Page 10 AeGIS NPB9000P Series PROGRAMMING 06/20/11...

  • Page 19: Lock Out Count

    If more than one systems are on the same phone line, you must set each system to MULTI. Step 3 Enter 1 for SINGLE or 0 for MULTI, then press #, the display shows Pach and Company Chapter 3 Page 11 AeGIS NPB9000P Series PROGRAMMING 06/20/11...

  • Page 20: System Id

    #, the display shows Step 4 Select another Function Code to program different field from the table or press * to exit the programming mode. Pach and Company Chapter 3 Page 12 AeGIS NPB9000P Series PROGRAMMING 06/20/11...

  • Page 21: Alarm Telephone Number

    Step 2 Enter Function Code 11 then press # and the display shows display. A total 48-characters (16 - characters for each segment) can be programmed for the welcome message. Pach and Company Chapter 3 Page 13 AeGIS NPB9000P Series PROGRAMMING 06/20/11...
  • Page 22 Press 0 for space (move cursor to the right. Press 8 then 0 for back space (move cursor to left) Press * to clear all letters or numbers entered FIGURE 3.1 Pach and Company Chapter 3 Page 14 AeGIS NPB9000P Series PROGRAMMING 06/20/11...

  • Page 23: Set Time And Date

    0 if it is NOT CORRECT, return to step 5 Step 8 The display shows Step 9 Select another Function Code to program different field from the table or press * to exit the programming mode. Pach and Company Chapter 3 Page 15 AeGIS NPB9000P Series PROGRAMMING 06/20/11...

  • Page 24: Time Zone

    Step 2 Enter Function Code 14 then press # and the display shows schedules up to date every year. If holiday schedule (s) is pro- grammed, Time Zone Schedule(s) (TMZ) , Auto Unlock Pach and Company Chapter 3 Page 16 AeGIS NPB9000P Series PROGRAMMING 06/20/11...

  • Page 25: Auto Unlock Schedule

    2 is set as door control (mode 1) on Function Code 08, proceed to step 5 if relay 2 is set other than mode 1, proceed to step 6 Pach and Company Chapter 3 Page 17 AeGIS NPB9000P Series PROGRAMMING 06/20/11...

  • Page 26: Reinitialize Time Zones Schedules

    Step 3 Press 1 for YES or 0 for NO then press #, the display shows Step 4 Select another Function Code to program different field from the table or press * to exit the programming mode. Pach and Company Chapter 3 Page 18 AeGIS NPB9000P Series PROGRAMMING 06/20/11...

  • Page 27: Reinitialize Auto Unlock Schedules

    Step 3 Press 1 for YES or 0 for NO then press #, the display show Step 4 Select another Function Code to program different field from the table or press * to exit the programming mode. Pach and Company Chapter 3 Page 19 AeGIS NPB9000P Series PROGRAMMING 06/20/11...

  • Page 28: New Tenant Code

    # after entering each character and press ## after entering the last character (see figure 3.1 for keypad correlation), the display shows Step 5 Enter a 4-digit relay number then press enter, the display shows Pach and Company Chapter 3 Page 20 AeGIS NPB9000P Series PROGRAMMING 06/20/11...

  • Page 29: Delete A Tenant Code

    Step 3 Enter 1 for YES then press # to continue the display shows proceed to step 4 or 0 for NO then press # to cancel and proceed to step 5 Step 4 Enter 5 and the display shows Pach and Company Chapter 3 Page 21 AeGIS NPB9000P Series PROGRAMMING 06/20/11...

  • Page 30: Card And Code

    PROGRAMMED REMOTELY VIA SOFTWARE NOT FUNCTION CODE 25. Step 4 Select another Function Code to program different field from the table or press * to exit the programming mode. Pach and Company Chapter 3 Page 22 AeGIS NPB9000P Series PROGRAMMING 06/20/11...

  • Page 31: Rs-232 Or Modem

    Step 4 Select another Function Code to program different field from the table or • Trigger relay 2 if set for MODE 2 (A press * to exit the programming mode. SHUNT) (00-90 seconds). Pach and Company Chapter 3 Page 23 AeGIS NPB9000P Series PROGRAMMING 06/20/11...

  • Page 32: Add Keypad Access Code And Card Number

    Step 9 Enter the name up to 12 characters then press #, the display shows Step 10 Select another Function Code to program different field from the table or press * to exit the programming mode. Pach and Company Chapter 3 Page 24 AeGIS NPB9000P Series PROGRAMMING 06/20/11...

  • Page 33: Modify Keypad Access Code And Card Number

    Step 8 Enter 1=YES then press # and proceed to step 6 or 0=NO then press # and the display shows Step 9 Enter the name up to 12 characters then press #, the display shows Pach and Company Chapter 3 Page 25 AeGIS NPB9000P Series PROGRAMMING 06/20/11...

  • Page 34: Delete Keypad Access Code And Card Number

    4 Or Enter 0=NO then press # and proceed to step 5. Step 4 Press 5 to clear all keypad access codes and card numbers, the display shows Pach and Company Chapter 3 Page 26 AeGIS NPB9000P Series PROGRAMMING 06/20/11...

  • Page 35: Master Code Mask

    * to exit the programming mode. NOT APPLICABLE FOR NON SUBSCRIBER (NPB 9000 SERIES) ENABLE OR DISABLE PBX (Default setting is disabled) NOT APPLICABLE FOR NON SUBSCRIBER (NPB 9000 SERIES) Pach and Company Chapter 3 Page 27 AeGIS NPB9000P Series PROGRAMMING 06/20/11...

  • Page 36: Open Door 1 And Door 2 Number

    Enter (0-9) then press # , the proceed to step 5 display shows proceed to step 5. If the number is already used, the display shows re-enter the number. Pach and Company Chapter 3 Page 28 AeGIS NPB9000P Series PROGRAMMING 06/20/11...

  • Page 37: Display System Information

    Step 1 Log on to programming mode (see section 3.1). The display shows VIEW DIRECTORY AND NAME Step 2 Enter Function Code 78 then press # and the display shows NNNNNNNNNNN= tenant name Pach and Company Chapter 3 Page 29 AeGIS NPB9000P Series PROGRAMMING 06/20/11...
  • Page 38 5 or press * and the display shows Step 5 Select another Function Code to program different field from the table or press * to exit the programming mode. Pach and Company Chapter 3 Page 30 AeGIS NPB9000P Series PROGRAMMING 06/20/11...

  • Page 39: Chapter 4. System's Operation

    Step 4 Tenant must press 9 (default setting to unlock relay 1 (door 1)) or 8 (default setting to unlock relay 2 (door 2)). Pach and Company Chapter 4 Page 31 AeGIS NPB9000P Series SYSTEM’S OPERATION 06/20/11...
  • Page 40 NOTE: If invalid card access is used more than the number program on Function Code 03, the display shows If a telephone number is programmed on Function Code 09, the display shows ALARM ACTIVATED and will call the number Pach and Company Chapter 4 Page 32 AeGIS NPB9000P Series SYSTEM’S OPERATION 06/20/11...
  • Page 41 "8" on his or her phone to open relay 2 (door 2) remotely. The connection to the door strike is identical as relay 1 (see figure 2.1 for AeGIS NPB9000 wiring diagram). Pach and Company Chapter 4 Page 33 AeGIS NPB9000P Series SYSTEM’S OPERATION 06/20/11...
  • Page 42 • Or door 1or door 2 is forced open. If Function Code 09 is programmed to call a phone number, the system will • Make double beeps every 60 seconds. • Call to the number programmed on Function Code 09 every 60 Pach and Company Chapter 4 Page 34 AeGIS NPB9000P Series SYSTEM’S OPERATION 06/20/11...
  • Page 43 The authorized person will hear continuous beeps when the phone is answered. The display shows ALARM ACTIVATED The scenarios above are valid until the problems are corrected. Pach and Company Chapter 4 Page 35 AeGIS NPB9000P Series SYSTEM’S OPERATION 06/20/11...
  • Page 44 XXXX= total number of tenant programmed NOTE: A directory without a tenant name will not be counted in the total number of tenant. Pach and Company Chapter 4 Page 36 AeGIS NPB9000P Series SYSTEM’S OPERATION 06/20/11...
  • Page 45 140 °F. • If the display only fails when the outside temperature is below 32°F or 0°C, you may need to install a heater (AHP-5). Pach and Company Chapter 5 Page 37 AeGIS NPB9000P Series TROUBLE SHOOTING GUIDE 06/20/11...
  • Page 46 • The tenant phone may not tolerate with the system ring, you may have to TENANT PHONE DOES NOT try different phone. RING • Too many phone is connected to the same phone line. • Bad Main Relay Control Panel. Pach and Company Chapter 5 Page 38 AeGIS NPB9000P Series TROUBLE SHOOTING GUIDE 06/20/11...
  • Page 47 The technical support team at Pach and Company are highly trained and committed to providing you with the best in support and repair services. Our Services are available between 7:30AM - 3:30PM TOLL FREE (888) 678-7224. Pacific Standard Time. Pach and Company Chapter 5 Page 39 AeGIS NPB9000P Series TROUBLE SHOOTING GUIDE 06/20/11...
  • Page 48 GENERAL FCC REQUIREMENTS This equipment complies with Part 68 of the FCC rules. Located on the back of your AeGIS system is a label that contains, among other information, the FCC registration and ringer equivalence number (REN) for the system. Prior to installing your AeGIS system, please call your telephone company and provide them the FCC registration and REN numbers as well as the telephone number of the line to which you will connect the system.
