130 Arm
COMPONENT CHECKLIST
A
Monitor Arm
(x1)
C
Post Clamp
(x1)
IMPORTANT INFORMATION
! Please ensure this product is installed as per these installation instructions.
! The manufacturer accepts no responsibility for incorrect installation.
! This product is compatible with Atdec AWM Series products.
D
B
Screw
VESA Head
M4x25mm
(x1)
(x4)
G
Spacer
(x4)
E
F
Screw
Screw
M4x16mm
M4x12mm
(x4)
(x4)
H
I
Security
4mm
screw
allen key
(x1)
(x4)
Installation Guide
AWM-A13
REQUIRED TOOLS
• Phillips Head Screwdriver
WEIGHT RANGE
0 - 12kg
(0 - 26.5lbs)
AWM-A13 Page 1 of 4
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Atdec AWM-A13
Summary of Contents for Atdec AWM-A13
- Page 1 (x1) (x4) IMPORTANT INFORMATION ! Please ensure this product is installed as per these installation instructions. ! The manufacturer accepts no responsibility for incorrect installation. ! This product is compatible with Atdec AWM Series products. AWM-A13 Page 1 of 4...
- Page 2 3.1 Push arm onto shaft. 3.2 Ensure arm is fully pushed onto shaft. 3.3 Tighten joint screw. nto clamp Note: Check the Tip: Check the arm rotation is arm rotation i smooth after smooth after tightening. tightening. AWM-A13 Page 2 of 4...
- Page 3 6.1 Use the allen key to adjust the tilt tension until the monitor 6.2 OPTIONAL security screw holds in a vertical position at the end of the arm. To install the optional security screw tilt the head upwards Note: Support monitor while adjusting Loosen Loosen Tighten Tighten AWM-A13 Page 3 of 4...
- Page 4 No portion of this document or any artwork contained herein should be reproduced in any way without the express written consent of Atdec Pty Ltd. Due to continuing product development, the manufacturer reserves the right to alter specifications without notice. ©20180521C AWM-A13 Page 4 of 4 atdec.com | atdec.co.uk | atdec.com.au...
