Page 1 User’s Guide NWA/WAC/WAX Series 802.11 a/b/g/n/ac/ax Access Point Version 6.10-6.20 Edition 1, 5/2021 Default Login Details Management IP http://DHCP-assigned IP Address http://192.168.1.2 User Name admin Password 1234 Copyright © 2021 Zyxel and/ or its affiliates. All rights reserved.
Page 2 IMPO RT ANT ! READ C AREFUL L Y BEFO RE USE. KEEP T HIS G UIDE FO R FUT URE REFERENC E. This is a User’s Guide for a series of products. Not all products support all firmware features. Screenshots and graphics in this book may differ slightly from your product due to differences in your product hardware, firmware, or your computer operating system.
Page 3: Do C Um E Nt C O Nve Ntio Ns
Do c um e nt C o nve ntio ns Wa rning s a nd No te s These are how warnings and notes are shown in this guide. Wa rning s te ll yo u a b o ut thing s tha t c o uld ha rm yo u o r yo ur de vic e . Note: Notes tell you other important information (for example, other things you may need to configure or helpful tips) or recommendations.
Page 4: Table Of Contents
Contents Overview C o nte nts O ve rvie w Introduction ............................12 AP Management ..........................20 Hardware ............................... 28 Web Configurator ..........................30 Sta nda lo ne C o nfig ura tio n ........................41 Standalone Configuration ........................42 Dashboard ............................44 Setup Wizard ............................
Page 5 Table of Contents T a b le o f C o nte nts Do c um e nt C o nve ntio ns ........................3 C o nte nts O ve rvie w ..........................4 T a b le o f C o nte nts ..........................5 C ha pte r 1 Intro duc tio n ............................12 1.1 Overview ............................
Page 6: Table Of Contents
Table of Contents 4.3.1 Title Bar ........................... 34 4.3.2 Navigation Panel ........................35 4.3.3 Standalone Mode Navigation Panel Menus ..............35 4.3.4 Cloud Mode Navigation Panel Menus ................37 4.3.5 Tables and Lists ........................38 Pa rt I: Sta nda lo ne C o nfig ura tio n ..............41 C ha pte r 5 Sta nda lo ne C o nfig ura tio n .........................42 5.1 Overview ............................
Page 7 Table of Contents 8.8 View Log ............................66 C ha pte r 9 Ne two rk...............................69 9.1 Overview ............................69 9.1.1 What You Can Do in this Chapter ..................69 9.2 IP Setting ............................69 9.3 VLAN ..............................71 9.4 NCC Discovery ..........................73 C ha pte r 10 Wire le ss ...............................75 10.1 Overview ............................
Page 8 Table of Contents 12.5 MAC Filter List ..........................115 12.5.1 Add/Edit MAC Filter Profile ....................115 C ha pte r 13 MO N Pro file ............................117 13.1 Overview ............................. 117 13.1.1 What You Can Do in this Chapter ................... 117 13.2 MON Profile ..........................
Page 9 Table of Contents 16.4.3 HTTPS ........................... 143 16.4.4 Configuring WWW Service Control ................. 144 16.4.5 HTTPS Example ........................145 16.5 SSH ..............................151 16.5.1 How SSH Works ........................152 16.5.2 SSH Implementation on the Zyxel Device ..............153 16.5.3 Requirements for Using SSH ....................153 16.5.4 Configuring SSH .........................
Page 10 Table of Contents 20.2 Suppression Screen ........................180 20.3 Locator Screen ........................... 181 C ha pte r 21 Re b o o t...............................183 21.1 Overview ............................. 183 21.1.1 What You Need To Know ....................183 21.2 Reboot ............................183 C ha pte r 22 Shutdo wn ............................184 22.1 Overview .............................
Page 11 Table of Contents C ha pte r 26 T ro ub le sho o ting ..........................198 26.1 Overview ............................. 198 26.2 Power, Hardware Connections, and LED ................198 26.3 Zyxel Device Management, Access, and Login ..............199 26.4 Internet Access ........................... 202 26.5 WiFi Network ..........................
Page 12: C Ha Pte R 1 Intro Duc Tio N
HA PTER Intro duc tio n 1.1 O ve rvie w This User’s Guide covers the models listed in the following table. They can be managed in one of the following methods: remote management through Nebula Control Center (NCC) or an AP Controller (AC) such as the NXC, or local management in Standalone Mode.
Page 13: Root Ap
Chapter 1 Introduction • Radio Frequency (RF) monitor - An RF monitor searches for rogue APs to help eliminate network threats if it supports monitor mode and rogue APs detection/containment. An RF monitor cannot simultaneously act as an AP. • Root AP - A root AP connects to the gateway or switch through a wired Ethernet connection and has wireless repeaters connected to it to extend its range.
Page 14 Chapter 1 Introduction 1.2.2 Wire le ss Re pe a te r Using Repeater mode, your Zyxel Device can extend the range of the WLAN. In the figure below, the Zyxel Device in Repeater mode ( ) has a wireless connection to the Zyxel Device in Root AP mode ( which is connected to a wired network and also has a wireless connection to another Zyxel Device in Repeater mode ( ) at the same time.
Page 15: Radio Frequency (Rf) Monitor
Chapter 1 Introduction 1.2.3 Ra dio Fre q ue nc y (RF) Mo nito r The Zyxel Device can be set to work as an RF monitor to discover nearby Access Points. The information it obtains from other APs is used to tag possible rogue APs and quarantine them if the Zyxel Device is managed by the NXC (see Section 2.1.3 on page 27).
Page 16: Sample Feature Applications
Chapter 1 Introduction Select the Ra dio 1(2) Pro file that you created in the previous step. Select O ve rride G ro up Ra dio Se tting and click MO NIT O R > Wire le ss > De te c te d De vic e Go to to see a list of APs scanned by the RF monitor.
Page 17: Dual-Radio
Chapter 1 Introduction Fig ure 3 Multiple BSSs 1.3.2 Dua l- Ra dio Some of the Zyxel Device models are equipped with dual wireless radios. This means you can configure two different wireless networks to operate simultaneously. Note: A different channel should be configured for each WLAN interface to reduce the effects of radio interference.
Page 18: Zyxel Device Product Feature
Chapter 1 Introduction Fig ure 4 Dual-Radio Application 1.4 Zyxe l De vic e Pro duc t Fe a ture C o m pa riso n The following tables show the differences between each Zyxel Device model. Table 1 Zyxel Device 1000/5000 Series Comparison Table NWA1123- NWA1123 NWA1123-...
Page 19 Chapter 1 Introduction Table 1 Zyxel Device 1000/5000 Series Comparison Table (continued) NWA1123- NWA1123 NWA1123- NWA1302 NWA5123 NWA5123 WAC 5302 FEAT URES - AC PRO AC HD - AC - AC - AC HD D- S WDS (Wireless Distribution System) - Root AP &...
Page 20 Chapter 1 Introduction The following tables show the differences between each Zyxel Device model. Table 2 Zyxel Device 1000/5000 Series Comparison Table WAC 500/ FEAT URES NWA1123- AC WAC 5302D- S WAC 500H Supported IEEE 802.11a IEEE 802.11a IEEE 802.11a IEEE 802.11b IEEE 802.11b IEEE 802.11b...
Page 21 Chapter 1 Introduction Table 2 Zyxel Device 1000/5000 Series Comparison Table (continued) WAC 500/ FEAT URES NWA1123- AC WAC 5302D- S WAC 500H NCC Discovery 802.11r Fast Roaming Support 802.11k/v Assisted Roaming Bluetooth Low Energy (BLE) USB Port for BLE Ethernet Storm Control Grounding...
Page 22 Chapter 1 Introduction Table 3 WAC 6000 Series Comparison Table (continued) WAC 6502D- S WAC 6502D- E FEAT URES WAC 6103D- I WAC 6303D- S WAC 6503D- S WAC 6553D- E WAC 6552D- S WDS (Wireless Distribution System) - Root AP & Repeater Modes Tunnel Forwarding Mode...
Page 23 The following tables show the differences between each Zyxel Device model. Table 4 802.11ax Series Comparison Table WAX510D NWA110AX FEAT URES WAX650S WAX610D NWA210AX Supported Wireless IEEE 802.11a IEEE 802.11a IEEE 802.11a IEEE 802.11b IEEE 802.11b Standards IEEE 802.11b IEEE 802.11g IEEE 802.11g IEEE 802.11g IEEE 802.11n...
Page 24 Chapter 1 Introduction Table 4 802.11ax Series Comparison Table (continued) WAX510D NWA110AX FEAT URES WAX650S WAX610D NWA210AX Power Jack Firmware Version 6.20 6.20 6.20 Maximum number of log 512 event logs messages A. For NXC managed devices only. See the NXC User’s Guide for details. NWA/WAC/WAX Series User’s Guide...
Page 25: Ap Management
Chapter 2 AP Management HA PTER AP Ma na g e m e nt 2.1 Ma na g e m e nt Mo de The Zyxel Device is a unified AP and can be managed by the NCC or an AP controller (AC), or work as a standalone device.
Page 26 Chapter 2 AP Management 2.1.2 Ne b ula C o ntro l C e nte r In this mode, which is also called cloud mode, you can manage and monitor the Zyxel Device through the Zyxel Nebula cloud-based network management system. This means you can manage devices remotely without the need of connecting to each device directly.
Page 27 Chapter 2 AP Management Fig ure 5 Traffic Monitoring Graph From NCC See the NCC (Nebula Control Center) User’s Guide for how to configure Nebula managed devices. See Chapter 24 on page 189 if you want to change the Zyxel Device’s VLAN setting or manually set its IP address.
Page 28: Switching Management Modes
Chapter 2 AP Management Note: If the Zyxel Device is already registered to NCC, the controller will be unable to manage An AC uses Control And Provisioning of Wireless Access Points (CAPWAP, see RFC 5415) to discover and configure multiple managed APs. 2.2 Switc hing Ma na g e m e nt Mo de s The Zyxel Device is in standalone mode by default, with NCC and/or AC discovery enabled.
Page 29: Zyxel One Network (Zon) Utility
Chapter 2 AP Management 2.3 Zyxe l O ne Ne two rk (ZO N) Utility ZON Utility is a program designed to help you deploy and manage a network more efficiently. It detects devices automatically and allows you to do basic settings on devices in the network without having to be near it.
Page 30 Chapter 2 AP Management Fig ure 6 Supported Devices and Versions If you want to check the supported models and firmware versions later, you can click the Sho w info rm a tio n a b o ut ZO N icon in the upper right hand corner of the screen.
Page 31 Chapter 2 AP Management Fig ure 8 Network Adapter Click the button for the ZON Utility to discover all supported devices in your network. Fig ure 9 Discovery The ZON Utility screen shows the devices discovered. Fig ure 10 ZON Utility Screen Select a device and then use the icons to perform actions.
Page 32 Chapter 2 AP Management Fig ure 11 Password Prompt The following table describes the icons numbered from left to right in the ZON Utility screen. Table 7 ZON Utility Icons IC O N DESC RIPT IO N 1 IP Configuration Change the selected device’s IP address.
Page 33: Ways To Access The Zyxel Device
Chapter 2 AP Management Table 8 ZON Utility Fields L ABEL DESC RIPT IO N MAC Address This field displays the MAC address of the discovered device. IP Address This field displays the IP address of an internal interface on the discovered device that first received an ZDP discovery request from the ZON utility.
Page 34: Good Habits For Managing The Zyxel Device
Chapter 2 AP Management File T ra nsfe r Pro to c o l (FT P) This protocol can be used for firmware upgrades and configuration backup and restore. Sim ple Ne two rk Ma na g e m e nt Pro to c o l (SNMP) The Zyxel Device can be monitored by an SNMP manager.
Page 35: Hardware
Chapter 3 Hardware HA PTER Ha rdwa re See the Quick Start Guide for hardware installation and connections. 3.1 G ro unding (WAC 6552D- S a nd WAC 6553D- E) Earth grounding helps protect against lightning and interference. Note: The power installation must be performed by qualified service personnel and should conform to the National Electrical Code.
Page 36: Zyxel Device Single Led
Chapter 3 Hardware Fig ure 12 Grounding Example 3.2 Zyxe l De vic e Mo de ls With Sing le L EDs The LEDs of some Zyxel Device models can be controlled by using the suppression feature such that the LEDs stay lit (ON) or OFF after the Zyxel Device is ready.
Page 37 Chapter 3 Hardware 3.3.1 NWA1123- AC v2 Fig ure 13 NWA1123-ACv2 LED The following are the LED descriptions for your NWA1123-ACv2. Table 9 NWA1123-ACv2 LED C O L O R ST AT US DESC RIPT IO N Amber Blinks amber for 1 second The LED blinks amber and green alternatively when the Zyxel and green for 1 second Device is booting up or is connecting to the NCC.
Page 38 Chapter 3 Hardware Table 9 NWA1123-ACv2 LED (continued) C O L O R ST AT US DESC RIPT IO N Steady On The Zyxel Device failed to boot up or is experiencing system failure. Slow Blinking (Blink for 3 The Uplink interface is down. times, Off for 3s) Fast Blinking (On for 50 ms, The Zyxel Device is undergoing firmware upgrade.
Page 39 Chapter 3 Hardware Table 10 WAC6303D-S, NWA1123-AC HD and NWA5123-AC HD LED (continued) C O L O R ST AT US DESC RIPT IO N Green Slow Blinking (On for 1 The wireless module of the Zyxel Device is disabled or fails, the second, Off for 1 second) Zyxel Device is using default wireless settings, or the Zyxel Device is configured to be managed by NCC but is not yet...
Page 40 Chapter 3 Hardware 3.3.3 NWA5123- AC Fig ure 15 NWA5123-AC LED The following are the LED descriptions for your NWA5123-AC. Table 11 NWA5123-AC LED C O L O R ST AT US DESC RIPT IO N Amber Blinks amber for 1 second The Zyxel Device is booting up.
Page 41 Chapter 3 Hardware Table 11 NWA5123-AC LED (continued) C O L O R ST AT US DESC RIPT IO N Steady On The Zyxel Device failed to boot up or is experiencing system failure. Slow Blinking (Blink for 3 The Uplink interface is down. times, Off for 3s) Fast Blinking (On for 50 ms, The Zyxel Device is undergoing firmware upgrade.
Page 42 Chapter 3 Hardware Fig ure 17 WAC500H LED The following are the LED descriptions for your WAC500, WAC500H, NWA1123ACv3, NWA110AX, NWA210AX, WAX510D, WAX610D and WAX650S. Table 12 WAC500, WAC500H, NWA1123ACv3, NWA110AX, WAX510D and WAX650S LED C O L O R ST AT US DESC RIPT IO N Amber...
Page 43 Chapter 3 Hardware Table 12 WAC500, WAC500H, NWA1123ACv3, NWA110AX, WAX510D and WAX650S LED (continued) C O L O R ST AT US DESC RIPT IO N Green Steady On The Zyxel Device is ready for use, the Zyxel Device’s wireless interface is activated, and/or wireless clients are connected to the Zyxel Device in full power mode (see Table 14 on page...
Page 44 Chapter 3 Hardware 3.4.1 NWA1123- AC PRO Fig ure 18 NWA1123-AC PRO LEDs The following table describes the LEDs. Table 13 NWA1123-AC PRO LEDs L ED C O L O R ST AT US DESC RIPT IO N PWR/SYS Amber Blinks amber for 1 The LED blinks amber and green alternatively when the second and green for...
Page 45 Chapter 3 Hardware Table 13 NWA1123-AC PRO LEDs (continued) L ED C O L O R ST AT US DESC RIPT IO N Management Green The Zyxel Device is managed by the NCC. Slow Blinking (On for 1 The Zyxel Device is using default wireless settings, or the sec, Off for 1 sec) Zyxel Device is connected to the NCC but is unregistered with the NCC.
Page 46 Chapter 3 Hardware Fig ure 19 NWA1302-AC/ WAC5301D-Sv2 LEDs The following table describes the LEDs. Table 14 NWA1302-AC/ WAC5301D-Sv2 LEDs L ED C O L O R ST AT US DESC RIPT IO N PWR/SYS Amber Blinks amber for 1 The LED blinks amber and green alternatively when the second and green for 1 Zyxel Device is booting up.
Page 47 Chapter 3 Hardware Table 14 NWA1302-AC/ WAC5301D-Sv2 LEDs (continued) L ED C O L O R ST AT US DESC RIPT IO N UPLINK Amber The port is operating as a 10/100 Mbps connection. Blinking The Zyxel Device is sending/receiving data through the port at 10/100 Mbps.
Page 48 Chapter 3 Hardware 3.4.3 WAC 6502D- E, WAC 6502D- S, a nd WAC 6503D- S Fig ure 20 WAC6502D-E, WAC6502D-S, or WAC6503D-S LEDs The following table describes the LEDs. Table 15 WAC6502D-E, WAC6502D-S, or WAC6503D-S LEDs L ED C O L O R ST AT US DESC RIPT IO N PWR/SYS...
Page 49 Chapter 3 Hardware Table 15 WAC6502D-E, WAC6502D-S, or WAC6503D-S LEDs (continued) L ED C O L O R ST AT US DESC RIPT IO N Management Green The Zyxel Device is managed by a the NCC or an AC. Slow Blinking (Blink for 3 The Zyxel Device is searching (discovery) for an AC.
Page 50 Chapter 3 Hardware 3.4.4 WAC 6103D- I Fig ure 21 WAC6103D-I LEDs The following table describes the LEDs. Table 16 WAC6103D-I LEDs L ED C O L O R ST AT US DESC RIPT IO N PWR/SYS Amber Blinks amber for 1 The Zyxel Device is booting up.
Page 51 Chapter 3 Hardware Table 16 WAC6103D-I LEDs (continued) L ED C O L O R ST AT US DESC RIPT IO N Management Green The Zyxel Device is managed by an AC or the NCC. Slow Blinking (Blink for 3 The Zyxel Device is searching (discovery) for an AC.
Page 52 Chapter 3 Hardware Fig ure 22 WAC5302D-S LEDs The following table describes the LEDs. Table 17 WAC5302D-S LEDs L ED C O L O R ST AT US DESC RIPT IO N PWR/SYS Amber Blinks amber for 1 The LED blinks amber and green alternatively when the second and green for 1 WAC is booting up.
Page 53 Chapter 3 Hardware Table 17 WAC5302D-S LEDs (continued) L ED C O L O R ST AT US DESC RIPT IO N UPLINK Amber The port is operating as a 10/100 Mbps connection. Blinking The Zyxel Device is sending/receiving data through the port at 10/100 Mbps.
Page 54: Web Configurator
HA PTER We b C o nfig ura to r 4.1 O ve rvie w The Web Configurator is an HTML-based management interface that allows easy system setup and management via internet browser. Use a browser that supports HTML5, such Internet Explorer 11, Mozilla Firefox, or Google Chrome.
Page 55 Chapter 4 Web Configurator If a Zyxel Device is in standalone mode and supports NCC, the login page displays as shown in the following figure. Ne b ula Mo de Click to show the following screen. Here, you can watch a tutorial for using the Zyxel Nebula Control Center (NCC) or access the link to the NCC, as shown in the following figure.
Page 56 Chapter 4 Web Configurator remotely manage and monitor the Zyxel Device (see Section 2.1.2 on page 26). If you want to return to the login page, click Sta nda lo ne Mo de and follow the next steps. Enter the user name (default: “admin”) and password (default: “1234”). If the Zyxel Device is being managed or has been managed by the NCC, check the NCC's Site - Wide >...
Page 57: Navigating The Web Configurator
Chapter 4 Web Configurator 4.3 Na vig a ting the We b C o nfig ura to r The following summarizes how to navigate the Web Configurator from the Da shb o a rd screen. The Da shb o a rd following figures show the screen for standalone mode and for cloud (NCC) mode.
Page 58: Title Bar
Chapter 4 Web Configurator 4.3.1 T itle Ba r The title bar provides some useful links that always appear over the screens below, regardless of how deep into the Web Configurator you navigate. If your Zyxel Device is in NCC mode, not all icons will be available in the Title Bar.
Page 59: Navigation Panel
Chapter 4 Web Configurator C L I Me ssa g e s C L I Click to look at the CLI commands sent by the Web Configurator. These commands appear in a popup window, such as the following. Fig ure 17 CLI Messages C le a r Click...
Page 60 Chapter 4 Web Configurator Da shb o a rd The dashboard displays general device information, system status, system resource usage, and interface status in widgets that you can re-arrange to suit your needs. For details on the Dashboard’s features, see Chapter 6 on page Mo nito r Me nu The monitor menu screens display status and statistics information.
Page 61 Chapter 4 Web Configurator Table 9 Configuration Menu Screens Summary (continued) FO L DER O R L INK T AB FUNC T IO N AP Profile Radio Create and manage wireless radio settings files that can be associated with different APs. SSID Create and manage wireless SSID, security, MAC filtering, and layer-2 isolation files that can be associated with different APs.
Page 62: Cloud Mode Navigation Panel Menus
Chapter 4 Web Configurator 4.3.4 C lo ud Mo de Na vig a tio n Pa ne l Me nus If your Zyxel Device is in NCC mode, you only need to use the Web Configurator for troubleshooting if your Zyxel Device cannot connect to the Internet. Da shb o a rd The dashboard displays general Zyxel Device information, and AP information in widgets that you can re-arrange to suit your needs.
Page 63 Chapter 4 Web Configurator • Filter by mathematical operators (<, >, or =) or searching for text. Select a column heading cell’s right border and drag to re-size the column. Select a column heading and drag and drop it to change the column order. A green check mark displays next to the column’s title when you drag the column to a valid new location.
Page 64 Chapter 4 Web Configurator 4.3.5.2 Wo rking with T a b le Entrie s The tables have icons for working with table entries. A sample is shown next. You can often use the [Shift] or [Ctrl] key to select multiple entries to remove, activate, or deactivate. Fig ure 19 Common Table Icons Here are descriptions for the most common table icons.
Page 65: Sta Nda Lo Ne C O Nfig Ura Tio N
A RT Sta nda lo ne C o nfig ura tio n...
Page 66: Sta Nda Lo Ne C O Nfig Ura Tio N
HA PTER Sta nda lo ne C o nfig ura tio n 5.1 O ve rvie w The Zyxel Device is in standalone mode by default. Use the web configurator to manage and configure the Zyxel Device directly. As shown in the following figure, wireless clients can connect to the Zyxel Device ( ) to access network resources.
Page 67 Chapter 5 Standalone Configuration Table 13 Starting and Stopping the Zyxel Device MET HO D DESC RIPT IO N Using the RESET button If you press the RESET button on the back of the Zyxel Device, the Zyxel Device sets the configuration to its default values and then reboots.
Page 68: Dashboard
HA PTER Da shb o a rd 6.1 O ve rvie w This screen displays general device information, system status, system resource usage, and interface status in widgets that you can re-arrange to suit your needs. You can also collapse, refresh, and close individual widgets.
Page 69 Chapter 6 Dashboard Table 14 Dashboard (continued) L ABEL DESC RIPT IO N Serial Number This field displays the serial number of this Zyxel Device. MAC Address This field displays the MAC addresses used by the Zyxel Device. Each physical port or Range wireless radio has one MAC address.
Page 70 Chapter 6 Dashboard Table 14 Dashboard (continued) L ABEL DESC RIPT IO N Current Login This field displays the user name used to log in to the current session, the amount of User reauthentication time remaining, and the amount of lease time remaining. Boot Status This field displays details about the Zyxel Device’s startup state.
Page 71: Cpu Usage
Chapter 6 Dashboard Table 14 Dashboard (continued) L ABEL DESC RIPT IO N Status This field displays the current status of each interface. The possible values depend on what type of interface it is. Ina c tive - The Ethernet interface is disabled. Do wn - The Ethernet interface is enabled but not connected.
Page 72: Memory Usage
Chapter 6 Dashboard Fig ure 21 Dashboard > CPU Usage The following table describes the labels in this screen. Table 15 Dashboard > CPU Usage L ABEL DESC RIPT IO N The y-axis represents the percentage of CPU usage. time The x-axis shows the time period over which the CPU usage occurred.
Page 73 Chapter 6 Dashboard The following table describes the labels in this screen. Table 16 Dashboard > Memory Usage L ABEL DESC RIPT IO N The y-axis represents the percentage of RAM usage. time The x-axis shows the time period over which the RAM usage occurred Refresh Interval Enter how often you want this window to be automatically updated.
Page 74: Setup Wizard
HA PTER Se tup Wiza rd 7.1 Ac c e ssing the Wiza rd When you log into the Web Configurator for the first time or when you reset the Zyxel Device to its default configuration, the wizard screen displays. Note: If you have already configured the wizard screens and want to open it again, click the Wiza rd icon on the upper right corner of any Web Configurator screen.
Page 75: Step 2 Password And Uplink Connection
Chapter 7 Setup Wizard Fig ure 23 Wizard: Time Settings 7.2.2 Ste p 2 Pa sswo rd a nd Uplink C o nne c tio n Use this screen to configure the Zyxel Device’s system password and IP address. C ha ng e Pa sswo rd : Enter a new password and retype it to confirm.
Page 76: Step 3 Radio
Chapter 7 Setup Wizard Fig ure 24 Wizard: Change Password and Uplink Connection 7.2.3 Ste p 3 Ra dio Use this screen to configure the Zyxel Device’s radio transmitter(s). • C ha nne l Se le c tio n : Select Auto to have the Zyxel Device automatically choose a radio channel that Ma nua l...
Page 77: Step 4 Ssid
Chapter 7 Setup Wizard 7.2.4 Ste p 4 SSID Use this screen to enable, disable or edit an SSID profile. Select an SSID profile and click the Sta tus switch to turn it on or off. To change an SSID profile’s settings, such as the SSID (WiFi network name) and WiFi password, double-click the SSID profile entry from the list.
Page 78 Chapter 7 Setup Wizard Fig ure 27 Wizard: SSID: Edit (WPA2-Personal) Fig ure 28 Wizard: SSID: Edit (WPA2-Enterprise) NWA/WAC/WAX Series User’s Guide...
Page 79: Summary
Chapter 7 Setup Wizard 7.2.5 Sum m a ry Use this screen to check whether what you have configured is correct. Click Sa ve to apply your settings and complete the wizard setup. Otherwise, click Pre v to return to the previous screen or click C a nc e l close the wizard without saving.
Page 80: Monitor
HA PTER Mo nito r 8.1 O ve rvie w Use the Mo nito r screens to check status and statistics information. 8.1.1 Wha t Yo u C a n Do in this C ha pte r • The Ne two rk Sta tus screen (Section 8.3 on page 55) displays general LAN interface information and...
Page 81: Network Status
Chapter 8 Monitor 8.3 Ne two rk Sta tus Use this screen to look at general Ethernet interface information and packet statistics. To access this Mo nito r > Ne two rk Sta tus screen, click Fig ure 28 Monitor > Network Status The following table describes the labels in this screen.
Page 82: Port Statistics Graph
Chapter 8 Monitor Table 17 Monitor > Network Status (continued) L ABEL DESC RIPT IO N Set Interval Click this to set the Po ll Inte rva l the screen uses. Stop Click this to stop the window from updating automatically. You can start it again by setting the Po ll Inte rva l and clicking Se t Inte rva l...
Page 83: Radio List
Chapter 8 Monitor Fig ure 29 Monitor > Network Status > Switch to Graphic View The following table describes the labels in this screen. Table 18 Monitor > Network Status > Switch to Graphic View L ABEL DESC RIPT IO N Refresh Interval Enter how often you want this window to be automatically updated.
Page 84 Chapter 8 Monitor Fig ure 30 Monitor > Wireless > AP Information > Radio List (for Zyxel Device that supports WDS) Fig ure 31 Monitor > Wireless > AP Information > Radio List (for Zyxel Device that does not support WDS) The following table describes the labels in this screen.
Page 85: Ap Mode Radio Information
Chapter 8 Monitor Table 19 Monitor > Wireless > AP Information > Radio List (continued) L ABEL DESC RIPT IO N Upload This displays the total number of packets received by the radio. Download This displays the total number of packets transmitted by the radio. Channel This indicates how much IEEE 802.11 traffic the radio can receive on the channel.
Page 86 Chapter 8 Monitor Fig ure 32 Monitor > Wireless > AP Information > Radio List > More Information The following table describes the labels in this screen. Table 20 Monitor > Wireless > AP Information > Radio List > More Information L ABEL DESC RIPT IO N SSID Detail...
Page 87: Station List
Chapter 8 Monitor Table 20 Monitor > Wireless > AP Information > Radio List > More Information (continued) L ABEL DESC RIPT IO N SSID Name This displays an SSID associated with this radio. There can be up to eight maximum. BSSID This displays a BSSID associated with this radio.
Page 88: Wds Link Info
Chapter 8 Monitor Table 21 Monitor > Wireless > Station Info (continued) L ABEL DESC RIPT IO N SSID Name This indicates the name of the wireless network to which the station is connected. A single AP can have multiple SSIDs or networks. Security Mode This indicates which secure encryption methods is being used by the station to connect to the network.
Page 89: Detected Device
Chapter 8 Monitor Table 22 Monitor > Wireless > WDS Link Info (continued) L ABEL DESC RIPT IO N MAC Address This is the MAC address of the root AP or repeater to which the Zyxel Device is connected using WDS.
Page 90 Chapter 8 Monitor Fig ure 35 Monitor > Wireless > Detected Device (for Zyxel Device that supports Monitor mode) NWA/WAC/WAX Series User’s Guide...
Page 91 Chapter 8 Monitor Fig ure 36 Monitor > Wireless > Detected Device (for Zyxel Device that does not support Monitor mode) The following table describes the labels in this screen. Table 23 Monitor > Wireless > Detected Device L ABEL DESC RIPT IO N Discovered APs Rogue AP...
Page 92: View Log
Chapter 8 Monitor Table 23 Monitor > Wireless > Detected Device (continued) L ABEL DESC RIPT IO N Mark as Rogue Click this button to mark the selected AP as a rogue AP. For more on managing rogue APs, see C o nfig ura tio n >...
Page 93 Chapter 8 Monitor Fig ure 37 Monitor > Log > View Log The following table describes the labels in this screen. Table 24 Monitor > Log > View Log L ABEL DESC RIPT IO N Show Filter / Hide Click this button to show or hide the filter settings. Filter If the filter settings are hidden, the Displa y...
Page 94 Chapter 8 Monitor Table 24 Monitor > Log > View Log (continued) L ABEL DESC RIPT IO N Destination This displays when you show the filter. Type the IP address of the destination of the incoming Address packet when the log message was generated. Do not include the port in this filter. Source Interface This displays when you show the filter.
Page 95: Network
HA PTER Ne two rk 9.1 O ve rvie w This chapter describes how you can configure the management IP address and VLAN settings of your Zyxel Device. The Internet Protocol (IP) address identifies a device on a network. Every networking device (including computers, servers, routers, printers, etc.) needs an IP address to communicate across the network.
Page 96 Chapter 9 Network Fig ure 39 AC managed Network Example Note: The Zyxel Device can be a standalone device or be managed by an AC. AC Disc o ve ry a nd Ma na g e m e nt The link between AC Discovery-enabled access points proceeds as follows: AC Disc o ve ry An Zyxel Device with enabled joins a wired network (receives a dynamic IP address).
Page 97: What You Can Do In This Chapter
Chapter 9 Network Note: The AC needs to have a static IP address. If it is a DHCP client, set the DHCP server to reserve an IP address for the AC. AC m a na g e m e nt a nd IP Sub ne ts By default, CAPWAP works only between Zyxel Devices with IP addresses in the same subnet.
Page 98: Ip Setting
Chapter 9 Network • The NC C Disc o ve ry screen (Section 9.4 on page 73) configures the Zyxel Device’s Nebula Control Center (NCC) discovery settings. 9.2 IP Se tting Use this screen to configure the IP address for your Zyxel Device. To access this screen, click C o nfig ura tio n >...
Page 99: Vlan
Chapter 9 Network Table 25 Configuration > Network > IP Setting (continued) L ABEL DESC RIPT IO N Enable Stateless Select this to enable IPv6 stateless auto-configuration on the Zyxel Device. The Zyxel Device Address Auto- will generate an IPv6 address itself from a prefix obtained from an IPv6 router in the network. configuration (SLAAC) Link-Local...
Page 100 Chapter 9 Network Fig ure 42 Management VLAN Setup In the figure above, to access and manage the Zyxel Device from computer , the Zyxel Device and switch ’s ports to which computer and the Zyxel Device are connected should be in the same VLAN. A Virtual Local Area Network (VLAN) allows a physical network to be partitioned into multiple logical networks.
Page 101 Chapter 9 Network Fig ure 43 Configuration > Network > VLAN (for Zyxel Device with multiple Ethernet ports) Fig ure 44 Configuration > Network > VLAN (for Zyxel Device with one Ethernet port) Each field is described in the following table. Table 26 Configuration >...
Page 102 Chapter 9 Network Table 26 Configuration > Network > VLAN (continued) L ABEL DESC RIPT IO N PVID This field displays the port number of the VLAN ID. VLAN Configuration Click this to create a new entry. For features where the entry’s position in the numbered list is important (features where the Zyxel Device applies the table’s entries in order like the SSID for example), you can select an entry and click to create a new entry after the...
Page 103 Chapter 9 Network Each field is described in the following table. Table 27 Configuration > Network > Storm Control L ABEL DESC RIPT IO N Broadcast Storm Select the check box to enable broadcast storm control on the Zyxel Device. Enabling this Control will drop ingress broadcast traffic in the physical Ethernet port if it exceeds the maximum traffic rate.
Page 104: Ncc Discovery
Chapter 9 Network Each field is described in the following table. Table 28 Configuration > Network > AC Discovery L ABEL DESC RIPT IO N Discovery Setting Auto Select this option to use DHCP option 138/DNS SRV record/Broadcast to get the AC’s IP address.
Page 105 Chapter 9 Network Each field is described in the following table. Table 29 Configuration > Network > NCC Discovery L ABEL DESC RIPT IO N Nebula Control Center Status Internet This field displays whether the Zyxel Device can connect to the Internet. Nebula Connectivity This field displays whether the Zyxel Device can connect to the Zyxel Nebula Control Center (NCC).
Page 106 Chapter 9 Network NWA/WAC/WAX Series User’s Guide...
Page 107 Chapter 9 Network NWA/WAC/WAX Series User’s Guide...
Page 108: Wireless
HA PTER Wire le ss 10.1 O ve rvie w This chapter discusses how to configure the wireless network settings in your Zyxel Device. The following figure provides an example of a wireless network. Fig ure 43 Example of a Wireless Network The wireless network is the part in the blue circle.
Page 109: What You Need To Know
Chapter 10 Wireless 10.1.2 Wha t Yo u Ne e d to Kno w The following terms and concepts may help as you read this chapter. Sta tio n / Wire le ss C lie nt A station or wireless client is any wireless-capable device that can connect to an AP using a wireless signal.
Page 110 Chapter 10 Wireless Fig ure 44 Configuration > Wireless > AP Management Each field is described in the following table. Table 28 Configuration > Wireless > AP Management L ABEL DESC RIPT IO N Radio 1 Setting Radio 1 Activate Select the check box to enable the Zyxel Device’s first (default) radio.
Page 111 Chapter 10 Wireless Table 28 Configuration > Wireless > AP Management (continued) L ABEL DESC RIPT IO N Radio 1 OP Mode Select the operating mode for radio 1. AP Mo de means the radio can receive connections from wireless clients and pass their data traffic through to the Zyxel Device to be managed (or subsequently passed on to an upstream gateway for managing).
Page 112 Chapter 10 Wireless Table 28 Configuration > Wireless > AP Management (continued) L ABEL DESC RIPT IO N Edit Click Edit icon ( )to open a screen where you can modify the entry’s settings. In some tables you can just click a table entry and edit it directly in the table. For those types of tables small red triangles display for table entries with changes that you have not yet applied.
Page 113: Rogue Ap
Chapter 10 Wireless Table 28 Configuration > Wireless > AP Management (continued) L ABEL DESC RIPT IO N Max Output Power Enter the maximum output power (between 0 to 30 dBm) of the Zyxel Device in this field. If there is a high density of APs in an area, decrease the output power of the Zyxel Device to reduce interference with other APs.
Page 114 Chapter 10 Wireless Fig ure 45 Rogue AP Example Frie ndly APs If you have more than one AP in your wireless network, you should also configure a list of “friendly” APs. Friendly APs are wireless access points that you know are not a threat. It is recommended that you export (save) your list of friendly APs often, especially if you have a network with a large number of access points.
Page 115 Chapter 10 Wireless Fig ure 46 Configuration > Wireless > Rogue AP (for Zyxel Devices that support Monitor mode) Fig ure 47 Configuration > Wireless > Rogue AP (for Zyxel Devices that support Rogue AP Detection) NWA/WAC/WAX Series User’s Guide...
Page 116: Add/Edit Rogue/Friendly List
Chapter 10 Wireless Each field is described in the following table. Table 29 Configuration > Wireless > Rogue AP L ABEL DESC RIPT IO N Rogue AP Detection Setting Enable Rogue AP Select this check box to detect Rogue APs in the network. Detection Suspected Rogue AP Select the check boxes (...
Page 117 Chapter 10 Wireless Each field is described in the following table. Table 30 Configuration > Wireless > Rogue AP > Add/Edit Rogue/Friendly AP List L ABEL DESC RIPT IO N Enter the MAC address of the AP you want to add to the list. A MAC address is a unique hardware identifier in the following hexadecimal format: xx:xx:xx:xx:xx:xx where xx is a hexadecimal number separated by colons.
Page 118 Chapter 10 Wireless Each field is described in the following table. Table 31 Configuration > Wireless > Load Balancing L ABEL DESC RIPT IO N Enable Load Select this to enable load balancing on the Zyxel Device. Balancing Use this section to configure wireless network traffic load balancing between the managed APs in this group.
Page 119 Chapter 10 Wireless 10.4.1 Disa sso c ia ting a nd De la ying C o nne c tio ns When your AP becomes overloaded, there are two basic responses it can take. The first one is to “delay” a client connection. This means that the AP withholds the connection until the data transfer throughput is lowered or the client connection is picked up by another AP.
Page 120: Dcs
Chapter 10 Wireless idle tim e o ut sig na l stre ng th Connections are cut based on either . The Zyxel Device first looks to see which devices have been idle the longest, then starts kicking them in order of highest idle time. If no connections are idle, the next criteria the Zyxel Device analyzes is signal strength.
Page 121 Chapter 10 Wireless Fig ure 53 An Example Three-Channel Deployment Three channels are situated in such a way as to create almost no interference with one another if used exclusively: 1, 6 and 11. When an AP broadcasts on any of these 3 channels, it should not interfere with neighboring APs as long as they are also limited to same trio.
Page 122 Chapter 10 Wireless available bandwidth to the point where each connecting device receives a meager trickle, the load balanced AP instead limits the incoming connections as a means to maintain bandwidth integrity. There are three kinds of wireless load balancing available on the Zyxel Device: L o a d b a la nc ing b y sta tio n num b e r limits the number of devices allowed to connect to your AP.
Page 123 HA PTER Blue to o th 11.1 O ve rvie w Use this screen to configure the iBeacon advertising settings for the Zyxel Device that supports Bluetooth Low Energy (BLE). Bluetooth Low Energy, which is also known as Bluetooth Smart, transmits less data over a shorter distance but consumes less power than classic Bluetooth.
Page 124 Chapter 11 Bluetooth 11.2 Blue to o th Adve rtising Se tting s The Zyxel Device communicates with another BLE enabled device for advertisements. Use this screen to configure up to five beacon IDs to be included in the advertising packet. To access this screen, click C o nfig ura tio n >...
Page 125 Chapter 11 Bluetooth Fig ure 75 Configuration > Bluetooth > Advertising Settings > Edit The following table describes the labels in this screen. Table 50 Configuration > Bluetooth > Advertising Settings > Edit L ABEL DESC RIPT IO N Activate Select this option to enable the advertising settings.
Page 126: User
HA PTER Use r 11.1 O ve rvie w This chapter describes how to set up user accounts and user settings for the Zyxel Device. 11.1.1 Wha t Yo u C a n Do in this C ha pte r •...
Page 127: User Summary
Chapter 11 User 11.2 Use r Sum m a ry Use r screen provides a summary of all user accounts. To access this screen click C o nfig ura tio n > O b je c t > Use r Fig ure 53 Configuration >...
Page 128 Chapter 11 User • - [dashes] The first character must be alphabetical (A-Z a-z), an underscore (_), or a dash (-). Other limitations on user names are: • User names are case-sensitive. If you enter a user 'bob' but use 'BOB' when connecting via CIFS or FTP, it will use the account settings used for 'BOB' not ‘bob’.
Page 129: Setting
Chapter 11 User Table 34 Configuration > User > User > Add/Edit A User (continued) L ABEL DESC RIPT IO N Authentication This field is not available if the user type is use r Timeout Settings If you want to set authentication timeout to a value other than the default settings, select Use Ma nua l Se tting s then fill your preferred values in the fields that follow.
Page 130 Chapter 11 User Fig ure 55 Configuration > Object > User > Setting The following table describes the labels in this screen. Table 35 Configuration > Object > User > Setting L ABEL DESC RIPT IO N User Default Setting Default Authentication These authentication timeout settings are used by default when you create a new Timeout Settings...
Page 131: Edit User Authentication Timeout Settings
Chapter 11 User Table 35 Configuration > Object > User > Setting (continued) L ABEL DESC RIPT IO N Limit the number of Select this check box if you want to set a limit on the number of simultaneous logins simultaneous logons for by admin users.
Page 132 Chapter 11 User The following table describes the labels in this screen. Table 36 User > Setting > Edit User Authentication Timeout Settings L ABEL DESC RIPT IO N User Type This read-only field identifies the type of user account for which you are configuring the default settings.
Page 133: Ap Profile
HA PTER AP Pro file 12.1 O ve rvie w This chapter shows you how to configure preset profiles for the Zyxel Device. 12.1.1 Wha t Yo u C a n Do in this C ha pte r • The Ra dio screen (Section 12.2 on page...
Page 134: Radio
Chapter 12 AP Profile WEP (Wired Equivalent Privacy) encryption scrambles all data packets transmitted between the AP and the wireless stations associated with it in order to keep network communications private. Both the wireless stations and the access points must use the same WEP key for data encryption and decryption. WPA2 WPA2 (IEEE 802.11i) is a wireless security standard that defines stronger encryption, authentication and key management than WPA.
Page 135: Add/Edit Radio Profile
Chapter 12 AP Profile Fig ure 57 Configuration > Object > AP Profile > Radio The following table describes the labels in this screen. Table 37 Configuration > Object > AP Profile > Radio L ABEL DESC RIPT IO N Click this to add a new radio profile.
Page 136 Chapter 12 AP Profile Fig ure 58 Configuration > Object > AP Profile > Radio > Add/Edit The following table describes the labels in this screen. Table 38 Configuration > Object > AP Profile > Radio > Add/Edit L ABEL DESC RIPT IO N Hide / Show Click this to hide or show the...
Page 137 Chapter 12 AP Profile Table 38 Configuration > Object > AP Profile > Radio > Add/Edit (continued) L ABEL DESC RIPT IO N 802.11 Mode Select how to let wireless clients connect to the AP. 802.11 Ba nd is set to 2.4G 11b / g •...
Page 138 Chapter 12 AP Profile Table 38 Configuration > Object > AP Profile > Radio > Add/Edit (continued) L ABEL DESC RIPT IO N Enable DCS This field is available when you set C ha nne l Se le c tio n DC S Client Aware Select this to have the Zyxel Device switch channels only when there are no clients...
Page 139 Chapter 12 AP Profile Table 38 Configuration > Object > AP Profile > Radio > Add/Edit (continued) L ABEL DESC RIPT IO N Time Interval Select this option to have the Zyxel Device survey the other APs within its broadcast radius at the end of the specified time interval.
Page 140 Chapter 12 AP Profile Table 38 Configuration > Object > AP Profile > Radio > Add/Edit (continued) L ABEL DESC RIPT IO N Enable Signal Select the check box to use the signal threshold to ensure wireless clients receive good Threshold throughput.
Page 141: Ssid
Chapter 12 AP Profile 12.3 SSID The SSID screens allow you to configure three different types of profiles for your networked APs: an SSID list, which can assign specific SSID configurations to your APs; a security list, which can assign specific encryption methods to the APs when allowing wireless clients to connect to them;...
Page 142: Add/Edit Ssid Profile
Chapter 12 AP Profile The following table describes the labels in this screen. Table 39 Configuration > Object > AP Profile > SSID > SSID List L ABEL DESC RIPT IO N Click this to add a new SSID profile. This button is not available after you configure the Zyxel Deviceusing the wizard.
Page 143 Chapter 12 AP Profile Fig ure 61 Configuration > Object > AP Profile > SSID > SSID List > Add/Edit SSID Profile The following table describes the labels in this screen. Table 40 Configuration > Object > AP Profile > SSID > SSID List > Add/Edit SSID Profile L ABEL DESC RIPT IO N Create new...
Page 144 Chapter 12 AP Profile Table 40 Configuration > Object > AP Profile > SSID > SSID List > Add/Edit SSID Profile (continued) L ABEL DESC RIPT IO N MAC Filtering Select a MAC filtering profile from the list to associate with this SSID. If none exist, you can use Profile C re a te ne w O b je c t menu to create one.
Page 145: Security List
Chapter 12 AP Profile Table 40 Configuration > Object > AP Profile > SSID > SSID List > Add/Edit SSID Profile (continued) L ABEL DESC RIPT IO N Enable Proxy ARP The Address Resolution Protocol (ARP) is a protocol for mapping an IP address to a MAC address.
Page 146: Add/Edit Security Profile
Chapter 12 AP Profile Table 41 Configuration > Object > AP Profile > SSID > Security List (continued) L ABEL DESC RIPT IO N Profile Name This field indicates the name assigned to the security profile. Security Mode This field indicates this profile’s security mode (if any). 12.4.1 Add/ Edit Se c urity Pro file This screen allows you to create a new security profile or edit an existing one.
Page 147 Chapter 12 AP Profile The following table describes the labels in this screen. Table 42 Configuration > Object > AP Profile > SSID > Security List > Add/Edit Security Profile> Security Mode: none L ABEL DESC RIPT IO N General Settings Profile Name Enter up to 31 alphanumeric characters for the profile name.
Page 148 Chapter 12 AP Profile Table 42 Configuration > Object > AP Profile > SSID > Security List > Add/Edit Security Profile> Security Mode: none (continued) L ABEL DESC RIPT IO N NAS Identifier If the RADIUS server requires the Zyxel Device to provide the NAS (Network Access Server) identifier attribute, enter it here.
Page 149 Chapter 12 AP Profile Table 43 Configuration > Object > AP Profile > SSID > Security List > Add/Edit Security Profile> Security Mode: enhanced- open (continued) L ABEL DESC RIPT IO N Advance Sho w Adva nc e d Se tting s Note: Click on the button to show the fields describe below.
Page 150 Chapter 12 AP Profile Fig ure 65 Configuration > Object > AP Profile > SSID > Security List > Add/Edit Security Profile> Security Mode: wep The following table describes the labels in this screen. Table 44 Configuration > Object > AP Profile > SSID > Security List > Add/Edit Security Profile> Security Mode: wep L ABEL DESC RIPT IO N...
Page 151 Chapter 12 AP Profile Table 44 Configuration > Object > AP Profile > SSID > Security List > Add/Edit Security Profile> Security Mode: wep (continued) L ABEL DESC RIPT IO N Authentication Settings Enterprise Select this to enable 802.1x secure authentication with a RADIUS server. ReAuthentication Enter the interval (in seconds) between authentication requests.
Page 152 Chapter 12 AP Profile Table 44 Configuration > Object > AP Profile > SSID > Security List > Add/Edit Security Profile> Security Mode: wep (continued) L ABEL DESC RIPT IO N Interim Update Specify the time interval for how often the Zyxel Device is to send a subscriber status Interval update to the accounting server.
Page 153 Chapter 12 AP Profile Fig ure 66 Configuration > Object > AP Profile > SSID > Security List > Add/Edit Security Profile> Security Mode: wpa2 The following table describes the labels in this screen. Table 45 Configuration > Object > AP Profile > SSID > Security List > AAdd/Edit Security Profile> Security Mode: wpa2 L ABEL DESC RIPT IO N...
Page 154 Chapter 12 AP Profile Table 45 Configuration > Object > AP Profile > SSID > Security List > AAdd/Edit Security Profile> Security Mode: wpa2 (continued) L ABEL DESC RIPT IO N Security Mode Select a security mode from the list: no ne e nha nc e d- o pe n we p...
Page 155 Chapter 12 AP Profile Table 45 Configuration > Object > AP Profile > SSID > Security List > AAdd/Edit Security Profile> Security Mode: wpa2 (continued) L ABEL DESC RIPT IO N Radius Server Secret Enter the shared secret password of the RADIUS server to be used for authentication. Primary / Secondary Select the check box to enable user accounting through an external authentication Accounting Server...
Page 156 Chapter 12 AP Profile Fig ure 67 Configuration > Object > AP Profile > SSID > Security List > Add/Edit Security Profile> Security Mode: wpa2-mix The following table describes the labels in this screen. Table 46 Configuration > Object > AP Profile > SSID > Security List > AAdd/Edit Security Profile> Security Mode: wpa2-mix L ABEL DESC RIPT IO N...
Page 157 Chapter 12 AP Profile Table 46 Configuration > Object > AP Profile > SSID > Security List > AAdd/Edit Security Profile> Security Mode: wpa2-mix (continued) L ABEL DESC RIPT IO N Security Mode Select a security mode from the list: no ne e nha nc e d- o pe n we p...
Page 158 Chapter 12 AP Profile Table 46 Configuration > Object > AP Profile > SSID > Security List > AAdd/Edit Security Profile> Security Mode: wpa2-mix (continued) L ABEL DESC RIPT IO N Accounting Interim This field is available only when you enable user accounting through an external Update authentication server.
Page 159 Chapter 12 AP Profile Fig ure 68 Configuration > Object > AP Profile > SSID > Security List > Add/Edit Security Profile> Security Mode: wpa3 The following table describes the labels in this screen. Table 47 Configuration > Object > AP Profile > SSID > Security List > Add/Edit Security Profile> Security Mode: wpa3 L ABEL DESC RIPT IO N...
Page 160 Chapter 12 AP Profile Table 47 Configuration > Object > AP Profile > SSID > Security List > Add/Edit Security Profile> Security Mode: wpa3 (continued) L ABEL DESC RIPT IO N Security Mode Select a security mode from the list: no ne e nha nc e d- o pe n we p...
Page 161: Mac Filter List
Chapter 12 AP Profile Table 47 Configuration > Object > AP Profile > SSID > Security List > Add/Edit Security Profile> Security Mode: wpa3 (continued) L ABEL DESC RIPT IO N Radius Server Secret Enter the shared secret password of the RADIUS server to be used for authentication. Primary / Secondary Select the check box to enable user accounting through an external authentication Accounting Server...
Page 162: Add/Edit Mac Filter Profile
Chapter 12 AP Profile The following table describes the labels in this screen. Table 48 Configuration > Object > AP Profile > SSID > MAC Filter List L ABEL DESC RIPT IO N Click this to add a new MAC filtering profile. Edit Click this to edit the selected MAC filtering profile.
Page 163 Chapter 12 AP Profile Table 49 Configuration > Object > AP Profile > SSID > MAC Filter List > Add/Edit MAC Filter Profile (continued) L ABEL DESC RIPT IO N Remove Click this to remove the selected MAC address from the profile’s list. This field is a sequential value, and it is not associated with a specific user.
Page 164 Chapter 12 AP Profile Fig ure 72 Configuration > Object > AP Profile > SSID > Layer-2 Isolation List The following table describes the labels in this screen. Table 50 Configuration > Object > AP Profile > SSID > Layer-2 Isolation List L ABEL DESC RIPT IO N Click this to add a new layer-2 isolation profile.
Page 165 Chapter 12 AP Profile The following table describes the labels in this screen. Table 51 Configuration > Object > AP Profile > SSID > Layer-2 Isolation List > Add/Edit Layer-2 Isolation Profile L ABEL DESC RIPT IO N Profile Name Enter up to 31 alphanumeric characters for the profile name.
Page 166 Chapter 12 AP Profile NWA/WAC/WAX Series User’s Guide...
Page 167 Chapter 12 AP Profile NWA/WAC/WAX Series User’s Guide...
Page 168 Chapter 12 AP Profile NWA/WAC/WAX Series User’s Guide...
Page 169 Chapter 12 AP Profile NWA/WAC/WAX Series User’s Guide...
Page 170 Chapter 12 AP Profile NWA/WAC/WAX Series User’s Guide...
Page 171: Mon Profile
HA PTER MO N Pro file 13.1 O ve rvie w This screen allows you to set up monitor mode configurations that allow your Zyxel Device to scan for other wireless devices in the vicinity. Once detected, you can use the Wire le ss >...
Page 172: Add/Edit Mon Profile
Chapter 13 MON Profile Table 50 Configuration > Object > MON Profile (continued) L ABEL DESC RIPT IO N Object Click this to view which other objects are linked to the selected monitor mode profile (for Reference example, an AP management profile). This field is a sequential value, and it is not associated with a specific profile.
Page 173 Chapter 13 MON Profile The following table describes the labels in this screen. Table 51 Configuration > Object > MON Profile > Add/Edit MON Profile L ABEL DESC RIPT IO N Activate Select this to activate this monitor mode profile. Profile Name This field indicates the name assigned to the monitor mode profile.
Page 174: Wds Profile
HA PTER WDS Pro file 14.1 O ve rvie w This chapter shows you how to configure WDS (Wireless Distribution System) profiles for the Zyxel Device to form a WDS with other APs. 14.1.1 Wha t Yo u C a n Do in this C ha pte r WDS Pro file screen (Section 14.2 on page...
Page 175: Add/Edit Wds Profile
Chapter 14 WDS Profile 14.2.1 Add/ Edit WDS Pro file This screen allows you to create a new WDS profile or edit an existing one. To access this screen, click the button or select and existing profile and click the Edit button.
Page 176: Certificates
HA PTER C e rtific a te s 15.1 O ve rvie w The Zyxel Device can use certificates (also called digital IDs) to authenticate users. Certificates are based on public-private key pairs. A certificate contains the certificate owner’s identity and public key. Certificates provide a way to exchange public keys for use in authentication.
Page 177 Chapter 15 Certificates Additionally, Jenny uses her own private key to sign a message and Tim uses Jenny’s public key to verify the message. The Zyxel Device uses certificates based on public-key cryptology to authenticate users attempting to establish a connection, not to encrypt the data that you send after establishing a connection. The method used to secure the data that you send through an established connection depends on the type of connection.
Page 178: Verifying A Certificate
Chapter 15 Certificates • Binary PKCS#12: This is a format for transferring public key and private key certificates.The private key in a PKCS #12 file is within a password-encrypted envelope. The file’s password is not connected to your certificate’s public or private passwords. Exporting a PKCS #12 file creates this and you must provide it to decrypt the contents when you import the file into the Zyxel Device.
Page 179: My Certificates
Chapter 15 Certificates 15.2 My C e rtific a te s Click C o nfig ura tio n > O b je c t > C e rtific a te > My C e rtific a te s to open this screen. This is the Zyxel Device’s summary list of certificates and certification requests.
Page 180: Add My Certificates
Chapter 15 Certificates Table 54 Configuration > Object > Certificate > My Certificates (continued) L ABEL DESC RIPT IO N Issuer This field displays identifying information about the certificate’s issuing certification authority, such as a common name, organizational unit or department, organization or company and Sub je c t country.
Page 181 Chapter 15 Certificates The following table describes the labels in this screen. Table 55 Configuration > Object > Certificate > My Certificates > Add L ABEL DESC RIPT IO N Name Type a name to identify this certificate. You can use up to 31 alphanumeric and ;‘~!@#$%^&()_+[]{}’,.=- characters.
Page 182: Edit My Certificates
Chapter 15 Certificates Table 55 Configuration > Object > Certificate > My Certificates > Add (continued) L ABEL DESC RIPT IO N Create a certification Select this to have the Zyxel Device generate a request for a certificate and apply to a request and enroll for certification authority for a certificate.
Page 183 Chapter 15 Certificates Fig ure 77 Configuration > Object > Certificate > My Certificates > Edit NWA/WAC/WAX Series User’s Guide...
Page 184 Chapter 15 Certificates The following table describes the labels in this screen. Table 56 Configuration > Object > Certificate > My Certificates > Edit L ABEL DESC RIPT IO N Name This field displays the identifying name of this certificate. You can use up to 31 alphanumeric and ;‘~!@#$%^&()_+[]{}’,.=- characters.
Page 185: Import Certificates
Chapter 15 Certificates Table 56 Configuration > Object > Certificate > My Certificates > Edit L ABEL DESC RIPT IO N MD5 Fingerprint This is the certificate’s message digest that the Zyxel Device calculated using the MD5 algorithm. SHA1 Fingerprint This is the certificate’s message digest that the Zyxel Device calculated using the SHA1 algorithm.
Page 186: Trusted Certificates
Chapter 15 Certificates Fig ure 78 Configuration > Object > Certificate > My Certificates > Import The following table describes the labels in this screen. Table 57 Configuration > Object > Certificate > My Certificates > Import L ABEL DESC RIPT IO N File Path Type in the location of the file you want to upload in this field or click Bro wse...
Page 187: Edit Trusted Certificates
Chapter 15 Certificates Fig ure 79 Configuration > Object > Certificate > Trusted Certificates The following table describes the labels in this screen. Table 58 Configuration > Object > Certificate > Trusted Certificates L ABEL DESC RIPT IO N PKI Storage Space This bar displays the percentage of the Zyxel Device’s PKI storage space that is currently in use.
Page 188 Chapter 15 Certificates authority. Fig ure 80 Configuration > Object > Certificate > Trusted Certificates > Edit NWA/WAC/WAX Series User’s Guide...
Page 189 Chapter 15 Certificates The following table describes the labels in this screen. Table 59 Configuration > Object > Certificate > Trusted Certificates > Edit L ABEL DESC RIPT IO N Name This field displays the identifying name of this certificate. You can change the name. You can use up to 31 alphanumeric and ;‘~!@#$%^&()_+[]{}’,.=- characters.
Page 190: Import Trusted Certificates
Chapter 15 Certificates Table 59 Configuration > Object > Certificate > Trusted Certificates > Edit (continued) L ABEL DESC RIPT IO N Valid From This field displays the date that the certificate becomes applicable. The text displays in red and includes a Not Yet Valid! message if the certificate has not yet become applicable. Valid To This field displays the date that the certificate expires.
Page 191: Technical Reference
Chapter 15 Certificates Fig ure 81 Configuration > Object > Certificate > Trusted Certificates > Import The following table describes the labels in this screen. Table 60 Configuration > Object > Certificate > Trusted Certificates > Import L ABEL DESC RIPT IO N Bro wse File Path Type in the location of the file you want to upload in this field or click...
Page 192: System
HA PTER Syste m 16.1 O ve rvie w Use the system screens to configure general Zyxel Device settings. 16.1.1 Wha t Yo u C a n Do in this C ha pte r • The Ho st Na m e screen (Section 16.2 on page 138) configures a unique name for the Zyxel Device in...
Page 193 Chapter 16 System The following table describes the labels in this screen. Table 61 Configuration > System > Host Name L ABEL DESC RIPT IO N System Name Choose a descriptive name to identify your Zyxel Device device. This name can be up to 64 alphanumeric characters long.
Page 194: Date And Time
Chapter 16 System 16.4 Da te a nd T im e For effective scheduling and logging, the Zyxel Device system time must be accurate. The Zyxel Device has a software mechanism to set the time manually or get the current time and date from an external server.
Page 195 Chapter 16 System Table 63 Configuration > System > Date/Time (continued) L ABEL DESC RIPT IO N New Date This field displays the last updated date from the time server or the last date configured (yyyy-mm-dd) manually. T im e a nd Da te Se tup Ma nua l When you set , enter the new date in this field and then click...
Page 196: Pre-Defined Ntp Time Servers List
Chapter 16 System 16.4.1 Pre - de fine d NT P T im e Se rve rs L ist When you turn on the Zyxel Device for the first time, the date and time start at 2003-01-01 00:00:00. The Zyxel Device then attempts to synchronize with one of the following pre-defined list of Network Time Protocol (NTP) time servers.
Page 197: Www Overview
Chapter 16 System To get the Zyxel Device date and time from a time server: Syste m > Da te / T im e Click Select G e t fro m T im e Se rve r under T im e a nd Da te Se tup Under T im e Zo ne Se tup , select your...
Page 198: Configuring Www Service Control
Chapter 16 System 16.5.3 HT T PS You can set the Zyxel Device to use HTTP or HTTPS (HTTPS adds security) for Web Configurator sessions. HTTPS (HyperText Transfer Protocol over Secure Socket Layer, or HTTP over SSL) is a web protocol that encrypts and decrypts web pages.
Page 199: Https Example
Chapter 16 System Fig ure 88 Configuration > System > WWW > Service Control The following table describes the labels in this screen. Table 65 Configuration > System > WWW > Service Control L ABEL DESC RIPT IO N HTTPS Enable Select the check box to allow or disallow the computer with the IP address that matches the IP address(es) in the...
Page 200 Chapter 16 System 16.5.5.1 G o o g le C hro m e Wa rning Me ssa g e s When you attempt to access the Zyxel Device HTTPS server, you will see the error message shown in the following screen. Fig ure 89 Security Alert Dialog Box (Google Chrome) Adva nc e d...
Page 201 Chapter 16 System Fig ure 90 Security Certificate 1 (Firefox) 16.5.5.3 Avo iding Bro wse r Wa rning Me ssa g e s Here are the main reasons your browser displays warnings about the Zyxel Device’s HTTPS server certificate and what you can do to avoid seeing the warnings: •...
Page 202 Chapter 16 System Fig ure 91 Trusted Certificates The CA sends you a package containing the CA’s trusted certificate(s), your personal certificate(s) and a password to install the personal certificate(s). 16.5.5.5 Insta lling a Pe rso na l C e rtific a te You need a password in advance.
Page 203 Chapter 16 System Enter the password given to you by the CA. Have the wizard determine where the certificate should be saved on your computer or select Pla c e a ll c e rtific a te s in the fo llo wing sto re and choose a different location.
Page 204 Chapter 16 System Finish Click to complete the wizard and begin the import process. You should see the following screen when the certificate is correctly installed on your computer. 16.5.5.6 Using a C e rtific a te Whe n Ac c e ssing the Zyxe l De vic e To access the Zyxel Device via HTTPS: NWA/WAC/WAX Series User’s Guide...
Page 205: Ssh
Chapter 16 System Enter ‘https://Zyxel Device IP Address/’ in your browser’s web address field. When Authe ntic a te C lie nt C e rtific a te s is selected on the Zyxel Device, the following screen asks you to select a personal certificate to send to the Zyxel Device.
Page 206: How Ssh Works
Chapter 16 System 16.6.1 Ho w SSH Wo rks The following figure is an example of how a secure connection is established between two remote hosts using SSH v1. Fig ure 93 How SSH v1 Works Example Host Identification The SSH client sends a connection request to the SSH server. The server identifies itself with a host key. The client encrypts a randomly generated session key with the host key and server key and sends the result back to the server.
Page 207: Ssh Implementation On The Zyxel Device
Chapter 16 System 16.6.2 SSH Im ple m e nta tio n o n the Zyxe l De vic e Your Zyxel Device supports SSH versions 1 and 2 using RSA authentication and four encryption methods (AES, 3DES, Archfour, and Blowfish). The SSH server is implemented on the Zyxel Device for management using port 22 (by default).
Page 208: Examples Of Secure Telnet Using Ssh
Chapter 16 System 16.6.5 Exa m ple s o f Se c ure T e lne t Using SSH This section shows two examples using a command interface and a graphical interface SSH client program to remotely access the Zyxel Device. The configuration and connection steps are similar for most SSH client programs.
Page 209 Chapter 16 System Fig ure 96 SSH Example 2: Test $ telnet 192.168.1.2 22 Trying 192.168.1.2... Connected to 192.168.1.2. Escape character is '^]'. SSH-1.5-1.0.0 Enter “ssh –2 192.168.1.2”. This command forces your computer to connect to the Zyxel Device using SSH version 1. If this is the first time you are connecting to the Zyxel Device using SSH, a message displays prompting you to save the host information of the Zyxel Device.
Page 210: Ftp
Chapter 16 System Table 67 Configuration > System > TELNET (continued) L ABEL DESC RIPT IO N Apply Click Apply to save your changes back to the Zyxel Device. Re se t Reset Click to return the screen to its last-saved settings. 16.8 FT P You can upload and download the Zyxel Device’s firmware and configuration files using FTP.
Page 211 Chapter 16 System 16.9 SNMP Simple Network Management Protocol is a protocol used for exchanging management information between network devices. Your Zyxel Device supports SNMP agent functionality, which allows a manager station to manage and monitor the Zyxel Device through the network. The Zyxel Device supports SNMP version one (SNMPv1), version two (SNMPv2c), and version three (SNMPv3).
Page 212 Chapter 16 System • Trap - Used by the agent to inform the manager of some events. 16.9.1 Suppo rte d MIBs The Zyxel Device supports MIB II that is defined in RFC-1213 and RFC-1215. The Zyxel Device also supports private MIBs (ZYXEL-ES-CAPWAP.MIB, ZYXEL-ES-COMMON.MIB, ZYXEL-ES-ZyXELAPMgmt.MIB, ZYXEL-ES- PROWLAN.MIB, ZYXEL-ES-RFMGMT.MIB, ZYXEL-ES-SMI.MIB, and ZYXEL-ES-WIRELESS.MIB) to collect information about CPU and memory usage and VPN total throughput.
Page 213 Chapter 16 System The following table describes the labels in this screen. Table 70 Configuration > System > SNMP L ABEL DESC RIPT IO N Enable Select the check box to allow or disallow users to access the Zyxel Device using SNMP. Server Port You may change the server port number for a service if needed, however you must use the same port number in order to use that service for remote management.
Page 214 Chapter 16 System Fig ure 102 Configuration > System > SNMP > Add The following table describes the labels in this screen. Table 71 Configuration > System > SNMP L ABEL DESC RIPT IO N User Name Select the user name of the user account for which this SNMPv3 user profile is configured. Authentication Select the type of authentication the SNMPv3 user must use to connect to the Zyxel Device using this SNMPv3 user profile.
Page 215: Log And Report
HA PTER L o g a nd Re po rt 17.1 O ve rvie w Use the system screens to configure daily reporting and log settings. 17.1.1 Wha t Yo u C a n Do In this C ha pte r •...
Page 216 Chapter 17 Log and Report Fig ure 98 Configuration > Log & Report > Email Daily Report The following table describes the labels in this screen. Table 67 Configuration > Log & Report > Email Daily Report L ABEL DESC RIPT IO N Enable Email Select this to send reports by e-mail every day.
Page 217: Log Setting
Chapter 17 Log and Report Table 67 Configuration > Log & Report > Email Daily Report (continued) L ABEL DESC RIPT IO N SSL/TLS Select SSL / T L S to use Secure Sockets Layer (SSL) or Transport Layer Security (TLS) if you want Encryption encrypted communications between the mail server and the Zyxel Device.
Page 218: Log Setting Screen
Chapter 17 Log and Report Sum m a ry screen to edit this information for all logs at the same time. 17.3.1 L o g Se tting Sc re e n C o nfig ura tio n > L o g & Re po rt > L o g Se tting To access this screen, click Fig ure 99 Configuration >...
Page 219: Edit System Log Settings
Chapter 17 Log and Report Table 68 Configuration > Log & Report > Log Setting (continued) L ABEL DESC RIPT IO N Log Format This field displays the format of the log. Inte rna l - system log; you can view the log on the Vie w L o g tab.
Page 220 Chapter 17 Log and Report Fig ure 100 Configuration > Log & Report > Log Setting > Edit System Log Setting NWA/WAC/WAX Series User’s Guide...
Page 221 Chapter 17 Log and Report The following table describes the labels in this screen. Table 69 Configuration > Log & Report > Log Setting > Edit System Log Setting L ABEL DESC RIPT IO N E-Mail Server 1/2 Active Select this to send log messages and alerts according to the information in this section. You specify what kinds of log messages are included in log information and what kinds of log messages are included in alerts in the Ac tive L o g a nd Ale rt...
Page 222 Chapter 17 Log and Report Table 69 Configuration > Log & Report > Log Setting > Edit System Log Setting (continued) L ABEL DESC RIPT IO N E-mail Server 1 Use the E- Ma il Se rve r 1 drop-down list to change the settings for e-mailing logs to e-mail server 1 for all log categories.
Page 223: Edit Remote Server
Chapter 17 Log and Report 17.3.3 Edit Re m o te Se rve r This screen controls the settings for each log in the remote server (syslog). Select a remote server entry in L o g Se tting screen and click the Edit icon.
Page 224: Active Log Summary
Chapter 17 Log and Report The following table describes the labels in this screen. Table 70 Configuration > Log & Report > Log Setting > Edit Remote Server L ABEL DESC RIPT IO N Log Settings for Remote Server Active Select this check box to send log information according to the information in this section.
Page 225 Chapter 17 Log and Report Fig ure 102 Active Log Summary This screen provides a different view and a different way of indicating which messages are included in De fa ult each log and each alert. (The category includes debugging messages generated by open source software.) The following table describes the fields in this screen.
Page 226 Chapter 17 Log and Report Table 71 Configuration > Log & Report > Log Setting > Active Log Summary (continued) L ABEL DESC RIPT IO N E-mail Server 1 Use the E- Ma il Se rve r 1 drop-down list to change the settings for e-mailing logs to e-mail server 1 for all log categories.
Page 227: File Manager
HA PTER File Ma na g e r 18.1 O ve rvie w Configuration files define the Zyxel Device’s settings. Shell scripts are files of commands that you can store on the Zyxel Device and run when you need them. You can apply a configuration file or run a shell script without the Zyxel Device restarting.
Page 228: Configuration File
Chapter 18 File Manager While configuration files and shell scripts have the same syntax, the Zyxel Device applies configuration files differently than it runs shell scripts. This is explained below. Table 71 Configuration Files and Shell Scripts in the Zyxel Device Configuration Files (.conf) Shell Scripts (.zysh) •...
Page 229 Chapter 18 File Manager Once your Zyxel Device is configured and functioning properly, it is highly recommended that you back up your configuration file before making further configuration changes. The backup configuration file will be useful in case you need to return to your previous settings. C o nfig ura tio n File Flo w a t Re sta rt •...
Page 230 Chapter 18 File Manager The following table describes the labels in this screen. Table 72 Maintenance > File Manager > Configuration File L ABEL DESC RIPT IO N Rename Use this button to change the label of a configuration file on the Zyxel Device. You can only la stg o o d.c o nf syste m - rename manually saved configuration files.
Page 231 Chapter 18 File Manager Table 72 Maintenance > File Manager > Configuration File (continued) L ABEL DESC RIPT IO N Apply Use this button to have the Zyxel Device use a specific configuration file. Click a configuration file’s row to select it and click Apply to have the Zyxel Device use that configuration file.
Page 232: Example Of Configuration File Download Using Ftp
Chapter 18 File Manager Table 72 Maintenance > File Manager > Configuration File (continued) L ABEL DESC RIPT IO N Last Modified This column displays the date and time that the individual configuration files were last changed or saved. Upload The bottom part of the screen allows you to upload a new or previously saved configuration file Configuration File from your computer to your Zyxel Device.
Page 233: Firmware Package
Chapter 18 File Manager C:\>ftp 192.168.1.2 Connected to 192.168.1.2. 220---------- Welcome to Pure-FTPd [privsep] [TLS] ---------- 220-You are user number 1 of 5 allowed. 220-Local time is now 21:28. Server port: 21. 220-This is a private system - No anonymous login 220 You will be disconnected after 600 minutes of inactivity.
Page 234: Example Of Firmware Upload Using Ftp
Chapter 18 File Manager Fig ure 104 Maintenance > File Manager > Firmware Package The following table describes the labels in this screen. Table 73 Maintenance > File Manager > Firmware Package L ABEL DESC RIPT IO N Boot Module This is the version of the boot module that is currently on the Zyxel Device.
Page 235: Shell Script
Chapter 18 File Manager Use an FTP client on your computer to connect to the Zyxel Device. For example, in the Windows command prompt, type ftp 192.168.1.2. Keep the console session connected in order to see when the firmware recovery finishes. Enter your user name when prompted.
Page 236 Chapter 18 File Manager Fig ure 106 Maintenance > File Manager > Shell Script Each field is described in the following table. Table 74 Maintenance > File Manager > Shell Script L ABEL DESC RIPT IO N Rename Use this button to change the label of a shell script file on the Zyxel Device. You cannot rename a shell script to the name of another shell script in the Zyxel Device.
Page 237 Chapter 18 File Manager Table 74 Maintenance > File Manager > Shell Script (continued) L ABEL DESC RIPT IO N Browse... Click Bro wse ... to find the .zysh file you want to upload. Uplo a d Upload Click to begin the upload process. This process may take up to several minutes. NWA/WAC/WAX Series User’s Guide...
Page 238: Diagnostics
HA PTER Dia g no stic s 19.1 O ve rvie w Use the diagnostics screen for troubleshooting. 19.1.1 Wha t Yo u C a n Do in this C ha pte r Dia g no stic s screen (Section 19.2 on page 178) generates a file containing the Zyxel Device’s configuration and diagnostic information if you need to provide it to customer support during troubleshooting.
Page 239: Remote Capture
Chapter 19 Diagnostics Fig ure 108 Maintenance > Diagnostics: Debug Information Collector 19.3 Re m o te C a pture Use this screen to capture network traffic going through the Zyxel Device connected to the Zyxel gateway or ZyWALL, and output the captured packets to a packet analyzer (also known as network or protocol analyzer) such as Wireshark.
Page 240: Leds
HA PTER L EDs 20.1 O ve rvie w The LEDs of your Zyxel Device can be controlled such that they stay lit (ON) or OFF after the Zyxel Device L o c a to r Suppre ssio n is ready. There are two features that control the LEDs of your Zyxel Device - (see Section 1.4 on page 18).
Page 241: Locator Screen
Chapter 20 LEDs Fig ure 110 Maintenance > LEDs > Suppression The following table describes fields in the above screen. Table 76 Maintenance > LED > Suppression L ABEL DESC RIPT IO N Suppression On If the Suppre ssio n O n check box is checked, the LEDs of your Zyxel Device will turn off after it’s ready.
Page 242 Chapter 20 LEDs Fig ure 111 Maintenance > LEDs > Locator The following table describes fields in the above screen. Table 77 Maintenance > LED > Locator L ABEL DESC RIPT IO N Turn On Click T urn O n button to activate the locator.
Page 243 HA PTER Ante nna Switc h 22.1 O ve rvie w Use this screen to adjust coverage depending on the orientation of the antenna. 22.1.1 Wha t Yo u Ne e d T o Kno w Positioning the antennas properly increases the range and coverage area of a wireless LAN. On the Zyxel Device that comes with internal antennas and also has an antenna switch, you can adjust coverage depending on the antenna orientation for the Zyxel Device radios using the web configurator, the command line interface (CLI) or a physical switch.
Page 244 Chapter 22 Antenna Switch Fig ure 152 Maintenance > Antenna > Antenna Switch (Per Radio) Fig ure 153 Maintenance > Antenna > Antenna Switch (Per AP) If the Zyxel Device has a physical antenna switch, select the Ena b le So ftwa re C o ntro l option to use the Web Configurator to adjust coverage depending on each radio’s antenna orientation for better coverage.
Page 245: Reboot
HA PTER Re b o o t 21.1 O ve rvie w Use this screen to restart the Zyxel Device. 21.1.1 Wha t Yo u Ne e d T o Kno w If you applied changes in the Web Configurator, these were saved automatically and do not change when you reboot.
Page 246: Shutdown
HA PTER Shutdo wn 22.1 O ve rvie w Use this screen to shut down the Zyxel Device. Alwa ys use Ma inte na nc e > Shutdo wn > Shutdo wn o r the shutdown c o m m a nd b e fo re yo u turn o ff the Zyxe l De vic e o r re m o ve the po we r. No t do ing so c a n c a use the firm wa re to b e c o m e c o rrupt.
Page 247: L O C A L C O Nfig Ura Tio N In C Lo Ud Mo De
A RT L o c a l C o nfig ura tio n in C lo ud Mo de...
Page 248: Cloud Mode
HA PTER C lo ud Mo de 23.1 O ve rvie w The Zyxel Device is managed and provisioned automatically by the when NCC (Ne b ula Co ntro l Ce nte r) it is connected to the Internet and has been registered in the NCC. If you need to change the Zyxel Device’s VLAN setting or manually set its IP address, access its simplified web configurator (see Chapter 4 on page...
Page 249: Dashboard
Chapter 23 Cloud Mode • Ma inte na nc e > She ll Sc ript • Ma inte na nc e > Dia g no stic s • Ma inte na nc e > L o g These screens also have fewer options than those in standalone Zyxel Devices. The rest of the Zyxel Device’s features must be configured through the NCC.
Page 250 Table 78 Dashboard (continued) L ABEL DESC RIPT IO N Nebula Control This field displays whether the Zyxel Device has been registered and can be managed by Center the NCC. Activation Status Use Proxy to This displays whether the NAP uses a proxy server to access the NCC (Nebula Control Access NCC Center).
Page 251: Network
HA PTER Ne two rk 24.1 O ve rvie w This chapter describes how you can configure the management IP address and VLAN settings of your Zyxel Device in cloud mode. Section 9.1 on page 69 for information about IP addresses. Note: Make sure your VLAN settings allow the Zyxel Device to connect to the Internet so you could manage it with NCC.
Page 252 Chapter 24 Network Fig ure 116 Configuration > Network > IP Setting Each field is described in the following table. Table 79 Configuration > Network > IP Setting L ABEL DESC RIPT IO N IP Address Assignment Select this to make the interface a DHCP client and automatically get the IP address, Automatically subnet mask, and gateway address from a DHCP server.
Page 253 Chapter 24 Network 24.3 VL AN This section discusses how to configure the Zyxel Device’s VLAN settings. See Section 9.3 on page 71 more information about VLAN. Use this screen to configure the VLAN settings for your Zyxel Device. To access this screen, click C o nfig ura tio n >...
Page 254: Maintenance
HA PTER Ma inte na nc e 25.1 O ve rvie w When the Zyxel Device is set to work in cloud mode, the Ma inte na nc e screens let you mange shell script files on the Zyxel Device, generate a diagnostic file, or view log messages. Chapter 18 on page 167 for information about shell scripts.
Page 255: Diagnostics
Chapter 25 Maintenance Each field is described in the following table. Table 81 Maintenance > Shell Script L ABEL DESC RIPT IO N Rename Use this button to change the label of a shell script file on the Zyxel Device. You cannot rename a shell script to the name of another shell script in the Zyxel Device.
Page 256: View Log
Chapter 25 Maintenance Fig ure 119 Maintenance > Diagnostics De b ug Info rm a tio n C e nte r screen then displays showing whether the collection is in progress, was successful, or has failed. When the data collection is done, click Do wnlo a d to save the most recent diagnostic file to a computer.
Page 257 Chapter 25 Maintenance Fig ure 121 Maintenance > Log > View Log The following table describes the labels in this screen. Table 82 Maintenance > Log > View Log L ABEL DESC RIPT IO N Show Filter / Hide Click this button to show or hide the filter settings. Filter If the filter settings are hidden, the Displa y...
Page 258 Chapter 25 Maintenance Table 82 Maintenance > Log > View Log (continued) L ABEL DESC RIPT IO N Refresh Click this to update the list of logs. Clear Log Click this button to clear the whole log, regardless of what is currently displayed on the screen. This field is a sequential value, and it is not associated with a specific log message.
Page 259: Appe Ndic E S A Nd T Ro Ub Le Sho O Ting
A RT Appe ndic e s a nd T ro ub le sho o ting...
Page 260: Overview
HA PTER T ro ub le sho o ting 26.1 O ve rvie w This chapter offers some suggestions to solve problems you might encounter. The potential problems are divided into the following categories. • Power, Hardware Connections, and LED •...
Page 261: Zyxel Device Management, Access, And Login
Chapter 26 Troubleshooting Disconnect and re-connect the power adapter or PoE power injector to the Zyxel Device. If the problem continues, contact the vendor. 26.3 Zyxe l De vic e Ma na g e m e nt, Ac c e ss, a nd L o g in I forgot the IP address for the Zyxel Device.
Page 262 Chapter 26 Troubleshooting If the problem continues, contact the network administrator or vendor, or try one of the advanced suggestions. Adva nc e d Sug g e stio ns • Try to access the Zyxel Device using another service, such as Telnet. If you can access the Zyxel Device, check the remote management settings to find out why the Zyxel Device does not respond to HTTP.
Page 263 Chapter 26 Troubleshooting NC C Disc o ve ry I enabled , but the Zyxel Device is still in standalone mode. Make sure your Zyxel Device is registered to the NCC. The Zyxel Device is already registered with NCC, but it is still in standalone mode; it cannot connect to the NCC.
Page 264 Chapter 26 Troubleshooting Make sure that the Zyxel Device and the AC are both in the same subnet. If you have to set them up in different subnets, see AC management and IP Subnets on page 104. I accidentally pressed the Nebula button in the NXC’s Web Configurator. How do I undo it? If the Zyxel Device is not registered with the NCC, register it first.
Page 265: Internet Access
Chapter 26 Troubleshooting I cannot upload the firmware uploaded using FTP. The Web Configurator is the recommended method for uploading firmware in standalone mode. For managed Zyxel Devices, using the NCC or AC is recommended. You only need to use FTP if you need to recover the firmware.
Page 266: Wifi Network
Chapter 26 Troubleshooting If the problem continues, contact the network administrator or vendor. 26.5 WiFi Ne two rk I cannot access the Zyxel Device or ping any computer from the WLAN. Make sure the wireless LAN (wireless radio) is enabled on the Zyxel Device. Make sure the radio or at least one of the Zyxel Device’s radios is operating in AP mode.
Page 267: Resetting The Zyxel Device
Chapter 26 Troubleshooting Any certificate that you want to import has to be in one of these file formats: • Binary X.509: This is an ITU-T recommendation that defines the formats for X.509 certificates. • PEM (Base-64) encoded X.509: This Privacy Enhanced Mail format uses lowercase letters, uppercase letters and numerals to convert a binary X.509 certificate into a printable form.
Page 268: Getting More Troubleshooting Help
Chapter 26 Troubleshooting Note: This procedure removes the current configuration. Make sure the Power LED is on and not blinking. Press the RESET button and hold it until the Power LED begins to blink. (This usually takes about ten seconds.) Release the RESET button, and wait for the Zyxel Device to restart.
Page 269 PPEN DIX Im po rting C e rtific a te s This appendix shows you how to import public key certificates into your web browser. Public key certificates are used by web browsers to ensure that a secure web site is legitimate. When a certificate authority such as VeriSign, Comodo, or Network Solutions, to name a few, receives a certificate request from a website operator, they confirm that the web domain and contact information in the request match those on public record with a domain name registrar.
Page 270: Appendix A Importing Certificates
Appendix A Importing Certificates Expo rt a C e rtific a te If your device’s Web Configurator is set to use SSL certification, then upon browsing with it for the first time, you are presented with a certification error. NWA/WAC/WAX Series User’s Guide...
Page 271 Appendix A Importing Certificates Click Adva nc e d > Pro c e e d to (unsa fe ) x.x.x.x In the Addre ss Ba r , click No t Se c ure > C e rtific a te (Inva lid) NWA/WAC/WAX Series User’s Guide...
Page 272 Appendix A Importing Certificates C e rtific a te De ta ils > C o py to File In the dialog box, click In the C e rtific a te Expo rt Wiza rd , click Ne xt NWA/WAC/WAX Series User’s Guide...
Page 273 Appendix A Importing Certificates Select the format and settings you want to use and then click Ne xt Ne xt Type a filename and specify a folder to save the certificate in. Click NWA/WAC/WAX Series User’s Guide...
Page 274 Appendix A Importing Certificates In the C o m ple ting the C e rtific a te Expo rt Wiza rd screen, click Finish Finally, click when presented with the successful certificate export message. Im po rt a C e rtific a te After storing the certificate in your computer (see Export a Certificate), you need to install it as a trusted...
Page 275 Appendix A Importing Certificates Open your web browser, click the menu icon, and click Se tting s NWA/WAC/WAX Series User’s Guide...
Page 276 Appendix A Importing Certificates Adva nc e d Priva c y a nd se c urity Ma na g e Scroll down and click to expand the menu. Under , click c e rtific a te s NWA/WAC/WAX Series User’s Guide...
Page 277 Appendix A Importing Certificates In the C e rtific a te s pop-up screen, click T ruste d Ro o t C e rtific a tio n Autho ritie s . Click Im po rt to start the C e rtific a te Im po rt Wiza rd Ne xt Bro wse Click...
Page 278 Appendix A Importing Certificates Select the certificate file you want to import and click O pe n Click Ne xt. NWA/WAC/WAX Series User’s Guide...
Page 279 Appendix A Importing Certificates Confirm the settings displayed and click Finish Ye s If presented with a security warning, click NWA/WAC/WAX Series User’s Guide...
Page 280 Appendix A Importing Certificates Finally, click when you are notified of the successful import. Insta ll a Sta nd- Alo ne C e rtific a te File Rather than installing a public key certificate using web browser settings, you can install a stand-alone certificate file if one has been issued to you.
Page 281 Appendix A Importing Certificates Click Ne xt on the first wizard screen, click Pla c e a ll c e rtific a te s in the fo llo wing sto re , and click Bro wse Select T ruste d Ro o t C e rtific a te Autho ritie s >...
Page 282 Appendix A Importing Certificates Confirm the information shown on the final wizard screen and click Finish If presented with a security warning, click Ye s NWA/WAC/WAX Series User’s Guide...
Page 283 Appendix A Importing Certificates Finally, click when you are notified of the successful import. Re m o ve a C e rtific a te in G o o g le C hro m e This section shows you how to remove a public key certificate in Google Chrome on Windows 7. Open your web browser, click the menu icon, and click Se tting s NWA/WAC/WAX Series User’s Guide...
Page 284 Appendix A Importing Certificates Scroll down and click Adva nc e d to expand the menu. Under Priva c y a nd se c urity , click Ma na g e c e rtific a te s T ruste d Ro o t C e rtific a tio n Autho ritie s In the Certificates pop-up screen, click NWA/WAC/WAX Series User’s Guide...
Page 285 Appendix A Importing Certificates Select the certificate you want to remove and click Re m o ve Ye s Click when you see the following warning message. Confirm the details displayed in the warning message and click Ye s Fire fo x The following example uses Mozilla Firefox on Windows 7.
Page 286 Appendix A Importing Certificates Expo rt a C e rtific a te If your device’s Web Configurator is set to use SSL certification, then the first time you browse to it you are presented with a certification error. Click Adva nc e d Vie w C e rtific a te .
Page 287 Appendix A Importing Certificates Click De ta ils > Expo rt. Type a filename and click Sa ve Im po rt a C e rtific a te After storing the certificate in your computer, you need to import it in trusted root certification authorities using the following steps: NWA/WAC/WAX Series User’s Guide...
Page 288 Appendix A Importing Certificates Open Fire fo x and click T o o ls > O ptio ns NWA/WAC/WAX Series User’s Guide...
Page 289 Appendix A Importing Certificates In the O ptio ns page, click Priva c y & Se c urity , scroll to the bottom of the page, and then click Vie w C e rtific a te s In the C e rtific a te Ma na g e r , click Autho ritie s >...
Page 290 Appendix A Importing Certificates Use the Se le c t File dialog box to locate the certificate and then click O pe n Select T rust this C A to ide ntify we b site s and click Re m o ving a C e rtific a te in Fire fo x This section shows you how to remove a public key certificate in Firefox.
Page 291 Appendix A Importing Certificates Open Fire fo x and click T o o ls > O ptio ns In the O ptio ns page, click Priva c y & Se c urity , scroll to the bottom of the page, and then click Vie w C e rtific a te s NWA/WAC/WAX Series User’s Guide...
Page 292 Appendix A Importing Certificates In the C e rtific a te Ma na g e r , click Autho ritie s and select the certificate you want to remove. Click De le te o r Distrust In the following dialog box, click The next time you go to the web site that issued the public key certificate you just removed, a certification error appears.
Page 293: Appendix B Ipv6
PPEN DIX IPv6 O ve rvie w IPv6 (Internet Protocol version 6), is designed to enhance IP address size and features. The increase in IPv6 address size to 128 bits (from the 32-bit IPv4 address) allows up to 3.4 x 10 IP addresses.
Page 294 Appendix B IPv6 Unspe c ifie d Addre ss An unspecified address (0:0:0:0:0:0:0:0 or ::) is used as the source address when a device does not have its own address. It is similar to “0.0.0.0” in IPv4. L o o pb a c k Addre ss A loopback address (0:0:0:0:0:0:0:1 or ::1) allows a host to send packets to itself.
Page 295 Appendix B IPv6 Sub ne t Ma sking Both an IPv6 address and IPv6 subnet mask compose of 128-bit binary digits, which are divided into eight 16-bit blocks and written in hexadecimal notation. Hexadecimal uses four bits for each character (1 ~ 10, A ~ F).
Page 296 Appendix B IPv6 Each DHCP client and server has a unique DHCP Unique IDentifier (DUID), which is used for identification when they are exchanging DHCPv6 messages. The DUID is generated from the MAC address, time, vendor assigned ID and/or the vendor's private enterprise number registered with the IANA. It should not change over time even after you reboot the device.
Page 297 Appendix B IPv6 IC MPv6 Internet Control Message Protocol for IPv6 (ICMPv6 or ICMP for IPv6) is defined in RFC 4443. ICMPv6 has a preceding Next Header value of 58, which is different from the value used to identify ICMP for IPv4. ICMPv6 is an integral part of IPv6.
Page 298 Appendix B IPv6 multicast packets and the IP addresses of multicast groups the hosts want to join on its network. MLD snooping and MLD proxy are analogous to IGMP snooping and IGMP proxy in IPv4. MLD filtering controls which multicast groups a port can join. ML D Me ssa g e s A multicast router or switch periodically sends general queries to MLD hosts to update the multicast forwarding table.
Page 299 Appendix B IPv6 Install Dibbler and select the DHCPv6 client option on your computer. Sta rt All Pro g ra m s Dib b le r- DHC Pv6 C lie nt Insta ll a s se rvic e After the installation is complete, select >...
Page 300 Appendix B IPv6 C o ntro l Pa ne l Ne two rk a nd Sha ring C e nte r L o c a l Are a C o nne c tio n Select > > Select the Inte rne t Pro to c o l Ve rsio n 6 (T C P/ IPv6) checkbox to enable it.
Page 301 C o rpo ra te He a dq ua rte rs (Wo rldwide ) T a iwa n • Zyxel Communications Corporation • http://www.zyxel.com Asia C hina • Zyxel Communications (Shanghai) Corp. Zyxel Communications (Beijing) Corp. Zyxel Communications (Tianjin) Corp. • https://www.zyxel.com/cn/zh/ India • Zyxel Technology India Pvt Ltd •...
Page 302: Appendix C Customer Support
• Zyxel Communications Corporation • https://www.zyxel.com/tw/zh/ T ha ila nd • Zyxel Thailand Co., Ltd • https://www.zyxel.com/th/th/ Vie tna m • Zyxel Communications Corporation-Vietnam Office • https://www.zyxel.com/vn/vi Euro pe Be la rus • Zyxel BY • https://www.zyxel.by Be lg ium •...
Page 303 Appendix C Customer Support • https://www.zyxel.com/be/fr/ Bulg a ria • Zyxel България • https://www.zyxel.com/bg/bg/ C ze c h Re pub lic • Zyxel Communications Czech s.r.o • https://www.zyxel.com/cz/cs/ De nm a rk • Zyxel Communications A/S • https://www.zyxel.com/dk/da/ Esto nia •...
Page 304 Ro m a nia • Zyxel Romania • https://www.zyxel.com/ro/ro Russia • Zyxel Russia • https://www.zyxel.com/ru/ru/ Slo va kia • Zyxel Communications Czech s.r.o. organizacna zlozka • https://www.zyxel.com/sk/sk/ Spa in • Zyxel Communications ES Ltd • https://www.zyxel.com/es/es/ Swe de n • Zyxel Communications •...
Page 305 Appendix C Customer Support T urke y • Zyxel Turkey A.S. • https://www.zyxel.com/tr/tr/ • Zyxel Communications UK Ltd. • https://www.zyxel.com/uk/en/ Ukra ine • Zyxel Ukraine • http://www.ua.zyxel.com So uth Am e ric a Arg e ntina • Zyxel Communications Corporation •...
Page 306 Appendix C Customer Support Middle Ea st • Zyxel Communications Corporation • https://www.zyxel.com/me/en/ No rth Am e ric a • Zyxel Communications, Inc. - North America Headquarters • https://www.zyxel.com/us/en/ O c e a nia Austra lia • Zyxel Communications Corporation •...
Page 307 PPEN DIX L e g a l Info rm a tio n C o pyrig ht Copyright © 2021 by Zyxel and/ or its affiliates The contents of this publication may not be reproduced in any part or as a whole, transcribed, stored in a retrieval system, translated into any language, or transmitted in any form or by any means, electronic, mechanical, magnetic, optical, chemical, photocopying, manual, or otherwise, without the prior written permission of Zyxel and/ or its affiliates.
Page 308: Appendix D Legal Information
Appendix D Legal Information BRAZIL The following applies if you use the product within Brazil. Este equipamento opera em caráter secundário, isto é, não tem direito a proteção contra interferência prejudicial, mesmo de estações do mesmo tipo, e não pode causar interferência a sistemas operando em caráter primário. C ANA DA The following information applies if you use the product within Canada area.
Page 309 Appendix D Legal Information Ante nna Info rm a tio n ANT ENNA MO DEL NO . T YPE C O NNEC T O R 2.4 G G AIN (dBi) 5G G AIN (dBi) REMARK NWA1123-ACv2 PIFA 3.08 PIFA 3.07 PIFA 4.06 (5150~5250 MHz) 3.79 (5725~5850 MHz)
Page 310 Appendix D Legal Information ANT ENNA MO DEL NO . T YPE C O NNEC T O R 2.4 G G AIN (dBi) 5G G AIN (dBi) REMARK WAC5302D-S Loop I-PEX 5.82 (2400-2483.5 MHz) Loop I-PEX 5.02 (2400-2483.5 MHz) PIFA I-PEX 5 (5150-5250 MHz) 5 (5250-5350 MHz)
Page 311 Appendix D Legal Information • Where applicable, antenna type(s), antenna model(s), and the worst-case tilt angle(s) necessary to remain compliant with the e.i.r.p. elevation mask requirement set forth in Section 6.2.2.3 of RSS 247 shall be clearly indicated. If the product with 5G wireless function operating in 5250-5350 MHz and 5470-5725 MHz, the following attention must be paid. •...
Page 312 Appendix D Legal Information Informations Anten MO DÈL E D'ANT ENNE T YPE C O NNEC T EUR 2.4 G G AIN (dBi) 5G G AIN (dBi) REMARQ UE NWA1123-ACv2 PIFA 3.08 PIFA 3.07 PIFA 4.06 (5150~5250 MHz) 3.79 (5725~5850 MHz) PIFA 3.99 (5150~5250 MHz) 3.78 (5725~5850 MHz)
Page 313 Appendix D Legal Information MO DÈL E D'ANT ENNE T YPE C O NNEC T EUR 2.4 G G AIN (dBi) 5G G AIN (dBi) REMARQ UE WAC5302D-S Loop I-PEX 5.82 (2400-2483.5 MHz) Loop I-PEX 5.02 (2400-2483.5 MHz) PIFA I-PEX 5 (5150-5250 MHz) 5 (5250-5350 MHz) 5 (5470-5725 MHz)
Page 314 Appendix D Legal Information • Pour les dispositifs munis d'antennes amovibles, le gain maximal d'antenne permis (pour les dispositifs utilisant la bande de 5 725 à 5 850 MHz) doit être conforme à la limite de la p.i.r.e. spécifiée pour l'exploitation point à point et l’exploitation non point à point, selon le cas; •...
Page 315 Appendix D Legal Information NWA1123- AC v2 a nd NWA5123- AC • The band 2,400 MHz to 2,483.5 MHz is 97.95 mW, • The band 5,150 MHz to 5,350 MHz is 199.07 mW, • The band 5,470 MHz to 5,725 MHz is 743.02 mW. WAC 6503D- S •...
Page 316 Appendix D Legal Information • The band 5,470 MHz to 5,725 MHz is 889.2 mW. Български С настоящото Zyxel декларира, че това оборудване е в съответствие със съществените изисквания и другите приложими разпоредбите на Директива 2014/53/ЕC. (Bulgarian) Na tio na l Re stric tio ns •...
Page 317 RF exposure requirement. External antenna Use only the antennas which have been approved by Zyxel Communications Corporation. The non-approved antenna(s) may produce unwanted spurious or excessive RF transmitting power which may lead to the violation of FCC/IC limit and is prohibited.
Page 318 Appendix D Legal Information Instruc tio ns d'insta lla tio n pro fe ssio nne lle (WAC 6553D- E) Veuillez noter que l'appareil etant dedie a une fonction unique, il doit etre utilise avec notre logiciel proprietaire de divertissement interactif . Ce produit sera propose par un reseau de distribution controle et installe par des professionels;...
Page 319 Appendix D Legal Information Die folgende Symbol bedeutet, dass Ihr Produkt und/oder seine Batterie gemäß den örtlichen Bestimmungen getrennt vom Hausmüll entsorgt werden muss. Wenden Sie sich an eine Recyclingstation, wenn dieses Produkt das Ende seiner Lebensdauer erreicht hat. Zum Zeitpunkt der Entsorgung wird die getrennte Sammlung von Produkt und/oder seiner Batterie dazu beitragen, natürliche Ressourcen zu sparen und die Umwelt und die menschliche Gesundheit zu schützen.
Page 320 Appendix D Legal Information • 假若電源變壓器或電源變壓器的纜線損壞，請從插座拔除，若您還繼續插電使用，會有觸電死亡的風險。 • 請勿試圖修理電源變壓器或電源變壓器的纜線，若有毀損，請直接聯絡您購買的店家，購買⼀個新的電源變壓器。 • 請勿將此設備安裝於室外，此設備僅適合放置於室內。 • 請勿隨⼀般垃圾丟棄。 • 請參閱產品背貼上的設備額定功率。 • 請參考產品型錄或是彩盒上的作業溫度。 • 產品沒有斷電裝置或者採用電源線的插頭視為斷電裝置的⼀部分，以下警語將適用 : －對永久連接之設備，在設備外部須安裝可觸及之斷電裝置；－對插接式之設備，插座必須接近安裝之地點而且是易於觸及的。 Ab o ut the Sym b o ls Various symbols are used in this product to ensure correct usage, to prevent danger to the user and others, and to prevent property damage. The meaning of these symbols are described below.
Page 321 Index Inde x Symbols Numbers and certificates CA (Certificate Authority), see certificates 802.11k 158, 164 CEF (Common Event Format) 802.11r Certificate Authority (CA) 802.11v see certificates Certificate Management Protocol (CMP) Certificate Revocation List (CRL) vs OCSP certificates AC. See AP Controller advantages of access and CA...
Page 322 Index messages dual radios popup window dual-radio application Reference Guide dynamic channel selection cold start commands sent by Web Configurator 158, 164 Common Event Format (CEF) configuration encryption 178, 193 information ESSID configuration files Extended Service Set IDentification at restart backing up downloading downloading with FTP...
Page 323 Index vs HTTPS HTTPS and certificates key pairs authenticating clients avoiding warning messages example vs HTTP with Internet Explorer 169, 171 with Netscape Navigator lastgood.conf HyperText Transfer Protocol over Secure Socket Layer, LED suppression see HTTPS LEDs Locator LED log messages 162, 164, 165, 166 categories debugging...
Page 324 Index My Certificates, see also certificates reset vs reboot vs shutdown 43, 205 RESET button restart RF interference NCC, see Nebula Control Center RF monitor, see Radio Frequency Monitor Nebula Control Center Netscape Navigator 2510 (Certificate Management Protocol or Network Time Protocol (NTP) CMP) Rivest, Shamir and Adleman public-key algorithm (RSA)
Page 325 Index 175, 192 with Linux shell scripts with Microsoft Windows usage 45, 47 SSID flash SSID profile 45, 48 memory pre-configured onboard flash SSID profiles user authentication user name starting the device rules startup-config.conf user objects if errors users missing at restart access, see also access users present at restart admin (type)
Page 326 Index WEP (Wired Equivalent Privacy) wireless channel wireless client Wireless Distribution System (WDS) wireless LAN wireless network example overview wireless profile layer-2 isolation MAC filtering radio security SSID 16, 203 wireless security wireless station Wizard Setup WLAN interface WPA2 and certificates see also HTTP, HTTPS ZON Utility Zyxel Discovery Protocol...

This manual is also suitable for:

Wac series Wax series Nwa1123-acv2 Nwa1123-ac pro Nwa1123-ac hd Nwa1302-ac ... Show all

ZyXEL Communications NWA Series User Manual

Pa Rt I: Sta Nda lo Ne C O Nfig Ura Tio N

Pa Rt II: L O C a L C O Nfig Ura Tio N in C lo Ud Mo de

Pa Rt III: Appe Ndic E S a Nd T Ro Ub Le Sho O Ting

Appendix A Importing Certificates

Appendix B Ipv6

Appendix C Customer Support

Appendix D Legal Information

Quick Links

Troubleshooting

Related Manuals for ZyXEL Communications NWA Series

Summary of Contents for ZyXEL Communications NWA Series

This manual is also suitable for:

Table of Contents
