130 Arm
COMPONENT CHECKLIST
A
Monitor
arm
(x1)
C
Channel
clamp
(x1)
IMPORTANT INFORMATION
! Please ensure this product is installed as per these installation instructions.
! The manufacturer accepts no responsibility for incorrect installation.
! This product is compatible with Atdec modular (AWM) products.
D
B
Screw
VESA
M4x12mm
head
(x4)
(x1)
G
Spacer
10mm
(x4)
E
F
Screw
Screw
M4x10mm
M4x8mm
(x4)
(x4)
H
I
Security
4mm
screw
allen key
(x4)
(x4)
Installation Guide
AWM-A13
REQUIRED TOOLS
• Phillips Head Screwdriver
WEIGHT RANGE
0 - 12kg
(0 - 26.5lbs)
AWM-A13 Page 1 of 4
Advertisement
Related Manuals for Atdec AWM-A13
Summary of Contents for Atdec AWM-A13
-
Page 1: Installation Guide
(x4) (x4) IMPORTANT INFORMATION ! Please ensure this product is installed as per these installation instructions. ! The manufacturer accepts no responsibility for incorrect installation. ! This product is compatible with Atdec modular (AWM) products. AWM-A13 Page 1 of 4... - Page 2 3.3 Lock at preferred height by pushing lever down ‘Click’ Note: Ensure clamp lever is vertical and Note: Squeeze and unlocked hold clamp jaws before Fit top cap on post inserting into channel Post Wall Channel AWM-A13 Page 2 of 4...
- Page 3 6.1 To make for easy tilt adjustment and to prevent the monitor 6.2 OPTIONAL security screw from falling forward, adjust the tension as show below To install the optional security screw tilt the head upwards Note: Support monitor while adjusting Loosen Loosen Tighten Tighten AWM-A13 Page 3 of 4...
- Page 4 No portion of this document or any artwork contained herein should be reproduced in any way without the express written consent of Atdec Pty Ltd. Due to continuing product development, the manufacturer reserves the right to alter specifications without notice. ©20171206B AWM-A13 Page 4 of 4 atdec.com | atdec.co.uk | atdec.com.au...
