TELECO AUTOMATION TVRDS868B01 Installer Instruction Manual page 2

INDEX
1. PRODUCT DESCRIPTION
2. INSTALLATION
2.1 Mounting the product
2.2 Mounting the wireless safety system (BST24/BST25/BST25S)
2.3 Control unit diagram
2.4 Electrical connections
2.5 Wired safety device connections
3. PRELIMINARY CHECK AND INITIAL START-UP
3.1 Limit switch configuration
3.2 Deactivation of wireless safety system
3.3 Exclusion of safety edge in the last 5cm of the closure
3.4 Light output mode
4. TRANSMITTERS MEMORIZATION
4.1 Single channel memorization
4.2 Double channel memorization
4.3 Single channel: Courtesy light ON/OFF
4.4 Four channels memorization
4.5 Remote memorization of the first transmitter
4.6 Remote memorization of further transmitters
4.7 Alarm function: shock sensor memorization
4.8 Single channel: door status request ("ASK")
5. TRANSMITTERS DELETION
5.1 Deleting a single transmitter
5.2 Deleting all the transmitters
5.3 Remote deletion of a transmitter
6. TIME SETTINGS
6.1 Auto close time setting
6.2 Courtesy light time setting
7. OTHER PROGRAMMING
7.1 "Holiday mode"
7.2 Control unit reset
8. TECHNICAL SPECIFICATIONS
8.1 WARNINGS
9. TROUBLESHOOTING (What to do if...)
--------------------------------------------------------------- p. 3
----------------------------------------------------------------------- p. 4 - 7
------------------------------------------------------- p. 11 - 13
------------------------------------------------------- p. 14
----------------------------------------------------------------------- p. 15
------------------------------------------------------- p. 16
------------------------------------------------------- p. 17
----------------------------------------------- p. 18 - 19
--------------------------------------- p. 8 - 10
2
