460 Arm
COMPONENT CHECKLIST
A
Monitor Arm
(x1)
IMPORTANT INFORMATION
! Please ensure this product is installed as per these installation instructions.
! The manufacturer accepts no responsibility for incorrect installation.
! This product is compatible with Atdec AWM Series products.
B
D
VESA Head
Screw
(x1)
M4x25mm
(x4)
C
G
Post Clamp
Spacer
(x1)
(x4)
E
F
Screw
Screw
M4x16mm
M4x12mm
(x4)
(x4)
H
I
Security
4mm
screw
allen key
(x1)
(x1)
Installation Guide
AWM-A46
REQUIRED TOOLS
• Phillips Head Screwdriver
WEIGHT RANGE
0 - 12kg
(0 - 26.5lbs)
AWM-A46 Page 1 of 4
Advertisement
Table of Contents
Related Manuals for Atdec AWM-A46-B
Summary of Contents for Atdec AWM-A46-B
- Page 1 (x1) (x1) IMPORTANT INFORMATION ! Please ensure this product is installed as per these installation instructions. ! The manufacturer accepts no responsibility for incorrect installation. ! This product is compatible with Atdec AWM Series products. AWM-A46 Page 1 of 4...
- Page 2 1. Fix clamp to Post or Wall Channel ure Knob is undone 1.1 Ensure knob is undone. 2. Slide post clamp into channel 3. Hold clamp in desired position on post a 1.2 Slide post clamp into channel. 1.3 Hold clamp in desired position on channel and turn knob to lock in place.
- Page 3 4. Attach VESA head to monitor 4.1 VESA mounting compatibility 4.2 Screw the VESA head onto monitor 4.3 Ensure the correct screw length is used to attach the monitor. 12mm 100mm 75mm Flush Spacer 100mm 75mm Too long Too short Note: For other sizes, use a suitable Note spacers may be required for curved, adaptor plate (sold separately).
- Page 4 No portion of this document or any artwork contained herein should be reproduced in any way without the express written consent of Atdec Pty Ltd. Due to continuing product development, the manufacturer reserves the right to alter specifications without notice. ©20180521C AWM-A46 Page 4 of 4 atdec.com | atdec.co.uk | atdec.com.au...
