- Page 1 SUNNY SF-T1414 TREADMILL USER MANUAL IMPORTANT: Read all instructions carefully before using this product. Retain owner’s manual for future reference. For customer service, please contact: support@sunnyhealthfitness.com...
-
Page 2: Important Safety Information
IMPORTANT SAFETY INFORMATION We thank you for choosing our product. To ensure your safety and health, please use this equipment correctly. It is important to read this entire manual before assembling and using the equipment. It is your responsibility to ensure that all users of the equipment are informed of all warnings and precautions. - Page 3 IMPORTANT OPERATION INSTRUCTIONS 1. Insert the power plug into the socket directly. 2. The constant running time for this machine is less than 2 hours. Be sure to read the manual before operating the equipment. 3. Changes in speed do not occur immediately, set your desired speed using the adjustment key on the computer console, when finished, release the adjustment key.
-
Page 4: Exploded Drawing
EXPLODED DRAWING... -
Page 5: Parts List
PARTS LIST Base frame Main frame Incline bracket Bolt M10*15 Bolt Console bracket M10*45 Bolt Cross bar M10*50 Bolt Motor bracket M10*60 Bolt Left upright tube M10*65 Bolt Right upright tube M8*15 Bolt Left handle bar M8*30 Bolt Right handle bar M8*40 Bolt Front roller... - Page 6 Speed sensor Right water bottle Left upright tube Transformer cover Right upright tube Power socket cover Blue cushion Power wire Black cushion DC motor Motor top cover Incline motor acrylic Square switch Motor belt Overload protector Handle bar foam Bolt M8*55 Handle bar end cap Hand pulse with...
-
Page 7: Carton Contents
ASSEMBLY INSTRUCTIONS CARTON CONTENTS: DES. Specification Nos. DES. Specification Nos. Right upright tube Main frame cover Lock washer Spanner Bolt M10*15 Left handle bar S=13,14,15 Bolt M5*8 Right handle bar 6# Allen wrench 5# Allen wrench Φ8 ARC washer Cross bar Bolt M8*15 Left outside rail... - Page 8 STEP: 1 Open carton remove contents. Place the Main Frame (No. D) on level ground, ensure that you have a work area that is clean and has adequate space. Lift the Console (No. 28) STEP: 2 and Upright Tubes (No. 7 and 8) in the direction specified by the arrows on the diagram to the left.
- Page 9 STEP: 4 Fix the Console (No. 28) to the Left and Right Upright Tubes (No. 7 and No. 8), using 4 sets of M10x15 Bolts (No. 56) and Lock Washers (No. 77), secure using Allen Wrench (No. 19). STEP: 5 Connect the pulse wires “A”...
- Page 10 STEP: 6 Fix the Left and Right Tube Covers (No. 34 and No. 35) to the Base Frame (No. 1) using 6 sets of M5*8 Bolts (No.68), secure using Spanner (No. 20). STEP: 7 Insert the Safety Key (No. 24) into the magnet area of the Console top cover (No.
-
Page 11: Folding Instructions
FOLDING INSTRUCTIONS FOLDING: Place your hand at position “A” and lift up on the Main Frame (No. D) until the Air Pressure Cylinder (No. 14) “B” locks into the tube. Notice: When Pressure Cylinder (No. 14) successfully locks into the tube you will hear a clicking sound. -
Page 12: How To Move The Machine
HOW TO MOVE THE MACHINE Before attempting to move the treadmill please make sure that been properly folded. Remove power cord. To tilt; start by placing one hand at position “A” to support the top end of the treadmill, next place one foot at position “B”... -
Page 13: Grounding Methods
IMPORTANT ELLECTRICAL INFORMATION WARNING: This treadmill requires a power source of 18 amps (110 Volts) in order to operate correctly. For your safety as well as the safety of others please verify that the power source is correct before powering the equipment. Any power supply source above or below this level could cause significant damage to the equipment and or user. -
Page 14: Operating The Computer
OPERATING THE COMPUTER PART I: WINDOW DISPLAY 1. SPEED: Displays the speed. The speed range is 0.5—11 mph. 2. INCLINE: Displays the incline. The incline range is 0-15. 3. TIME: Displays the running time from 0:00-99:59. When the clock reaches 99:59, the machine will stop smoothly and display “End”... -
Page 15: Multifunction Button
PART II: BUTTON FUNCTION: 1. MODE: Under standby mode, press mode buttons to select different modes. 2. USB / MP3: You can press this button to choose USB or MP3 function. 3. START: To start the machine insert the magnet end of the safety key into the computer console and then press the START button. -
Page 16: Control Functions
PART III: QUICK START 1. Insert the magnet end of the safety key into the computer console. 2. Press the START button, a buzzer will sound and the system will automatically display a 3 second countdown when the countdown reaches zero the running belt of the treadmill will start, the initial speed will be 0.5mph (the system default running mode). -
Page 17: Program Exercise Chart
Press the MODE button three times to into the Calories Countdown, the CALORIES window will display a flashing 50; press the SPEED +/- or INCLINE +/- BUTTONS to set the desired CALORIES, the setting range is 10-995. PART V: PROGRAMS 1. -
Page 18: Range Of Program
mountain SPEED running mode INCLINE beach running SPEED mode INCLINE man mode SPEED INCLINE woman mode SPEED INCLINE health mode SPEED INCLINE middle-aged SPEED sports mode INCLINE old-aged SPEED sports mode INCLINE walking mode SPEED INCLINE RANGE OF PROGRAM: Initial Default Value Set Range Display Range... - Page 19 2. BODY QUALITY CALCULATION: While in the standby mode, press the MODE button scroll through the programs until the window displays measuring fat (Body Quality Calculation), press the Confirm button to enter. Press the or the INCLINE +/- button on the handlebar to select an option;...
- Page 20 3. USER SETTINGS PROGRAMS (U1-U3): Press the MODE button to cycle through the programs until you reach U1-U2-U3. User Settings Programs (U1-U3) are programs that allow the user(s) to manually pre-set each of the 16 exercise programs in order to create personal exercise profile(s).
- Page 21 TREADMILL FUNCTIONS: SAFETY LOCK FUNCTION: Removing the Safety Key from the computer console while the treadmill is running will cause it to stop immediately, once the treadmill reaches a full stop the window display of the computer will show “- - -“ and the buzzer will “Beep” 3 times. To start the treadmill again, insert the magnet end of the Safety Key into the computer console and press the START button.
-
Page 22: Getting Started
EXERCISE INSTRUCTIONS: GETTING STARTED: Before starting any exercise program you should consult your physician to determine if you have any medical or physical conditions that could put your health and safety at risk, or prevent you from using the equipment properly. Be aware of your body’s signals. Incorrect or excessive exercise can damage your health. -
Page 23: Maintenance Instructions
MAINTENANCE INSTRUCTIONS: General cleaning will help to prolong the life of the treadmill and improve performance. Keep the unit clean and maintained by dusting the components on a regular basis, cleaning the two exposed sides of the running belt to prevent dust from accumulating underneath the belt. - Page 24 RUNNING BELTS & TREADMILL LUBERCANT: Lubricating the running board and running belt is essential as the friction between the two affects the life span and function of the treadmill, therefore it is suggested that the running board and belt be inspected regularly. Should you find any wear on the Running Board, please contact us support@sunnyhealthfitness.com WARNING: Always unplug the treadmill from the electrical outlet before cleaning,...
-
Page 25: Troubleshooting
TROUBLESHOOTING: PROBLEM CAUSE SOLUTION Not plugged in Plug cord into outlet Treadmill will not start Safety Key not inserted Insert Safety Key Not calibrated correctly Re-calibrate speed setting Running speed inaccurate Speed set in the wrong Change setting to proper Units of measurement Units. - Page 26 The incline motor is damaged or the wire for Re-connect or replace the the incline motor is not wire for the incline motor. E04: Incline failure connected properly or has Replace the incline motor become damaged with a new one. Restart the treadmill.
