Summary of Contents for Para systems Minuteman Encompass EC1000RT2U
- Page 1 Encompass RT On-Line UPS Series User's Manual Para Systems, Inc. 1455 Lemay Dr. Carrollton, TX 75007 Phone: 1-972-446-7363 Fax: 1-972-446-9011 Internet: minutemanups.com UPS Sizing: sizemyups.com PN - 34000519 R3...
-
Page 2: Table Of Contents
Table Of Contents Introduction Controls and Indicators Installation Operation Configurable Parameters & Settings Obtaining Service Troubleshooting Replacing the Battery Specifications Limited Product Warranty A1. Declaration of Conformity... -
Page 3: Introduction
Chapter 1: Introduction CAUTION! This UPS series is ONLY intended to be installed in an indoor temperature controlled environment that is free of conductive contaminants. This UPS series is not intended for use in a computer room as defined in the Thank you for purchasing this power protection product. - Page 4 Manual at any time without obligation to notify any person of such revision Shielded communications interface cables must be used with this product. or changes. Para Systems will make all possible efforts to secure the accu- racy and the integrity of this Manual. Para Systems disclaims any kinds or WARNING:...
-
Page 5: Controls And Indicators
Chapter 2: Controls and Indicators 1. Displays the power flow of the UPS: AC Mode Power Flow Bypass Mode Power Flow Battery Mode Power Flow 1. The ON button is to turn the UPS on. Pressing the ON button during the 2. -
Page 6: Installation
REAR PANEL Input Power Plug Model # Output Power Receptacles (All power cords are 10ft) NEMA 5-15P EC1000RT2U 6-NEMA 5-15R (Controllable) EC1500RT2U NEMA 5-15P 6-NEMA 5-15R (Controllable) EC2000RT2U NEMA 5-20P 6-NEMA 5-15/20R (Controllable) 6-NEMA 5-15/20R (Controllable) EC3000RT2U NEMA L5-30P 1-NEMA L5-30R (Always On) Chapter 3: Installation INSTALLATION PLACEMENT This UPS series is ONLY intended to be installed in an indoor temperature con-... - Page 7 RACKMOUNT CONFIGURATION CONNECTING THE BATTERIES (QUALIFIED SERVICE PERSONNEL ONLY) This UPS series comes with mounting brackets for the standard 19" (46.5cm) Please read all of the WARNINGS and CAUTIONS before attempting to con- rack pre-installed on the UPS. There are optional Rail Kits for the 4-post nect the batteries.
- Page 8 TOWER CONFIGURATION CONNECTING YOUR EQUIPMENT The tower configuration allows the user to install the UPS in the up-right posi- Plug the equipment into the output receptacles on the rear panel of the UPS. tion. The tower brackets are provided with the UPS. WARNING: Use two or Ensure that you do not exceed the maximum output rating of the UPS (refer to more people when installing the UPS, the UPS is extremely heavy.
-
Page 9: Operation
The UPS will charge the batteries when the UPS is in the on or off position as COMMUNICATIONS PORT CONNECTION (OPTIONAL) long as the UPS is plugged into the wall outlet and there is an acceptable AC The Power Monitoring Software and interface cables can be used with the voltage present (55V (load dependent) - 150VAC). - Page 10 EMERGENCY POWER OFF (EPO) FUNCTION TURNING THE UNIT ON/OFF Connect one end of a two (2) wire cable to the EPO port on the rear panel of Turning the unit On the UPS and the other end of the two (2) wire cable to an EPO switch. To When the UPS is connected to an AC source and there is an accept- shutdown the UPS in the AC or the Battery mode short pin1 to pin2 for ap- able AC voltage present;...
- Page 11 ALARMS Chapter 5: Configurable Parameters and Settings ON BATTERY When the UPS is operating on the batteries, the On-Battery icon will illumi- (These items may require optional software or hardware) nate, the Utility power LED (Green) will extinguish and the audible alarm will sound one beep every ten-seconds.
-
Page 12: Obtaining Service
6. Return the unit by insured, prepaid carrier to: The UPS has an internal fault. Call for service. Er29: Charger overcharges the battery. Para Systems Inc. Er38: Failed to synchronize Turn the UPS off, unplug the power cord, wait for 5-minutes and MINUTEMAN UPS with utility input. -
Page 13: Replacing The Battery
Chapter 8: Replacing the Battery BATTERY REPLACEMENT PROCEDURE PLEASE READ THE CAUTIONS AND WARNINGS BEFORE ATTEMPTING QUALIFIED SERVICE PERSONNEL ONLY TO REPLACE THE BATTERY MODULE Hot-swappable batteries mean that the battery modules can be replaced with- Please read all of the WARNINGS and CAUTIONS before attempting to ser- out powering down the whole UPS system. -
Page 14: Specifications
10.Grasp the battery pull tab and gently pull the battery module out of the UPS Chapter 9: Specifications and set it aside. (FIG. 3) NOTE: Use Caution, the battery module is heavy. SYSTEM SPECIFICATIONS 11. Slide the new battery module into the UPS. 12.Re-install the battery retaining bracket. -
Page 15: Limited Product Warranty
(Conforms to UL1778 5th Edition & CSA 22.2 no. 107.3-14 / Safety and Approvals R: 2014), FCC Class A, CE certified, Energy Star certified, RoHS2 No employee, salesman, or agent of Para Systems is authorized to add to or vary the (EU Directive 2011/65/EU) terms of this warranty. -
Page 16: A1. Declaration Of Conformity
Standard(s) to which Conformity is declared: EN62040-2, IEC61000-2-2 IEC61000-4-2, IEC61000-4-3, IEC61000-4-4, IEC61000-4-5, IEC61000-4- 6, IEC61000-4-8, UL1778, CSA 22.2 no. 107.3-14, FCC Class A Manufacturer’s Name: Para Systems, Inc. (MINUTEMAN UPS) Manufacturer’s Address: 1455 LeMay Drive Carrollton, Texas 75007 USA Type of Equipment: Uninterruptible Power Supplies (UPS)
