We are very grateful for your purchasing
Shenzhen Kirisun Electronics Co., Ltd.
We believe
great convenience to your life and work.
We also believe that the quality and function of
demands for reliable communication.
Instructional Icons
This radio is not intended for use by general population in an uncontrolled environment. It is only
for occupational use and only applied to work-related conditions.
The radio must be only used by users, who are fully aware of the hazards of the exposure and who
are able to exercise control over their RF exposure to qualify for the higher exposure limits.
The following icons are available through this manual:
Notice to the User:
* Government laws prohibit radio communication without permission in government districts.
* Illegal operation is subject to punishment by fine and/or imprisonment.
* Refer service to the well-trained professional technicians only.
Safety:
It is important that the user is aware of and understands hazards common to the operation of
any radio.
Warning:
.
Turn off your radio before entering any area with a potentially explosive atmosphere (where
the air contains gas, dust and smog, etc.), such as while taking on fuel, or while parking at a
gasoline service station.
Attentions:
Please comply with the following attentions to avoid fire, bodily injury and damage to the
radio.
* Long time transmitting or continuous working in high power mode will make the rear side of the
radio generate heat.
* Please do not disassemble or assemble the radio under any circumstance.
* Please do not expose the radio to direct sunlight for a long time; do not place the radio near any
heating device, either.
* Please do not put the radio in extremely dusty, moist or dabbling places; do not place it on any
unstable surface, either.
* If the radio emits smoke or strange odors, turn it off and remove the battery from the radio and
contact your local authorized Kirisun dealer without delay.
Instruction Manual
PT3600
FM HANDHELD TRANSCEIVER
two-way radio, which always incorporates the latest technology, can bring
brand two-way radios produced by
two-way radio can meet your
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Kirisun PT360002
Summary of Contents for Kirisun PT360002
- Page 1 * Please do not put the radio in extremely dusty, moist or dabbling places; do not place it on any unstable surface, either. * If the radio emits smoke or strange odors, turn it off and remove the battery from the radio and contact your local authorized Kirisun dealer without delay.
- Page 2 RF Energy Exposure Compliance ● Your radio is designed and tested to comply with a number of national and international standards and guidelines (listed below) regarding human exposure to radio frequency electromagnetic energy. This radio complies with the IEEE and ICNIRP exposure limits for occupational/controlled RF exposure environment at operating duty factors of up to 50% transmitting and is authorized by the FCC for occupational use only.
- Page 3 FCC Licensing Information Part 15 Compliance This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
-
Page 4: Table Of Contents
Contents 1. Unpacking and Checking ......................5 2. Preparation ............................5 2.1 Charging the Battery ......................5 2.2 Installing/Removing the Battery ..................6 2.3 Installing the Antenna ......................7 2.4 Installing the External Speaker/MIC...................7 2.5 Installing/Removing the Belt Clip ..................7 3. Radio Overview ..........................8 4. Basic Operations ...........................9 4.1 Switching On........................9 4.2 Adjusting the Volume ......................9 4.3 Selecting a Channel......................9... -
Page 5: Unpacking And Checking
1. Unpacking and Checking Unpack the radio carefully. We recommend that you check the radio and the supplied accessories listed in the following table before discarding the packing material. If any damage or loss has occurred during shipment, please contact the dealer without delay. Supplied accessories Item Quantity... -
Page 6: Installing/Removing The Battery
* The radio battery is not fully charged in the factory. Before the initial use, please charge the new battery. * KB-31A Li-poly battery of Kirisun is applicable to this radio. * When charging the battery for the first time after purchase or long-time storage (over 2 months), please repeat charging several times for the battery to achieve normal capacity. -
Page 7: Installing The Antenna
To remove the battery pack, push the battery latch upwards, and then remove the battery away from the radio. Note: * Do not short-circuit the battery terminals or dispose battery in fire. * Do not disassemble the battery casing by yourself. 2.3 Installing the Antenna Hold the base of the antenna and turn the antenna clockwise into the connector on the top of the radio until secure. -
Page 8: Radio Overview
3. Radio Overview 1. PTT (Push-To-Talk) Button To make a call, press and hold the PTT button, then speak into the microphone. Release the PTT button to receive signals. 2. Programmable Button 2 You can assign functions to this button through PC software. 3. -
Page 9: Basic Operations
you hear a click to turn it off. Rotate it to adjust the volume after turning on the radio. 7. LED Indicator Lights red while transmitting; lights green while receiving; flashes red when the radio is in low power while transmitting. 8. -
Page 10: Sending A Call
4.4 Sending a Call To make a call, press and hold the PTT button and speak to the microphone in normal voice. Please keep your mouth 3 - 8 cm away from the microphone. 4.5 Receiving a Call Adjust the volume to a proper level. Release the PTT button to receive a call. 5. -
Page 11: Scan Function
Press the preprogrammed High/Low Power Switch button to switch the current channel power between high and low. ● Battery Check Press the preprogrammed Battery Check button, the current battery power level can be heard. There are four levels in all. Level 4 indicates that the battery power is full, and level 1 indicates that the battery power is low. -
Page 12: Auxiliary Functions
When pressing the PTT button during scanning, the radio will transmit from the channel selected by the channel selector knob. ● You can choose to set one of the following 3 operations when the channel is switched during scanning: 1. No operation. 2. -
Page 13: Low Battery Warning
7.4 Low Battery Warning When the battery voltage drops too low while transmitting, the LED flashes red, low battery warning tone sounds, and the radio stops transmitting. You need to recharge or change the battery. 7.5 Monitor When there is no signal received, the radio's squelch circuit will mute the speaker automatically so that the background noise will not be heard by the user. -
Page 14: Major Specifications
The communication range is * Make sure the antenna is well connected. too short. * Make sure the antenna is the original supplied one. * Check if the battery power is in normal state. * Ask your local dealer to adjust the squelch level. 9. - Page 15 2. The way to resume scanning after its pause: Time Operate Carrier Operate □ □ 3. Revert channel: Selected Channel Selected Channel or Currently Working Channel □ □ Priority Channel Priority Channel or Currently Working Channel □ □ Last Called Channel □ Last Working Channel + Currently Working Channel □...
