  • Page 1 PRO-RT 2U Series UPS User's Manual Para Systems, Inc. 1455 Lemay Dr. Carrollton, TX 75007 Phone: 1-972-446-7363 Fax: 1-972-446-9011 Internet: minutemanups.com UPS Sizing: sizemyups.com PN - 34000526 R3...
  • Page 2: Table Of Contents

    Introduction Controls and Indicators Installation Operation Obtaining Service Troubleshooting Replacing the Battery Specifications Limited Product Warranty A1. Declaration of Conformity...
  • Page 3: Introduction

    Chapter 1: Introduction CAUTION! This UPS series is ONLY intended to be installed in an indoor temperature controlled environment that is free of conductive contaminants. Thank you for purchasing this power protection product. It has been designed This UPS series is not intended for use in a computer room as defined in the and manufactured to provide many years of trouble free service.
  • Page 4 CAUTION! To reduce the risk of electrical shock in conditions where the load CAUTION! DO NOT USE THE MOUNTING BRACKETS TO LIFT THE equipment grounding cannot be verified, disconnect the UPS from the AC wall UPS. The mounting brackets are ONLY for securing the UPS to the rack. outlet before installing a computer interface cable.
  • Page 5  Relocate the computer with respect to the receiver. by Para Systems, Inc. (“Para Systems”). The Manual can only be applied to  Move the computer away from the receiver.
  • Page 6: Controls And Indicators

    Chapter 2: Controls and Indicators Load Capacity Bar Graph: Displays the amount of load connected to the UPS in the AC and Battery mode as 20%, 40%; 60%, 80%, 100%. CONTROL PANEL When the amount of load attached to the UPS exceeds 110% of its power rating;...
  • Page 7: Installation

    REAR PANEL Chapter 3: Installation INSTALLATION PLACEMENT This UPS series is ONLY intended to be installed in an indoor temperature controlled environment that is free of conductive contaminants. DO NOT oper- ate the UPS in: extremely dusty and/or unclean areas, locations near heating devices, water or excessive humidity, or where the UPS is exposed to direct sunlight.
  • Page 8 CONNECTING THE BATTERIES RACKMOUNT CONFIGURATION (QUALIFIED SERVICE PERSONNEL ONLY) This UPS series comes with mounting brackets for the standard 19" (46.5cm) Please read all of the WARNINGS and CAUTIONS before attempting to con- rack pre-installed on the UPS. The mounting brackets to fit a 23" (59.2cm) nect the batteries.
  • Page 9 TOWER CONFIGURATION 2. The LCD panel can be rotated to read in the up-right position. There is a small The tower configuration allows the user to install the UPS in the up-right position. slot on each side of the LCD panel. Insert a small flat head screwdriver into one The tower brackets are provided with the UPS.
  • Page 10 CONNECTING YOUR EQUIPMENT USB COMMUNICATIONS PORT CONNECTION (OPTIONAL) Plug the equipment into the output receptacles on the rear panel of the UPS. The power monitoring software and interface cable can be used with the UPS. Ensure that you do not exceed the maximum output rating of the UPS (refer to Use only the interface cable that comes with these UPSs.
  • Page 11: Operation

    Chapter 4: Operation TURNING THE UNIT ON/OFF On / Off / Test Button SYSTEM OVERVIEW This Line-Interactive UPS protects computers, servers, telecom systems, VoIP When the UPS is connected to an AC source and there is an acceptable AC volt- systems, security systems, and a variety of electronic equipment from black- age present;...
  • Page 12 ALARMS The LCD screen will include dedicated icons for the following information: AC Mode / AVR Mode (Boost and Buck: The AC mode icon will flash) ON BATTERY On-Battery When the UPS is operating on the batteries, the AC mode icon will extinguish, Weak/Bad Battery the On-Battery icon will illuminate, the LCD will display the estimated runtime UPS Fault...
  • Page 13: Obtaining Service

    Error Code: E07. Low The UPS's battery reserve is low. This condition will Battery Warning. continue until AC returns or the UPS shuts down from Para Systems Inc. battery exhaustion. MINUTEMAN UPS 1809 W. Frankford Road, Suite 150 Error Code: E08. SWF...
  • Page 14: Replacing The Battery

    CAUTION: The battery system can present a risk of electrical shock. These Chapter 7: Replacing the Battery batteries produce sufficient current to burn wire or tools very rapidly, produc- ing molten metal. Observe these precautions when replacing the batteries: REPLACING THE BATTERY 1.
  • Page 15 BATTERY REPLACEMENT PROCEDURE FIG. 2 PLEASE READ THE CAUTIONS AND WARNINGS BEFORE ATTEMPTING TO REPLACE THE BATTERIES Hot-swappable batteries mean that the batteries can be replaced without pow- ering down the whole UPS system. NOTE: If there is a power interruption while replacing the hot-swappable batter- ies, with the UPS on, the load will not be backed up.
  • Page 16: Specifications

    Chapter 8: Specifications BATTERY SYSTEM Battery Type Sealed, Non-Spillable, Maintenance Free, Value Regulated Lead Acid SYSTEM SPECIFICATIONS Typical Recharge Time 8-hours to 90% capacity from a full load discharge Typical Battery Life 3 to 5 years. Environmental factors do affect battery life. High Model Number PRO1500RT2U PRO2000RT2U...
  • Page 17: Limited Product Warranty

    This warranty gives you specific legal rights and you may also have other rights which vary from state to state. No employee, salesman, or agent of Para Systems is authorized to add to or vary the terms of this warranty.
  • Page 18 Notes: Notes:...
