130 Arm
COMPONENT CHECKLIST
A
Monitor Arm
(x1)
C
Post Clamp
(x1)
IMPORTANT INFORMATION
! Please ensure this product is installed as per these installation instructions.
! The manufacturer accepts no responsibility for incorrect installation.
! This product is compatible with Atdec AWM Series products.
! Curved monitors, deep devices (such as all-in-one PCs) and offset VESA locations exert additional leverage that can exceed the
capacity of the mount even though the monitor weight may be within the stated range. Please contact Atdec if you would like further
information.
D
B
Screw
VESA Head
M4x25mm
(x1)
(x4)
G
Spacer
(x4)
E
F
Screw
Screw
M4x16mm
M4x12mm
(x4)
(x4)
H
I
Security
4mm
screw
allen key
(x1)
(x4)
Installation Guide
AWM-A13
REQUIRED TOOLS
• Phillips Head Screwdriver
WEIGHT RANGE
Flat Monitors
0 - 12kg
(0 - 26.5lbs)
Curved Monitors
0 - 8kg
(0 - 17.6lbs)
Monitor weight should be within the
weight range of all modular elements
that make up the complete monitor
mounting solution.
AWM-A13 Page 1 of 4
