Remote Annunciation
Annunciation outputs are provided for alarm, remote trouble indicator and buzzer. Cut JW7 to
enable lamp supervision for the remote annunciator alarm zones. Refer to Figure 6 on page 9 for
wiring instruction.
A.C. Power and Batteries
The A.C. power is connected to the terminal block above the transformer.
Use Gel Cell or Sealed Lead-Acid type of batteries only. Connect the batteries after power up. Use
24V 4AH batteries for 24 hours standby and 5 or 30 minutes of alarm. For greater accuracy, use the
battery calculations chart located in Appendix B on page 14.
ELECTRICAL RATING: 120V, 60Hz, 1A / 240V, 50Hz, 0.5A
Trouble Indicators and Controls
Refer to Figure 2 on page 6 for the location of indicators and controls.
Common Trouble LED
The yellow Common Trouble LED will flash and the buzzer will sound for any trouble in the panel
(unless DSW1-8 is ON, then the common trouble LED will illuminate steadily and the buzzer will
sound).
Buzzer/Buzzer Silence Switch
The buzzer will sound intermittently for any trouble. The buzzer will sound steadily for any alarm in
the system. Operating the Buzzer Silence switch will silence the buzzer. Any subsequent alarm will
resound the buzzer. Turning the Buzzer Silence switch OFF normal will sound the buzzer steadily.
Zone Trouble LED
The yellow Zone Trouble LED will illuminate steadily for an open loop in the zone wiring. Refer to
Figure 2 on page 6 for the location of indicators and control.
Battery Fault LED
Battery removal, low voltage and open battery leads will turn on the yellow Battery Fault LED and
the Common Trouble LED.
Ground Fault LED
Any ground fault of 10K ohms or less will turn on the yellow Ground Fault LED steadily, flashing the
Common Trouble LED and sounding the common trouble buzzer intermittently.
Remote Lamp Fail LED
Any open on the supervised remote annunciator wiring will illuminate the yellow Remote Lamp Fail
LED steadily, flash the Common Trouble LED and the Common Trouble buzzer will sound
intermittently.
Signal Trouble LED
The yellow Signal Trouble LED will illuminate steadily for any open or short. (The LED is located
behind the display plate.)
FA-1025T Installation and Operation Manual
3
