ED10000T & ED10200T
Parallel Redundant
ON-LINE SERIES
User's Manual
Para Systems, Inc.
1455 LeMay Drive
Carrollton, TX 75007
Phone: 1-972-446-7363
Fax: 1-972-446-9011
Internet: minutemanups.com
UPS Sizing: sizemyups.com
PN – 34000356 R3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Minuteman ED10000T and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Para systems Minuteman ED10000T

  • Page 1 ED10000T & ED10200T Parallel Redundant ON-LINE SERIES User’s Manual Para Systems, Inc. 1455 LeMay Drive Carrollton, TX 75007 Phone: 1-972-446-7363 Fax: 1-972-446-9011 Internet: minutemanups.com UPS Sizing: sizemyups.com PN – 34000356 R3...
  • Page 2: Table Of Contents

    Table of Contents 1 Important Safety Instructions........... 2 1.1 An Important Notice............... 2 1.2 Life Support Policy ..............3 1.3 FCC Notice................3 2 Product Introduction ..............4 2.1 System Overview..............4 2.2 General Characteristics............4 2.3 Symbols on the LCD Display Panel ........5 2.4 Controls and Indicators ............
  • Page 3: Important Safety Instructions

    1.1.11 SAVE THESE INSTRUCTIONS - This manual contains important 1 Important Safety Instruction instructions that should be followed during the Installation and the Maintenance of the UPS and batteries. 1.1. An Important Notice 1.1.12 CAUTION - A disconnect switch must be provided by the user for the AC 1.1.1 To ensure safety in all applications where a UPS system is hardwired to output circuit when the UPS’s output is hardwired.
  • Page 4: Product Introduction

    2 Product Introduction 2.2.9 The temperature-controlled fans will extend the life of the fans and reduce the annoying noise caused by fans. 2.1. System Overview 2.3. Symbols on the LCD Display Panel This On-Line UPS protects computers, servers, internetworking, and telecommunications equipment from blackouts, brownouts, overvoltages, and Item Symbol...
  • Page 5 Er06 Output Short Circuit ON and Alarm Silencer Switch Er08 DC Bus high-voltage-level abnormal OFF Switch Er09 DC Bus low-voltage-level abnormal Previous Page or Setting Change Er10 Inverter Over-current Next Page Er11 UPS Overheated Special Function Log in /out Er12 Inverter Overload Enter or Reconfirmed Er13...
  • Page 6: Controls And Indicators

    2.4. Controls and Indicators Bypass Input found when running on CVCF Er24 2.4.1 UPS Control panel mode (CVCF mode not supported) Er26 PFC Over-current The UPS must be operated in normal mode in Er27 parallel system Er28 Bypass Overload Time out and cut off output. Er29 Charger overcharges battery (>300Vdc) Er30...
  • Page 7: Rear Panels

    Since the manufacturer is not responsible for shipping damage Thermal Circuit Breaker (CB3) for output isolation transformer protection (Only on incurred when the system is returned, the original packing material is model ED10000T) inexpensive insurance. Terminal Block for Input/Output Connections.
  • Page 8: Installation Placement

    3.2. 3.4. Installation Placement Installation of the Caster Covers This UPS system is intended to be install in a temperature controlled 3.4.1 Lock the casters so that the unit will not move. 3.4.2 Step 1: There are two A1 cover plates, one for each side of the unit. Insert environment that is free of conductive contaminants.
  • Page 9: Wiring The Input And Output Connections

    22.1lb-in of torque force when connecting to the terminal blocks. 3.5.1.1.1 OUTPUT connections for ED10000T Hardwired only: Configurations #1 – #7 are for Hardwiring the output of ED10000T. A Qualified 3.5.1.1.3 Configuration # 2: Electrical Contractor must perform the hardwiring. The outputs must be Output: One 120VAC 10KVA circuit.
  • Page 10 3.5.1.1.4 Configuration # 3: 3.5.1.1.6 Configuration # 5: Output: One 208VAC 10KVA circuit. Total output load not to exceed 10KVA. Output: Two 120VAC circuits (5KVA max load per circuit). and one 208VAC 1. Connect a jumper wire from L22 to N21. 10KVA circuit.
  • Page 11: Operation And Setup Instructions

    3.5.2 A Qualified Electrical Contractor must perform the hardwiring when 3.6. Operation and Setup Instructions connecting the Input and Output wires to the terminal block on the ED10200T UPS. Apply 22.1lb-in of torque force when connecting to the 3.6.1 Startup in the Normal Mode terminal blocks.
  • Page 12 3.6.1.6 The UPS will perform another self-test and the LCD display will change 3.6.1.7 The UPS has successfully passed the start-up procedure. The UPS will from drawing C to drawing D. During the self-test the UPS will switch to charge the batteries whenever the UPS is connected to an AC source and the Battery mode for approximately 4-seconds, then the LCD display will there is an acceptable AC voltage present.
  • Page 13 * It shows the UPS is providing power to the “load”. * It shows the input frequency from the Bypass Input. 3.6.3 Measured Values detected by UPS 3.6.3.1 If you would like to check the measured values detected by the UPS, please use the scroll down and scroll up keypads.
  • Page 14 * It shows the Internal Temperature of the UPS System. * It shows the Self-test is “Disabled”. 3.6.4 UPS Default Data and Special Function Features 3.6.4.1 Once the UPS has successfully started up, press the Special Function keypad to change the LCD display screen to drawing Q1. * It shows the Self-test is “Enabled”.
  • Page 15 * It shows the Inverter Output Voltage setting. * It shows that this UPS is the first UPS in the parallel systems. 3.6.4.3 Press the scroll up keypad to change the default setting. The settings includes Buzzer ON (as drawing Q1), or Buzzer OFF (as drawing Q2, Alarm silence for UPS Warning) and self-test OFF (as drawing R1) or Self- test ON (as drawing R2).
  • Page 16 3.6.7 Turning Off the UPS 3.6.5.10 When all of the setting changes are complete, press the enter keypad to save all the changes. Then the LCD screen will display drawing Z, then the LCD screen will change to drawing AA to confirm the changes. If you 3.6.7.1 Press the Off switch for approximately 5-seconds, the Inverter will turned off, the UPS will transfer to the Bypass mode and the LCD screen...
  • Page 17: Communication Port, Epo Port And Option Cards

    3.6.8.1.12 Press and hold the On Switch (on the front panel of the UPS) for DC Mode Operation: approximately 3-seconds, then release. The audible alarm will sound 2- While the UPS is in the DC mode apply the short to pin1 and pin2 for beeps.
  • Page 18: Troubleshooting Guide

    6 Troubleshooting Guide 7 Replacing the Batteries (QUALIFIED SERVICE PERSONNEL ONLY) If the UPS malfunctions, check the followings: Please read all of the WARNINGS and CAUTIONS before attempting to a. Is the wiring of the input and the output correct? service the batteries.
  • Page 19: Battery Replacement Procedure

    7.1. 7.1.10 Looking from the front of the UPS on the right-hand side (FIG. 3), Battery Replacement Procedure disconnect the battery positive (Red) wire. Place a piece of electrical tape (QUALIFIED SERVICE PERSONNEL ONLY) over the end of battery positive (Red) wire. This UPS system does not have Hot-swappable batteries.
  • Page 20 7.1.21 Looking from the front of the UPS on the left-hand side (FIG. 4), disconnect 7.1.32 Back to the right-hand side of the UPS (FIG. 3), remove the piece of the battery negative (Black) wire. Place a piece of electrical tape over the electrical tape from the end of battery positive (Red) wire.
  • Page 21: Specifications

    8 Specifications BATTERY ED10000T ED10200T MODEL Sealed, Non-Spillable, Maintenance Free, Type (Has an internal Galvanic Valve Regulated, Lead Acid isolation step-down Typical Recharge Time 8-hours from total discharge transformer) Topology Double Conversion On-Line, True Sine Wave 3 - 5 years, depending on the number of charge...
  • Page 22: Obtaining Service

    MINUTEMAN United States and Canada, this warranty covers repair or replacement of defective equipment at the discretion of Para Systems. Repair will be from the nearest Technical Support at the following numbers; Voice phone (972) 446-7363, authorized service center.
  • Page 23: Declaration Of Conformity

    Application of Council Directive(s): 89/336/EEC, 73/23/EEC Standard(s) to which Conformity is declared: EN62040-1-1, EN62040-2, EN61000-3-2, EN61000-3-3, UL 1778, cUL (CSA 22.2 no. 107.1) Manufacturer’s Name: Para Systems, Inc. (MINUTEMAN UPS) Manufacturer’s Address: 1455 LeMay Drive Carrollton, Texas 75007 USA Type of Equipment: Uninterruptible Power Supplies (UPS...
