Parts List - Linear Technology DC2026 Demo Manual

PARTS LIST

ITEM QTY REFERENCE
1 2 C1, C7
2 2 C2, C14
3 4 C3, C9, C12, C15
4 5 C4, C13, C17, C18, C23
5 1 C5
6 1 C6
7 10 C8, C19-C22, C25, C28, C32-C34
8 1 C10
9 1 C11
10 1 C16
11 1 C24
12 1 C26
13 1 C27
14 0 C29
15 2 C30, C31
16 3 D1, D4, D5
17 1 D2
18 1 D3
19 1 JP3
20 1 J1
21 1 J2
22 2 J3, J8
23 1 J4
24 1 J5
25 1 J6
26 1 J7
27 1 L1
28 1 L2
29 4 MP1-MP4
30 1 Q1
31 1 R1
32 1 R2
33 1 R3
34 1 R4
35 1 R5
36 4 R6, R7, R9, R10
37 6 R8, R25, R48, R52, R53, R54
38 0 R11, R32
39 14 R12, R13, R15, R17, R20, R21,
R22, R23, R24, R35, R36, R42,
R44, R46
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
DEMO MANUAL DC2026C
PART DESCRIPTION
CAP., X5R, 4.7μF, 16V, 10%, 0603
CAP., X7R, 0.01μF, 16V, 10%, 0603
CAP., X5R, 10μF, 16V, 10%, 0805
CAP., X7R, 1μF, 16V, 10%, 0603
CAP., NPO, 15pF, 50V, 10%, 0603
CAP., X5R, 4.7μF, 25V, 10%, 0805
CAP., X7R, 0.1μF, 16V, 10%, 0603
CAP., COG, 10pF, 25V, 10%, 0402
CAP., X5R, 22μF, 6.3V, 20%, 1206
CAP., X7R, 2.2μF, 50V, 10%, 1206
CAP., X7R, 0.047μF, 16V, 10%, 0603
CAP., ALUM., 10μF, 50V, 10%, SMT
CAP., X5R, 0.22μF, 10V, 20%, 0402
CAP., OPT, 0805
CAP., X7R, 2.2nF, 1kV, 10%, 1206
LED,YELLOW, DIFFUSED, 0805
LED, GREEN, DIFFUSED, 0805
DIODE, SCHOTTKY, 100V, 2A, SMB
HEADER, 2×4 PIN, 0.079CC
HEADER, 2×7 DUAL ROW
CONNECTOR, POWER JACK, 2.1mm
CONN., RECEPT., 0.100, 8 POSITION
HEADER, 2×3 PIN, 0.100
CONNECTOR, USB TYPE B, RIGHT ANGLE PCB MOUNT
CONN., RECEPT., 0.100, 10 POSITION
CONN., RECEPT., 0.100, 6 POSITION
INDUCTOR, 15μH, 1.3A, SMD
INDUCTOR, SHIELDED POWER, 10μH, SMT
BUMPER, ADHESIVE-BACKED
TRANSISTOR, MOSFET, N-CH 60V,150mA, SOT-23
RES., CHIP, 64.9k, 1/10W, 1% 0603
RES., CHIP, 47.5k, 1/10W, 1% 0603
RES., CHIP, 215k, 1/10W, 1% 0603
RES., CHIP, 13.7k, 1/10W, 1% 0603
RES., CHIP, 42.2k, 1/10W, 1% 0603
RES., CHIP, 4.99k, 1/10W, 1% 0603
RES., CHIP, 49.9k, 1/10W, 1% 0603
RES., CHIP, OPT, 0805
RES., CHIP, 1k, 1/10W, 1% 0603
MANUFACTURER/PART NUMBER
TDK, C1608X5R1C475K080AC
AVX, 0603YC103KAT2A
MURATA, GRM21BR61C106KE15L
TDK, C1608X7R1C105K080AC
AVX, 06035A150KAT2A
TDK, C2012X5R1E475K125AB
AVX, 0603YC104KAT2A
AVX, 04023A100KAT2A
TAIYO YUDEN, JMK316ABJ226MLHT
MURATA, GRM31CR71H225KA88L
AVX, 0603YC473KAT2A
SUN ELECT., 50CE10BSS
AVX, 0402ZD224MAT2A
OPTION
AVX, 1206AC222KAT1A
AVAGO, HSMY-C170
AVAGO, HSMG-C170
DIODES INC., B2100-13-F
SULLINS, NRPN042PAEN-RC
MOLEX, 87831-1420
CUI INC., PJ-002AH
SULLINS, PPPC081LFBN-RC
SAMTEC, TSW-103-07-L-D
FCI, 61729-0010BLF
SULLINS, PPPC101LFBN-RC
SULLINS, PPPC061LFBN-RC
COOPER MPI4040R3-150-R
COILCRAFT, XFL3010-103ME
3M, SJ5376
DIODES INC., VN10LFTA
VISHAY, CRCW060364K9FKEA
VISHAY, CRCW060347K5FKEA
VISHAY, CRCW0603215KFKEA
VISHAY, CRCW060313K7FKEA
VISHAY, CRCW060342K2FKEA
VISHAY, CRCW06034K99FKEA
VISHAY, CRCW060349K9FKEA
OPTION
VISHAY, CRCW06031K00FKEA
