Altronix AL400ULPD8CB Installation Manual page 12

Enclosure Dimensions (BC400):
AL400ULXX, AL400ULXXR, AL400ULXPD4, AL400ULXPD4CB,
AL400ULXPD8, AL400ULXPD8CB, AL400ULXPD16, AL400ULXPD16CB
15.5" x 12" x 4.5" (393.7mm x 304.8mm x 114.3mm)
1.25"
4.5" (114.3mm)
(31.8mm)
1.5"
(38.1mm)
2.0"
(50.8mm)
2.0"
(50.8mm)
1.25" (31.8mm)
Altronix is not responsible for any typographical errors.
140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056
website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty | Made in U.S.A.
IIAL400ULX Series
- 12 -
1.5"
4.615" (117.2mm)
(38.1mm)
12.23" (310.6mm)
1.1" (27.9mm)
1.5"
4.615" (117.2mm)
(38.1mm)
1.5"
4.615" (117.2mm)
(38.1mm)
1.1" (27.9mm)
1.1" (27.9mm)
1.5"
4.615" (117.2mm)
(38.1mm)
G06U
1.75"
(44.5mm)
4.5" (114.3mm)
1.375"
(34.9mm)
1.125"
(28.6mm)
1.25" (31.8mm)
1.75"
(44.5mm)
1.25"
(31.8mm)
1.5"
(38.1mm)
MEMBER
AL400ULX Series
