PT-3208 (2) Operational Description
Supplied Accessories
Item
Antenna
Speaker/microphone jack cover
Belt clip
Screw set
Instruction manual
Charging the Battery Pack
The battery pack is not charged at the factory; charge it before use.
Initially charging the battery pack after purchase or extended storage (greater than 2
months) will not bring the battery pack to its normal operating capacity. After
repeating the charge/discharge cycle two or three times, the operating capacity will
increases to normal.
DO NOT RECHARGE THE BATTERY PACK IF IT IS ALREADY
FULLY CHARGED. DOING SO MAY CAUSE THE LIFE OF THE
BATTERY PACK TO SHORTEN OR THE BATTERY PACK MAY
BE DAMAGED.
AFTER RECHARGING THE BATTERY PACK,DISCONNECT IT
FROM THE CHARGER. CHARGING THE BATTERY PACK FOR
MORE THAN 5 DAYS MAY REDUCE THE BATTERY PACK LIFE
DUE TO OVERCHARGING.
Note:
The ambient temperature should be between 41 and 104°F (5 and 40 ) while
charging is in progress.Charging outside this range may not fully charge the
battery.
Always switch OFF the transceiver equipped with a battery pack before charging.
Using the transceiver while charging its battery pack will interfere with correct
charging.
The battery pack life is over when its operating time decreases even though it is
fully and correctly charged. Replace the battery pack.
Plug the AC adaptor cable into the adaptor jack located on the rear of the charger.
Plug the AC adaptor into an AC outlet.
Slide the battery pack or transceiver with a battery pack into the charger.
Make sure the battery pack contacts are in contact with the charging terminals.
The charger LED lights and charging begins.
After charging the supplied KNB-15A battery pack for 8 hours, remove it or the
transceiver equipped with it from the charger.
The charger does not turn OFF automatically after charging is completed.
Quantity
1
1
1
1
1
PREPARATION
1
Advertisement
Table of Contents
Related Manuals for Kirisun PT-3208
Summary of Contents for Kirisun PT-3208
- Page 1 PT-3208 (2) Operational Description Supplied Accessories Item Quantity Antenna Speaker/microphone jack cover Belt clip Screw set Instruction manual PREPARATION Charging the Battery Pack The battery pack is not charged at the factory; charge it before use. Initially charging the battery pack after purchase or extended storage (greater than 2 months) will not bring the battery pack to its normal operating capacity.
- Page 2 Unplug the AC adaptor from the AC outlet. Note: It takes approximately 6 hours to fully charge the optional KNB-14 battery pack. Installing /Removing the Battery Pack The average life of the supplied KNB-15A battery pack is 8 hours. Average times are calculated using 5% transmit time, 5% receive time, and 90% standby time.
- Page 3 Turn clockwise to switch ON the transceiver. To switch OFF the transceiver, turn counterclockwise until a click sounds. Rotate to adjust the volume level. PT-3208 OPERATION Switch ON the transceiver by turning the Power switch/Volume control clockwise. A beep sounds.
- Page 4 Note: Although using channels set up with QT/DQT tones relieves you from listening to unwanted calls, it does not mean your calls will be private. OPTIONAL ACCESSORIES You can use the following accessories with your transceiver: Long Life Battery (7.2V/1100mAh) Head Set with VOX (Voice Operated Transmit) Speaker/Microphone (Standard Duty) Speaker/ Microphone (Light Duty)
