Table 8 NWA5301-NJ LEDs (continued)
LABEL
WLAN
UPLINK
LAN1-3
1.6.4 NWA1123-ACv2, NWA5121-N, NWA5121-NI, NWA5123-AC and
NWA5123-NI
The following are the LED descriptions for your NWA1123/5120 series.
Figure 8 NWA1123/5120 Series LED
The following are the LED descriptions for your NWA1123/5120 series.
Table 9 NWA1123/5120 Series LED
COLOR
Amber
Green
Chapter 1 Introduction
COLOR STATUS
Green On
Off
Green On
Blinking
Off
Green On
Blinking
Off
STATUS DESCRIPTION
Slow Blinking (On for 1s, The NWA is booting up.
Off for 1s)
On
NWA / WAC Series User's Guide
DESCRIPTION
The WLAN is active.
The WLAN is not active.
The port is connected.
The NWA is sending/receiving data through the port.
The port is not connected.
The port is connected.
The NWA is sending/receiving data through the port.
The port is not connected.
