DEMO MANUAL DC2026C
PARTS LIST
ITEM QTY REFERENCE
40 1 R14
41 1 R16
42 5 R18, R40, R41, R45, R47
43 1 R19
44 5 R25, R48, R52, R53, R54
45 1 R26
46 1 R27
47 1 R28
48 1 R29
49 1 R30
50 1 R31
51 0 R33, R34, R37, R38, R43
52 1 R39
53 1 R49
54 1 R50
55 1 R51
56 2 R55, R56
57 1 R57
58 1 S1
59 1 U1
60 1 U2
61 1 U3
62 1 U4
63 1 U5
64 1 U6
65 1 U7
66 1 U8
67 1 U9
68 1 U10
69 1 U11
70 2 U12, U13
71 1 XJP3
72 1 Y1
14
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
PART DESCRIPTION
RES., CHIP, 1MEG, 1/16W, 1%, 0402
RES., CHIP, 1MEG, 1/10W, 1%, 0603
RES., CHIP, 10k, 1/10W, 1%, 0603
RES., CHIP, 86.6k, 1/10W, 1%, 0603
RES., CHIP, 49.9k, 1/10W, 1%, 0603
RES., CHIP, 0.20Ω, 1/4W, 5%, 0805
RES., CHIP, 107k, 1/16W, 1%, 0402
RES., CHIP, 475k, 1/16W, 1%, 0402
RES., CHIP, 215k, 1/16W, 1%, 0402
RES., CHIP, 316k, 1/16W, 1%, 0402
RES., CHIP, 100Ω, 1/10W, 5%, 0603
RES., CHIP, OPT, 0603
RES., CHIP, 0Ω, 1/10W, 0603
RES., CHIP, 105k, 1/10W, 1%, 0603
RES., CHIP, 19.1k, 1/10W, 1%, 0603
RES., CHIP, 40.2k, 1/10W, 1%, 0603
RES., 49.9Ω, 1/10W, 1%, 0603
RES., 24.9Ω, 1/10W, 1%, 0603
SWITCH, PUSHBUTTON, MINIATURE
MODULE, USB TRANSCEIVER, BGA-44
IC, DC-DC CONVERTER, TSOT-23
IC, LDO MICROPOWER REGULATOR, ADJUSTABLE, TSOT-23
IC, BUS BUFFER, 2-WIRE, MSOP
IC, LDO MICROPOWER REGULATOR, 3.3V, TSOT-23
IC, IDEAL DIODE, LOW LOSS,TSOT-23
IC, MICROCONTROLLER
IC, LDO MICROPOWER REGULATOR, ADJUSTABLE, TSOT-23
IC, USB UART, 28-SSOP
IC, STEP-DOWN REGULATOR, MS10
IC., SINGLE/DUAL-SUPPLY COMPARATOR
IC, TRI-STATE UHS BUFFER, US8
SHUNT, 2mm
RESONATOR, 16MHz, SMT
MANUFACTURER/PART NUMBER
VISHAY, CRCW04021M00FKED
VISHAY, CRCW06031M00FKEA
VISHAY, CRCW060310K0FKEA
NIC, NRC06F8662TRF
VISHAY, CRCW060349K9FKEA,
NIC, NRC06F4992TRF
PANASONIC, ERJ-S6SJR20V
VISHAY, CRCW0402107KFKED
VISHAY, CRCW0402475KFKED
VISHAY, CRCW0402215KFKED
VISHAY, CRCW0402316KFKED
VISHAY, CRCW0603100RJNEA
OPTION
VISHAY, CRCW06030000Z0EA
VISHAY, CRCW0603105KFKEA
VISHAY, CRCW060319K1FKEA
VISHAY, CRCW060340K2FKEA
NIC, NRC06F49R9TRF
NIC, NRC06F24R9TRF
WÜRTH ELEKTRONIK, 434111025826
LINEAR TECH., LTM2884CY#PBF
LINEAR TECH., LT3461ES6#PBF
LINEAR TECH., LT1761ES5-SD#PBF
LINEAR TECH., LTC4315CMS#PBF
LINEAR TECH., LT1761ES5-3.3#PBF
LINEAR TECH., LTC4411ES5#PBF
ATMEL, ATMEGA328P-AU
LINEAR TECH., LT1761ES5-BYP#PBF
FTDI, FT232RL-REEL
LINEAR TECH., LT3973EMSE#PBF
LINEAR TECH., LT1719CS6#PBF
FAIRCHILD, NC7WZ125K8X
SAMTEC, 2SN-BK-G
MURATA, CSTCE16M0V53-R0
